Summary of Contents for Aspes ALF3138

  • Page 1 Washing Machine / User Manual ALF3138...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...

  • Page 3: Table Of Contents

    CONTENTS 1. SAFETY INSTRUCTIONS ....................1 1.1 General Safety Warnings ....................2 1.2 During Use ........................6 1.3 Packaging and Environment...................7 1.4 Savings Information ......................8 2. TECHNICAL SPECIFICATIONS ..................9 2.1 Technical Specifications ....................9 3. INSTALLATION .......................10 3.1 Removing the Transit Bolts...................10 3.2 Adjusting the Feet / Adjusting Adjustable Stays............10 3.3 Electrical Connection ....................10 3.4 Water Inlet Hose Connection ..................

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS Operating voltage / frequency (220-240) V~/50Hz Total current (A) Water pressure (Mpa) Maximum 1 Mpa / Minimum 0. 1Mpa Total power (W) 2100 Maximum washing capacity (dry laundry) (kg) • Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base.

  • Page 5: General Safety Warnings

    NOTE: For a softcopy of this user manual, please contact the following address: “info@aspes.es”. In your e-mail, please provide the model name and serial number (20 digits) which you can find on the appliance door. Read this user manual carefully.
  • Page 6 • Residue may build up on detergent and softeners exposed to air for a long period of time. Only put softener or detergent in the drawer at the beginning of each wash. • Unplug your Washing Machine and switch off the water supply if the Washing Machine is left unused for a long time.
  • Page 7 • Washing laundry containing flour may damage your machine. • Please follow the manufacturers’ instructions regarding the use of fabric conditioner or any similar products that you intend to use in your Washing Machine. • Make sure that the door of your Washing Machine is not restricted and can be opened fully.
  • Page 8 or give you an electric shock. When damaged it must be replaced, this should only be done by qualified personnel. Risk of flooding • Check the speed of water flow before placing the drain hose in a sink. • Take necessary measures to prevent the hose from slipping.

  • Page 9: During Use

    The machine must be carried by at least 2 people. Child safety • Do not leave children unattended near the machine. Children might lock themselves in the machine resulting in risk of death. • Do not allow children to touch the glass door during operation.

  • Page 10: Packaging And Environment

    hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be done by children without supervision. • Only use your machine for laundry that is labelled as suitable for washing by the manufacturer. • Before operating the washing machine, remove the 4 transit bolts and rubber spacers from the rear of the machine.

  • Page 11: Savings Information

    1.4 Savings Information Some important information to get the most efficient use out of your machine: • Do not exceed the maximum load for the washing programme you have chosen. This will allow your machine to run in energy saving mode. •...

  • Page 12: Technical Specifications

    2. TECHNICAL SPECIFICATIONS 2.1 Technical Specifications Operating voltage / (220-240) frequency V~/50Hz (V/Hz) Total current Maximum: Water 1 Mpa pressure Minimum : (Mpa) 0.1 Mpa Total power 2100 Maximum dry laundry capacity (kg) Spinning revolution 1200 (rev / min) Programme number General Appearance Dimensions...

  • Page 13: Installation

    3. INSTALLATION 3.2 Adjusting the Feet / Adjusting Adjustable Stays 3.1 Removing the Transit Bolts 1. Do not install your machine on a surface (such as carpet) that would prevent ventilation at the base. • To ensure silent and vibration-free operation of your machine, install it on a firm surface.

  • Page 14: Water Inlet Hose Connection

    • The mains cord of your washing should be connected to cold water inlet machine is equipped with an earthed and red capped hose to the hot water plug. This plug should always be inlet (if applicable). inserted to an earthed socket of 10 •...

  • Page 15: Water Discharge Connection

    3.5 Water Discharge Connection 4.1 Detergent Drawer • Connect the water drain hose to a standpipe or to the outlet elbow of a household sink, using additional equipment. • Never attempt to extend the water drain hose. • Do not put the water drain hose from your machine into a container, bucket or bathtub.

  • Page 16: Sections

    4.2 Sections Powder detergent compartment: If you want to use the softener function, • If you press the softener dosage key 3 If you want to use powder detergent for times consecutively, the softener LED the washing cycle, please deactivate the appears on the LED display, indicating auto dosing function and use the powder that the softener function is enabled.

  • Page 17: Warnings For The Automatic Detergent Dosing System

    Only liquid detergent can be used in this compartment. If you want to use the powder detergent compartment: You should deactivate the liquid detergent (auto dosing) function. • When you first press the detergent NOTE: dosage key, will be shown on the Liquid detergent (auto LED display respectively, indicating dosing) level should be selected according...

  • Page 18: Program Dial

    4.5 Electronic Display detergent properly. WARNING: The drawer should not be open while the product is running. Detergent drawer: 1. When you remove the drawer, make sure that it is empty. Otherwise, you may pour the detergent in it. 2. When the detergent drawer is full: •...

  • Page 19: Using Your Washing Machine

    5. USING YOUR curtains or place them in a washing net or bag. WASHING MACHINE 6. Reverse textiles such as pants, knitwear, t-shirts and sweat shirts. 5.1 Preparing Your Laundry 7. Wash socks, handkerchiefs and other small items in a washing net. Can be Normal Do not bleach...

  • Page 20: Operating Your Machine

    The following table shows approximate 5.4 Selecting a Programme weights of typical laundry items: Use the programme tables to select the most appropriate programme for your LAUNDRY TYPE WEIGHT (gr) laundry. Towel 5.5 Half-Load Detection System Linen Your machine features a half-load detection Bathrobe 1200 system.
  • Page 21 2. Spin Speed Selection If you have pressed the Start/ Pause key to start the machine, you just need to press the delay key once. will go off on the electronic display. If you have not pressed the Start/ Pause key, press the delay key continuously until goes off on the electronic display.

  • Page 22: Child Lock

    Start/Pause button 5.8 Cancelling the Programme To cancel a running programme at any time: 1. Turn the programme dial to the “STOP” position. 2. Your machine will stop the washing operation and the programme will be cancelled. By pressing on the Start/Pause button, 3.

  • Page 23: Programme Table

    6. PROGRAMME TABLE Programme Laundry type / Descriptions Very dirty, cotton and flax textiles. COTTON *60-90-80-70-40 (Underwear, linen, tablecloth, towel (maximum 4,0 kg), bedclothes, etc.) Dirty cotton and flax textiles. ECO 40-60 *40 - 60 (Underwear, linen, tablecloth, towel (maximum 4,0 kg), bedclothes, etc.) Dirty cotton and flax textiles.
  • Page 24 NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. (*) Washing water temperature of the programme is the factory default. (**) If your machine has the rapid wash auxiliary function, you can enable the quick wash option on the display panel and load the machine with 2 kg or less laundry to wash it in 30 minutes.
  • Page 25 • The most efficient programmes in terms of energy consumption are generally those that perform at lower temperatures and longer duration. • Loading the household washing machine up to the capacity indicated by the manufacturer for the respective programmes will contribute to energy and water savings.

  • Page 26: Important Informations

    6.1 Important Informations • Use detergents, softeners and other additives suitable for automatic washing machines only. Excessive foam has occurred and automatic foam absorption system has been activated due to too much detergent usage. • We recommend that periodic cleaning for washing machine every 2 months. For periodic cleaning please use Drum Clean programme.

  • Page 27: Cleaning And Maintenance

    7. CLEANING AND 7.2 Water Inlet Filters Water inlet filters prevent dirt and foreign MAINTENANCE materials from entering your machine. We recommend that these filters are cleaned when your machine is unable to receive 7.1 Warning sufficient water, although your water supply is on and the tap is open.

  • Page 28: Pump Filter

    7.3 Pump Filter meet the holes on the front panel side. 6. Close the filter cover. WARNING: The water in the pump may be hot, wait until it has cooled down before carrying out any cleaning or maintenance. (*) Specifications may vary depending on the machine purchased.

  • Page 29: Detergent Drawer

    7.4 Detergent Drawer • Pull the detergent drawer as much as possible. Your detergents may form deposition on the detergent drawer and drawer • Keep on pulling the detergent drawer detergent slot. Remove the detergent as much as possible by pressing drawer periodically to clean the formed the area shown in the pictures in the deposition.

  • Page 30: Body / Drum

    To clean such rust stains, use a non-chlorine cleaning agent and follow the instructions of manufacturer of the cleaning agent. Never use wire wool or similar hard objects for cleaning rust stains. www.aspes.es EN - 27...

  • Page 31: Troubleshooting

    9. TROUBLESHOOTING Repair of your machine should be carried out by an authorised service company. If your machine requires repair or if you cannot solve an issue with the information provided below, then you should: • Unplug your machine from the mains power supply. •...

  • Page 32: Automatic Fault Warnings And What To Do

    FAULT POSSIBLE CAUSE TROUBLESHOOTING Your washing is too dirty for the Use the information in the programme tables to programme selected. select the most appropriate programme. Unsatisfactory washing Amount of detergent used Use the amount of detergent as instructed on the result.
  • Page 33 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 34 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 35 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 36 The minimum period which must supply the spare parts for the household washing machine is 10 years. WWW.ASPES.ES aspes@sareteknika.es; 902 99 69 01 / 944 04 14 08 52401717...
