- Page 1 - Installation Manual - Simple bracket solar street light 6.1 / 8.1 Installation Manual – POWER 365 –6.1 – 8.1 – 2020/03/18 – Page 1 of 18...
-
Page 2: How Does It Work
How does it work ? The battery gets loaded during daytime with the electricity produced by the solar panel (PV). Nighttime is detected by measuring the voltage of the solar panel : - daytime PV voltage > 30V - nighttime ... - Page 3 Maintenance - swap Likewise, control the right fit bracket/pole, if any operating The client is responsible for returning any defective part to FONROCHE problem is found, claim damage to FONROCHE Lighting. Lighting for expertise. After receipt of the defective parts, FONROCHE Lighting will determine the guarantee validity.
- Page 4 FCC Regulatory notices Modification statement “Fonroche Lighting” has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. Interference statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 5: Part List
Part list Thread Tightening N° screw type torque (Nm) > 10 > 24 3, 8, > 47,7 setscrews M10 Setscr e ws Page 5 of 18... - Page 6 Use a draw wire (fish-tape) to draw the connector cable of For all the setup, every screw/nut system must be the lantern through the bracket to the top. tightened to the torque advocated by FONROCHE* Be careful setting the nuts on the top side of the luminary...
- Page 7 Insert the tube into the bracket Assemble the bracket on the pole and orientation Insert the cable into the tube. Orient the luminary, fasten slightly each setscrew, and then tighten them all. Page 7 of 18...
- Page 8 Assemble the base support IMPORTANT Be so attentive to the lantern Set to 20° (unless otherwise stated). cable inside the tube when passing the screws N ° 3. Page 8 of 18...
- Page 9 Assemble the support for PV modules Be careful to set the screws n°8 in the same way as illustrated in the scheme to avoid any problem when installing the battery. Page 9 of 18...
- Page 10 Install the first PV binding, on Erect the street light the ground Install only one PV binding n°15 before erecting the pole 4 & 5 Once the street light erected, go to step 9. Page 10 of 18...
- Page 11 Install the second binding, the Assemble the PV battery and connect the luminary Box Energy Labels up Same steps as step 7. Pass the cable under the battery. Energy Box label should be positioned always to upside (direction to PV). Do not leave the cable hanging under the support.
- Page 12 Orient the PV to the south Orient the PV towards the equator, Tighten the 8 setscrews, Position the luminaries straight in order to optimize the lighting. Page 12 of 18...
-
Page 13: Please Wait
Initialize the battery Connect the PV to the battery Please wait 30 seconds after plugging for system activation pour que le système s’active Page 13 of 18... - Page 14 Validate your installation Detach one connector of each PV with the « Universal tool disconnect » n°1. Page 14 of 18...
- Page 15 Wait 1 min max, light must switch ON Then you can reconnect the PV. Wait another min max light must switch off Light ON If light switches OFF, installation is OK. You can bind all the cables with cable ties. Page 15 of 18...
- Page 16 Streetlight Labeling Very Important Box Energy serial number should be the same streetlight serial number Streetlight pole label to be pasted and protected with a larger transparent film protection. IMPORTANT Degreasing and cleaning are 2 Meters mandatory on the place where the label will be affixed.
- Page 17 Last step of installation – Check-list Installer check Check points (write OK or no) Are lanterns straight positioned to optimize the lighting? Are the 16 pressure screws installed and correctly tightened? Is the PV oriented to the south? If several solar street lights are installed, are the PVs oriented towards the same direction? Is the PV set to 20°...
-
Page 18: Troubleshooting
Batteries are discharged Check tilt angle and orientation of the solar module. several days Wait some days if it is winter, if not call FONROCHE Lighting for further actions. For any other problem, please contact FONROCHE Lighting: sav@fonroche-lighting.com...
