EST CM1 Installation Manual

Network controllers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Network Controllers
Installation Manual
P/N 270239
Revised 14JUL97
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM1 and is the answer not in the manual?

Questions and answers

Related Manuals for EST CM1

Summary of Contents for EST CM1

  • Page 1 Network Controllers Installation Manual P/N 270239 Revised 14JUL97 firealarmresources.com...
  • Page 2 Edwards Systems Technology, Inc. If you distribute any information contained in this manual to unauthorized persons, you have violated all distributor agreements and we may take legal action. CREDITS This manual was designed and written by the EST Technical Services - Documentation Department, Sarasota. firealarmresources.com...

  • Page 3: Table Of Contents

    Content CM1 Master Control Module Applicable Modules and Options 1 Description Application Specifications 2 Installation Indicators Controls CM1 System Configuration CM1N and RMDP-1N Master Control Modules 8 Applicable Modules And Options Description Application Specifications 10 Installation Indicators Controls System Configuration...
  • Page 4 Troubleshooting CPU-3/1N and CPU-3/2N Control Module Cards Description Application Specifications 36 Installation Troubleshooting COMM-3 Communications Card Description Application Specifications 39 Installation Indicators Programming Notes Application Drawings COMM-3S Serial Communications Card Description Application Specifications 44 Installation Indicators Programming Notes SO-20 Serial Option to 20mA Loop Module Description Application Specifications 46...
  • Page 5 Jurisdiction is mandatory. EST, Inc. shall not under any circumstances be liable for any incidental or consequential damages arising from loss of property or other damages or losses owing to the failure of EST, Inc. products beyond the cost of repair or replacement of any defective products.
  • Page 6 Document history Network Controllers Installation Manual P/N 270239 Revision Status Revision Date Reason For Change September 1995 Initial Release. July 1997 Layout and content revisions. Network Controllers Manual firealarmresources.com...

  • Page 7: Cm1 Master Control Module

    The CM1 is the master controller for a 576 point non-networked system. This controller contains all the circuitry, memory, instructions, and controls to define a system. The CM1 incorporates a 2 line, 40 character alpha-numeric LCD display, a keypad for manual control, LED status indicators, and panel control switches.

  • Page 8: Application

    Application The CM1 is designed to provide the master control function for a system of up to 576 points. Each system must have a CM1 which provides 32 panel addresses. A variety of system communication formats are available.

  • Page 9: Installation

    250 W @ 25 VRMS Max. Wire Size 14 AWG Mounting One module footprint CM1 firmware revision level may be determined by looking at the label on the EPROM chip U3 on the CPU card. Installation Disconnect power before removing or installing modules. Caution:...

  • Page 10: Indicators

    COMM FOR OPTION PRINTER/ OPTION CARD SLOT CARD SLOT P5 PROGRAM PORT CONTROL PANEL SHLD FOR OPTION MOTHER BOARD CM1(N) or CM2(N) 2(-) CARD SLOT P5 & P6 2(+) CLASS A DATA SHLD FOR OPTION LINES OPTION CARD SLOT 1(-)
  • Page 11 Drill/All Call (integrated into drill/all call switch) - Yellow LED, indicates drill/all (action 9003) has been activated. CM1 CPU status is indicated by the CPU Fail LED on the associated power supply. CM1 communication status is indicated by LEDs on the communications cards.

  • Page 12: Controls

    Communications Failures: ComP = Primary Communications ComS = Secondary Communications ComE = External Command = No Good = Enabled Status Codes w/ZAS-2 = Communications between ZAS-2 & CPU = ZAS-2 Device Reset = ZAS-2 Card Restsrt = Mapping = ZAS-2 Card Programming = ZAS-2 Card Ground Fault = Class A Fault on ZAS-2 Circuit = Map Fault...

  • Page 13: Cm1 System Configuration

    (P/N 130080) or the COMM-3S serial communications card (P/N 130144). Two option cards may be installed in the CM1 in connectors P5 and P6. Details on option card programming and termination’s of CM1 terminal strips TB2, TB3, and TB4 may be found on each modules technical data sheet.

  • Page 14: Cm1N And Rmdp-1N Master Control Modules

    CM1N and RMDP-1N Master Control Modules Applicable Modules And Options This covers the following module/options: CM1N - (P/N 240100) CM1N-RM - (P/N 240235) CM1N-SG-L CM1N-SO-RM - (P/N 240236) CM1N-SG-RM-L CM1N-X-RM - (P/N 240281) CM1N-SO (P/N 240186) CM1N-X-SO-RM - (P/N 240282) CM1N-X-SO - (P/N 240212) CM1N-SG-SO - (P/N 240527) CM1N-X - (P/N 240211)
  • Page 15 control module, which also provides basic system operating instructions on its front panel. STATUS AND PROGRAM DISPLAY NORMAL ALARM SUPERVISORY TROUBLE TEST/PRGM RESET OPERATING INSTRUCTIONS NEXT/ACK-Acknowledges ALARM currently displayed SILENCE off-normal condition, then displays next BACK NEXT/ACK TROUBLE off-normal condition. SILENCE BACK- Reviews previously acknowledged off-normal...

  • Page 16: Application

    A variety of option modules are available to customize the function of each CM1(N). Available modules include: • Network Communications Cards • Intelligent Analog Sensor and control cards • Supervised Input Cards •...

  • Page 17: Installation

    COMM FOR OPTION PRINTER/ OPTION CARD SLOT CARD SLOT P5 PROGRAM PORT CONTROL PANEL SHLD FOR OPTION MOTHER BOARD CM1(N) or CM2(N) 2(-) CARD SLOT P5 & P6 2(+) CLASS A DATA SHLD FOR OPTION LINES OPTION CARD SLOT 1(-)

  • Page 18: Indicators

    Field Wiring Refer to COMM-3 or COMM-3S section for instructions. Refer to the section of the module installed in slot P5 for instructions. Terminals 1-6, refer to section of module installed in connector P5 for instructions. Terminals 5-10, refer to section of module installed in connector P6 for instructions.
  • Page 19 Alphanumeric Display A 40 character 2 line liquid crystal display provides system status and program information. 08:53:18 AP 0000 DP 0000 40 CHARACTER CUSTOM MESSAGE [NWC-003.CDR] CM1N Display Status Codes = Fuse = Ground Fault = AC Voltage = DC Voltage = Battery = Trouble = Internal Fault (ZAS Card/Continuity Jumper, Display,...

  • Page 20: Controls

    Controls Switches Reset - Returns system to normal state after all inputs have been restored. Calls action 9002. Alarm Silence - Silences audible devices. Calls predetermined action 9004. Pressing Alarm Silence twice initiates drill/all call. Trouble Silence - Silences local PS4/8B trouble buzzer. Drill/All Call - Generates general activation on all audible circuits per action 9003.
  • Page 21 Jumper Connections: Pins 6, 8, and 20 Pins 1, 4, and 6 Pins 4 and 5 Pins 7 and 8 CONTROL PANEL MOTHER BOARD CM1(N) or CM2(N) DB25 FEMALE or DB9 FEMALE Download Cable [NWC-004.CDR] TO PC SERIAL PORT Programming Connections Network Controllers Manual firealarmresources.com...

  • Page 22: Cm2 Secondary Control Module

    The CM2 is a secondary controller for use on non-networked systems. This controller contains all the circuitry, memory, instructions, and controls to communicate with the CM1 master controller. The customizing software which defines and configures each CM2 is stored in non-volatile EEPROM. Information is entered and/or modified with an IBM compatible personal computer.

  • Page 23: Application

    Application The CM2s expand the control function of the master controller. A variety of system communication formats is available to meet many applications. A variety of option modules are available to customize the function of each CM2. Available modules include: •...
  • Page 24 COMM FOR OPTION PRINTER/ OPTION CARD SLOT CARD SLOT P5 PROGRAM PORT CONTROL PANEL SHLD FOR OPTION MOTHER BOARD CM1(N) or CM2(N) 2(-) CARD SLOT P5 & P6 2(+) CLASS A DATA SHLD FOR OPTION LINES OPTION CARD SLOT 1(-)

  • Page 25: System Configuration

    The CM2 panel configuration menu (menu selection “3”) in the data entry program should be set as “supervised” power supply. Additional control modules should be set as “unsupervised” power supply when connected to the same power supply as the CM1 or another CM2. TB1-2 TB1-2...

  • Page 26: Cm2N Secondary Control Module

    CM2N Secondary Control Module Applicable Modules and Options This covers the following modules/options: CM2N - (P/N 240101) CM2N-RM - (P/N 240237) CM2N-SG-L CM2N-SO-RM - (P/N 240238) CM2N-SG-RM-L CM2N-SG-SO - (P/N 240536) CM2N-SO - (P/N 240184) CM2N-SG-SO-RM - (P/N 240538) CM2N-SG - (P/N 240535) CM2N-SG-RM - (P/N 240541) Description The CM2N is a secondary network controller for use on networked...

  • Page 27: Application

    The CM2N-L is a limited address control module. The CM2N-L only allows 14 addresses from the master controller. The additional addresses are available for annunciators. The CM2N is comprised of a control module motherboard, a display panel, and the following plug in cards: A.

  • Page 28: Installation

    Max. Current (riser current) 3.5 Amps DC 250 W @ 70 VRMS 250 W @ 25 VRMS Max. Wire Size (any terminal) 14 AWG Mounting One module footprint CM2N-RM RMOF and one module footprint CM2N firmware revision level may be determined by looking at the label on the PROM chip U3 on the CPU card.
  • Page 29 COMM FOR OPTION PRINTER/ OPTION CARD SLOT CARD SLOT P5 PROGRAM PORT CONTROL PANEL SHLD FOR OPTION MOTHER BOARD CM1(N) or CM2(N) 2(-) CARD SLOT P5 & P6 2(+) CLASS A DATA SHLD FOR OPTION LINES OPTION CARD SLOT 1(-)

  • Page 30: Indicators

    Indicators LEDs Four seven-segment LED displays provide system status CPU Fail LED on associated power supply indicates CM2N CPU status. LED’s on the communication cards indicate CM2N communication status Controls Switches Switches on the CM2N are only operational when the CM2N looses communications with the CM1N / FCC head end.

  • Page 31: Troubleshooting

    Jumper Connections: Pins 6, 8, and 20 Pins 1, 4, and 6 Pins 4 and 5 Pins 7 and 8 CONTROL PANEL MOTHER BOARD CM1(N) or CM2(N) DB25 FEMALE or DB9 FEMALE Download Cable [NWC-004.CDR] TO PC SERIAL PORT Programming Connections...
  • Page 32 Supervisory Short Sensor Alert Internal ZONE/DEVICE CODE 1. FIRE ALARM 2. SUP. OPEN To RESET, push 3. SUP SHORT both switches 4. SENSOR ALERT simultaneously P. INTERNAL P 001 = 24 Vdc output #1 or #2 fail P 002 = Ground fault P 003 = AC power fail P 004 = PS Internal voltage trouble P 005 = Battery or charger trouble...
  • Page 33 CM2N Display Codes with One ZAS and One Traditional Card Installed Zone/Device Display Code Affected Devices 001 - 096 Top ZAS Card Sensors 101 - 096 Top ZAS Card Modules 201 - 296 Bottom Traditional Card Zones 301 - 396 CM2N Display Codes with Two Traditional Cards Installed Zone/Device Display Code Affected Devices...

  • Page 34: Cm2Nd Secondary Control Module With Display

    CM2ND Secondary Control Module With Display Applicable Modules and Options This covers the following modules/options: CM2ND - (P/N 240284) CM2ND-SG-RM - (P/N 240541) CM2ND-RM - (P/N 240285) CM2ND-SG-SO - (P/N 240540) CM2ND-SO - (P/N 240286) CM2ND-SG-SO-RM - (P/N 240542) CM2ND-RM-SO - (P/N 240287) CM2ND-SG - (P/N 240539) Description The CM2ND is a secondary controller for use on networked IRC-...

  • Page 35: Application

    The CM2ND annunciates, via its alphanumeric display, messages for local alarm, supervisory open and supervisory short conditions. The CM2ND also displays messages routed to it by a CM1N network controller and from CM2N(D)s in the regenerative mode. No messages may be routed from an FCC network to a CM2ND. Multiple messages are buffered and prioritized, and must be individually acknowledged at the CM2ND.

  • Page 36: Specifications

    Specifications Specifications Standby Current: CM2ND 190 mA CM2ND-RM 220mA Data Line Formats, Class A or B RS-485, 9600 Baud, 5 VDC max, 30 mA max 20 mA Loop using SO-20 Fiber Optic Loop using SO-FIB Printer Port RS 232, 300-4800 Baud Max.
  • Page 37 COMM FOR OPTION PRINTER/ OPTION CARD SLOT CARD SLOT P5 PROGRAM PORT CONTROL PANEL SHLD FOR OPTION MOTHER BOARD CM1(N) or CM2(N) 2(-) CARD SLOT P5 & P6 2(+) CLASS A DATA SHLD FOR OPTION LINES OPTION CARD SLOT 1(-)

  • Page 38: Indicators

    INSIDE BACK COVER OF CM2ND [NWC-012.CDR] CM2ND, Rear View of DIP Switch Switches shown in program mode. All Switches off for normal Note: operation. Indicators LEDs Normal - Green LED indicates CM2ND is normal, i.e. no zone alarms, troubles or internal faults. Alarm - Red flashing LED indicates the Network has detected an alarm condition.

  • Page 39: Controls

    Controls Switches The Reset, alarm silence and trouble silence switches on the CM2ND are functional in both the network and stand alone mode. Reset - Resets CM2ND when in stand alone mode. Locally, CM2ND reset uses a supervisory short response on zone xx97. In the network mode, the CM2ND reset initiates a supervisory open on zone xx96 at the CM1N / FCC.
  • Page 40 Programming Notes When using a CM2ND, zones xx94, xx95, AND xx96 are used Note: by the CM2ND, and can not be assigned to addressable devices. Example: A CM2ND with start panel address 05 has two ZAS cards installed. Addresses 0594, 0595, 0596, 0694, 0695, 0696, 0794, 0795, 0796, 0894, 0895, and 0896 are not available for assignment to addressable devices.

  • Page 41: Troubleshooting

    Pins 6, 8, and 20 Pins 1, 4, and 6 Pins 4 and 5 Pins 7 and 8 CONTROL PANEL MOTHER BOARD CM1(N) or CM2(N) DB25 FEMALE or DB9 FEMALE Download Cable [NWC-004.CDR] TO PC SERIAL PORT CM2ND Programming Connections Troubleshooting The CM2ND displays trouble codes similar to the CM1N.

  • Page 42: Cpu-3/1N And Cpu-3/2N Control Module Cards

    CPU-3/1N and CPU-3/2N Control Module Cards Description The control module CPU cards contain the circuitry and memory necessary to support control module I/O and processing functions. REV_____________IC___________ CHECK SUM__________________ DATA BASE [NWC-014.CDR] CPU Card Application A CPU card is required in each control module to support all processing functions.

  • Page 43: Installation

    Installation Disconnect power before removing or installing module. Caution: The CPU card is installed in connector P4 of the control module mother board. Troubleshooting • The CPU failure LED is located on the associated power supply. Defective CPU’s may be identified by substitution with a known good CPU card.

  • Page 44: Comm-3 Communications Card

    COMM-3 Communications Card Description The COMM-3 communications card is a communication input/output port for the central processing units of the CM1(N), RMDP-1N, and CM2(N). The card provides an RS-485 port for network communications and an RS-232-C port for down loading program data into the network CPU’s memories, as well as for the connection of...

  • Page 45: Specifications

    Specifications Specifications Wiring Configuration Style 7 (Class A) or Style 4 (Class B) Communications Speed 9600 Baud, Max. Maximum Line Resistance Maximum Line Capacitance 0.44 Maximum # of Electrical Drops RS-232: Wiring Configuration Style 4 (Class B) Communications Speed 4800 Baud, Max. Installation Disconnect power before removing or installing module.

  • Page 46: Indicators

    2 is active. Red LED. LED flashing indicates CPU is communicating. Programming Notes The CM1(N), RMDP-1N panel configuration menu communications baud rate (under item “D” of the Master Configuration Menu) should be set at 9600 Baud. This is the default.

  • Page 47: Application Drawings

    The following diagram illustrates Style 7 (Class A) RS-485 network signal (data) line wiring between a CM1(N) and CM2(N) control modules. Both the CM1(N) and the CM2(N) must be equipped with a COMM-3 communications card in connector P3. Route data 1 and data 2 cables separately such that a single incident e.g.
  • Page 48 The following diagram illustrates Style 4 (Class B) RS-485 network signal (data) line wiring between a CM1(N) and CM2(N) control modules. Both the CM1(N) and the CM2(N) must be equipped with a COMM-3 communications card in connector P3. RS-232 CM1(N)

  • Page 49: Comm-3S Serial Communications Card

    COMM-3S Serial Communications Card Description The COMM-3S Serial Communications Card is a communication input/output port for the CM1(N) and CM2(N) central processing units. The card provides a general purpose serial port for network communications and an RS-232-C port for down loading program data into the network CPU’s as well as for the connection of external...

  • Page 50: Specifications

    Red LED. LED activity indicates CPU is communicating through the COMM-3S. Programming Notes The CM1(N),(RMDP-1N) panel configuration menu communications baud rate (under item “D” of the Master Configuration Menu) in the data entry program should be set at “9600” baud. This is the default.

  • Page 51: So-20 Serial Option To 20Ma Loop Module

    [NWC-019.CDR] SO-20 Module Application The SO-20 module connects to the CM1(N) w/SO Option, the RMDP- 1N w/SO Option, and the CM2(N) w/SO Option using a 10 conductor ribbon cable (P/N 250099) which terminates on the COMM-3S Serial Communications Card (P/N 130144). The COMM-3S card plugs into control module mother board communications slot P3.

  • Page 52: Specifications

    network with a 20 mA loop. When 20 mA loop communications is used to network these components, their RS-485 communications driver chip is removed from its socket. In its place, an 8 pin header and ribbon cable (P/N 250098) is inserted, and connected to the SO-20 at A maximum of ten (10) 20 mA devices may be installed on a loop.

  • Page 53: Indicators

    Selects P3 as I/O connector for use with ACP(6), IRC-1, MST, REM, SAN-CPU. As Required Selects P1/P2 as I/O connectors for use with CM1/2(N) and RMDP- Indicators LD-1 Red LED. Indicates local module transmitting data. LD-2 Red LED. Indicates local module receiving data.

  • Page 54: Theory Of Operation

    Theory Of Operation The 20 mA current loop format transfers information using changes in current flow rather than voltage levels to indicate logic states. Logic levels are represented by current flow, and absence of current flow. A loop circuit is formed between each pair of SO-20 modules. Three loop circuits are shown in the figure below, loops A/B, B/C and C/A.

  • Page 55: Application Drawings

    Application Drawings Style 4 (Class B) 20 mA Single Line Wiring with COMM-3S COMM-3S INSTALLED IN P3 OF: CM1(N) w/SO OPTION CM2(N) w/SO OPTION RMDP-1N w/SO OPTION RED STRIPE TO CORRESPONDING TERMINALS OF PS4/8B WITHIN SAME ENCLOSURE COM EARTH DATA DATA [NWC-019.CDR]...
  • Page 56 Style 7 (Class A) 20 mA Single Line Wiring with COMM-3S COMM-3S INSTALLED IN P3 OF: CM1(N) w/SO OPTION CM2(N) w/SO OPTION RMDP-1N w/SO OPTION RED STRIPE TO CORRESPONDING TERMINALS OF PS4/8B WITHIN SAME ENCLOSURE COM EARTH UCN 5800A MAXIM...
  • Page 57 TO CORRESPONDING TERMINALS OF PS4/8B WITHIN SAME ENCLOSURE COM EARTH UCN 5800A MAXIM 9111 DATA DATA UCN 5800A UCN 5800A UCN 5800A 9111 9111 9111 TO "DATA OUT" TO "DATA IN" TERMINALS RED STRIPE TERMINALS OF PREVIOUS OF NEXT SO-20. SO-20.
  • Page 58 Style 7 (Class A) 20mA Single Line Wiring , no COMM-3S TO CORRESPONDING TERMINALS OF PS4/8B WITHIN SAME ENCLOSURE COM EARTH UCN 5800A MAXIM 9111 DATA DATA UCN 5800A UCN 5800A UCN 5800A 9111 9111 9111 TO "DATA OUT" TO "DATA IN" TERMINALS RED STRIPE RED STRIPE...
  • Page 59 FONC 1 FONC 2 EARTH FONC 4 FONC 3 DATA IN DATA OUT [NWC-025.CDR] Supervised and power limited 10 modules max per circuit 9800 feet max between any FROM CM1(N)(X) three modules minimum wire size 26 AWG. Network Controllers Manual firealarmresources.com...

  • Page 60: So-20D Dual Serial Option To 20Ma Loop Module

    +24V [NWC-026.CDR] SO-20D Module The SO-20D module connects to the CM1(N) with SO Option, the RMDP-1N w/SO Option, and the CM2(N) w/SO Option using a 10 conductor ribbon cable (P/N 250099) which terminates on the COMM- 3S Serial Communications Card (P/N 130144). The COMM-3S card plugs into control module mother board communications slot P3.

  • Page 61: Installation

    Specifications Specifications Communications Each loop Half Duplex 9600 baud max. Input Voltage 24 VDC @ 150 mA Loop Maximums 9600 feet between any 3 modules. Ten modules max. per loop. Mounting 1/2 Standard Footprint Installation Disconnect power before removing or installing module. Caution: The SO-20D module may be mounted on the 1/2 footprint space immediately to the left of the CM mother board, or mounted on the...

  • Page 62: Indicators

    Field Wiring 1 and 2 DATA IN - Channel 2 20mA loop wiring from the previous device. Observe polarity. 1 and 2 DATA OUT - Channel 2 20mA loop wiring to the next device. Observe polarity. 1 and 2 DATA IN - Channel 1 20mA loop wiring from the previous device.

  • Page 63: Application Drawings

    Application Drawings Style 7 (Class A) 20mA Single Line Wiring with COMM-3S COMM-3S INSTALLED IN P3 OF: CM1(N) w/SO OPTION CM2(N) w/SO OPTION RMDP-1N w/SO OPTION RED STRIPE TO CHANNEL 1 "DATA OUT" TO CHANNEL 1 TERMINALS OF "DATA IN"...
  • Page 64 General Wiring of SO-20D to SO-FIB with FIB-20 COMM-3S SUPERVISED AND POWER LIMITED 10 MODULES MAX PER CIRCUIT 9800 FEET MAX BETWEEN ANY 3 MODULES MINIMUM WIRE SIZE 26 AWG RED STRIPE EARTH EARTH SO-20D WITH COMM-3S SO-20D WITH COMM-3S +24V +24V RED STRIPE...
  • Page 65 FIB-20 Serial Option 20mA Loop Card, SO-FIB Option Fiber Optics Interface Module Description The SO-FIB Serial Option to Fiber Optics Module connects network components via fiber optic cables. This supervised network communications link is capable of communications rates up to 9600 Baud, and may be installed in Class A (Style 7) [with two modules] or Class B (Style 4) configurations.
  • Page 66 SO-FIB w/FIB-20 Module Application SO-FIB When used as the head-end fiber optic interface with a CM1(N) or RMDP-1N, fiber optics ports FONC 1 (receiver) and FONC 4 (transmitter) must receive and transmit the signal. Fiber optic ports FONC 2 and FONC 3 are not used for head-end applications. SO-FIB cards located at network points other than the head-end of the fiber optic link are "wired"...
  • Page 67 Regenerative network capability is not compatible with COMM- Note: 3S card communication (20mA Loop and Fiber Optic Link) protocol. Specifications Specifications SO-FIB Fiber Optic Cable 62.5/125 or 100/140 Multimode Fiber Optic Cable Connectors Type ST Fiber Optic Budget 14dB Attenuation Less Connectors per Fiber Cable Maximum Modules per Loop Communication (2 fiber optic...
  • Page 68 SO-FIB When a single SO-FIB is used for Style 4 (Class B) operation the module may be mounted on the 1/2 footprint space immediately to the left of the CM mother board. If two modules are being used for Style 7 (Class A) communication, they must be mounted on the backplane mounting studs immediately below the CM motherboard.
  • Page 69 Board (P/N 150055) MST (P/N 150033) REM (P/N 150031) SAN CPU (P/N 150125) BUSY PREAMP AUXILARY AUXILARY TELEPHONE START EXTERNAL ACTIVITY RISER OUTPUTS INPUTS SUPV. RISER CH1 CH1 + IN - + 1 - + 2 - CH1 SHLD CH2 SHLD 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 BUZZER...
  • Page 70 HEADER REPLACEMENT FOR SERIAL FORMAT COMMUNICATIONS. RIBBON CABLE TO SO-FIB OR SO-20D RED STRIPE DETAIL A +PWR- +CH1- +CH2- COMPONENT SIDE LAMP TEST [NWC-033.CDR] FOR SERIAL FORMAT COMMUNICATIONS REPLACE U3 FOR STYLE 4 AND U3 & U4 FOR STYLE 7 WITH HEADER/RIBBON CABLE ASSEMBLY.
  • Page 71 Application Drawings Style 4 (Class B) Single Line Link with COMM-3S and FIB-20 COMM-3S INSTALLED IN P3 OF: CM2(N) w/SO OPTION TO 12 VDC BATTERY RED STRIPE TO SUPERVISORY ZONE TO 24 VDC SUPPLY 24V IN 12V BAT FONC 1 FONC 2 TO "FONC2"...
  • Page 72 Style 7 (Class A) Single Line Link with no COMM-3S INSTALL HEADER IN PLACE OF RS-485 CHIP (U8). TO 12 VDC BATTERY (CHANNEL 1) TO SUPERVISORY ZONE RED STRIPE TO 24 VDC SUPPLY FONC 1 24V IN 12V BAT FONC 2 TO "FONC2"...
  • Page 73 20 mA Sub-loop from SO-20 with SO-FIB Network Controllers Manual firealarmresources.com...
  • Page 74 Network Controllers Manual firealarmresources.com...
