Basic Printing - Canon S520 Quick Start Manual

Load Limit and Paper Thickness Lever Position Load Limit and Paper Thickness Lever Position
Load Limit and Paper Thickness Lever Position Load Limit and Paper Thickness Lever Position
Media Type Media Type Media Type Media Type
Plain paper
High Resolution Paper
Photo Paper Pro
Photo Paper Pro for Borderless
Printing (4X6)
Photo Paper Pro (4X6)
High Gloss Photo Film
Glossy Photo Paper
Glossy Photo Cards
Transparencies
#10 Envelopes
Banner Paper
T-Shirt Transfers
To load plain paper or other Canon media: To load plain paper or other Canon media: To load plain paper or other Canon media: To load plain paper or other Canon media:
1.
Make sure the paper thickness lever is set correctly
for the media used.
2.
Slide the paper guide completely to the left.
3.
Fan the edges of the sheets to remove static cling
and avoid paper jams, then tap the edges of the
stack against a flat surface so the stack is aligned.
4.
Insert the media into the paper rest, with the print
side facing up.
up to 100 sheets (17 lb.)
up to 80 sheets
1 sheet
up to 20 sheets
up to 20 sheets
1 sheet
1 sheet
up to 20 sheets
up to 30 sheets
up to 10 envelopes
1 sheet (print up to 6 sheets)
1 sheet
Some specialty media have specific sides for printing. The
print side is usually the brighter white or glossier side of the
page. When using specialty media, ensure that the brighter/
glossier side faces up and avoid touching the print side.
Paper Rest Paper Rest Paper Rest Paper Rest
Load Limit Load Limit Load Limit Load Limit

Basic Printing

Paper Thickness Paper Thickness Paper Thickness Paper Thickness
Lever Position Lever Position Lever Position Lever Position
Left
Left
Left
Left
Left
Left
Left
Left
Left
Right
Right
Right
Print side
Load limit mark
5
