Collamat 8600 Technical Handbook

Hide thumbs Also See for 8600:
Table of Contents

Advertisement

Quick Links

Collamat 8600
Technical handbook
HM Collamat AG
Bodenmattstrasse 34
CH-4153 Reinach
Switzerland
Phone +41 61 756 28 28
Fax +41 61 756 29 29
contact@collamat.ch
www.collamat.ch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Collamat 8600

Summary of Contents for Collamat 8600

  • Page 1 HM Collamat AG Bodenmattstrasse 34 CH-4153 Reinach Switzerland Phone +41 61 756 28 28 Fax +41 61 756 29 29 contact@collamat.ch www.collamat.ch Collamat 8600 Technical handbook...

  • Page 2: Table Of Contents

    3 The Collamat 8600 Labeller ........
  • Page 3 Index page 6.7.4 Terminals and connectors ............
  • Page 4 Index page 7.9 Goods scanners ..............

  • Page 5: Safety Advices

    8600 labeler is exclusively determinated for labelling goods. It must ex- clusively be controlled and driven by a monitor C8600. Collamat The installation of a 8600 has to be done by a trained specialist. For this you have to consider the national specific regulations of prevention of accidents mechanical stability...

  • Page 6: Symbol Descriptions

    1.3 Symbol descriptions ATTENTION Indicates danger of damaging the Collamat 8600 or other system components, with a potential consequential danger of injuries. DANGER Indicates an immediate hazard for persons. DANGER Shock hazard due to high voltage at component. DANGER Hazard due to high temperature component.

  • Page 7: Introduction

    This technical handbook describes the construction and the function of the Collamat 8600. In ad- dition to the operating instructions, it contains the necessary tips and adjustments to get optimum use of the Collamat 8600. The descriptions of each electrical or mechanical device also helps for quick error analysis and error elimination.

  • Page 8: The Firmware

    The 3-phase motordriver is a standard component of a leading motor and motordriver manu- facturer. The driver gives the power to the steppermotor. The step-rate may be adjusted from 200 up to 1000 steps per revolution. Standard in the Collamat 8600 are 500 steps per revolution.

  • Page 9: The Collamat 8600 Labeller

    These assemblies must be certificated by HM Collamat AG. 3.3 Mechanical stability If the Collamat 8600 is used on a movable stand, this stand must be capable to be tilt 10° in each direction. See also following figure 1: 10°...

  • Page 10: Assemblies

    4 Assemblies In the following description the assemblies of the Collamat, their adjustment and maintenance are described. First an overall view of the dispenser. The assembly parts are mounted and placed on a modular rail. Following figure 2 shows these...

  • Page 11: Mechanical Adjustments

    5 Mechanical adjustments 5.1 Traction unit 5.1.1 Threading the label web Figure 3 Thread the label web as shown in figure 3 up to the dispensing edge and draw it out by approx. 1 m. Detach the labels from the paperweb at the drawn-out web. Then open the pinchroller by turn- ing the knob 1, place the paperweb over the dispensing edge and finish threading the paperweb as shown in figure 3.

  • Page 12: Readjustment Of Paper Brake

    5.1.3 Readjustment of paper brake Figure 5 The braking force is factory-set to an optimum value. Should it, however, be unadjusted, readjust it with the M3-bolt 2 in the web-end controlbox of the traction unit, from the outside. Screw in bolt = higher braking force Unscrew bolt = lower braking force...

  • Page 13: Flap Adapter

    5.2 Flap adapter 5.2.1 Inclination adjustment of flap adapter Figure 7 The inclination of the flap adapter can be changed against the module rail: Unscrew nut 1 with two turns (refer to figure 7), with special hexagonal spanner (included as accessory). Push adapter in the direction indicated by the arrow 2, turn to desired setting at ring 3.

  • Page 14: Adjustment Of The Optival Label Scanner

    Pull the labelweb so that the gap is located below the marking 1 of the scanner. Switch on the Collamat 8600 monitor. Set the label scanner in the menue Labelscanner sens. -> Auto adjust by pressing the ENTER key. The monitor now automatically sets the scanner to the transparency of the backing paper.

  • Page 15: Adjustment Of The Mechanical Label Scanner

    5.2.4 Adjustment of the mechanical label scanner The mechanical label scanner (not used on magnetic flap adapter) is an alternative to the optical label scanner and is mainly used for transparent labels. 1 Scanner support 2 Scanning head 3 Nut 2 - 6 mm Figure 10 Adjustment:...

  • Page 16: The Monitor C8600

    10 seconds before opening the monitor. 6.1 Construction All the controller electronics for the Collamat 8600 labeler are built in to a stable steel cabinet. This cabinet contains no adjustable controls inside. All settings can be done by keyboard. After removing the two screws from the backpanel the cover can be separated from the heatsink.

  • Page 17: The Control Panel

    All settings and adjust- ments of the Collamat 8600 are programmed and handled in this unit. The settings and adjust- ments are stored in the control panel even if the power is turned off.

  • Page 18: Construction

    ESD while working with the control panel. If a control panel is defective, it must be exchanged. Any repairs not made by HM Collamat AG will expire the guarantee. The control panel builds together with the frontpanel one unit. This unit is connected with one 50 pole flatcable to the interfaceboard.

  • Page 19: Firmware Memory Ic6, Eprom 128 Kbytes

    Press the EPROM into the socket by a slight pressing with your finger until you feel it snaps in. The program memory IC6 is programmed with the firmware of the two Collamat 8600 and 9100. The firmware makes out the connected interfaceboard by a specific code of the board.

  • Page 20: The Backpanel

    3. Mains plug 6. Blind cover 9. Motor connector Only units approved by Collamat Stralforsare allowed to be connected to the mains socket 5. The following table shows the fuse current ratings and the maximum permissible current for the mains socket:...

  • Page 21: The Mains Filter Board

    6.6 The mains filter board The mains filter board is used to give a clean filtered mains voltage to the transformer. The board is mounted onto the backpanel and contains components on both sides. The mains filter board carries a high efficiency mains filter, the voltage selector, the mains con- nectors, the mains sockets for the transformer and the mains fuses.

  • Page 22: The Interfaceboard

    Attention: After exchanging the mains filter board, the voltage selector must be set to the correct mains voltage to which the Collamat will be connected. 6.7 The Interfaceboard The interfaceboard is used to connect the labeler and its peripheral units to the monitor. It filters and shapes all the signals of the labeler or of the installation to the logic level of the micro control- ler.

  • Page 23: Fuses

    The supply voltage for the logic and the sensors is connected to terminal X12. Fuse F2 protects this voltage against overload. LED LD2 indicates 24V. The voltage 12V and 5V are generated by the 24V using switching regulators. LED LD3 indicates 12V, LED LD4 indicates 5V. The 5V and 12V supply's are protected against short connection and overload.

  • Page 24: Exchange Of The Interfaceboard

    PC or a modem to this connector. Connector X7 gives isolated relais contacts. With these contacts external units like signal lamps or PLCs can be controlled. Also an isolated input allows to Start or Stop the Collamat by an exter- nal signal.

  • Page 25: The Motor Driver

    The motordriver board is adjusted, tested and built into the monitor by HM Collamat AG. The settings must not be changed. The motor current must not be changed ! ATTENTION: No switch or jumper must be touched while power on !

  • Page 26: Exchange Of The Motordriver

    The colors of the wires are writen on the board. This colors are only valid for peripheral units from HM Collamat AG. The connection cables of the sensors are fed to the inside of the traction unit with special clamps.

  • Page 27: Control Signals For External Units

    With this signal an external flat printing unit can be controlled. See therefore figure 20. 6.10.2 READY The signal READY is used to signal the Collamat that a connected peripheral device like hotstamp or flatprinter is ready. If the signal is active, this means the NPN-output of the device is pulled to GND, labelling is not possible.

  • Page 28: Signals And Connector Pin Assignments

    7 Signals and connector pin assignments This chapter describes the signals of the Collamat 8600. All in- and outputs are described func- tionally and electrically. Also the pin assignments are described. All in- and outputs are equipped with filterelements to prevent electromagnetic interference.

  • Page 29: Comparator Inputs

    The inputs are protected against wrong polarity and they are active while being pulled to GND (0V, ground). (The peripheral units of HM Collamat AG have NPN-outputs to 0V). Figure 22 shows the input diagram of the comparator inputs:...

  • Page 30: Goods Scanner Gsc3

    7.2.4 Control input STOP The STOP input is used to stop or start the Collamat. It has the same function like the RUN/STOP key on the control panel. If the signal is activated while the Collamat is stopped, the Collamat will be started (RUN) and vice versa.

  • Page 31: Lsc (Label Scanner)

    For the paperend sensor an alternative sensor may be used. 7.2.7 READY The signal READY is used to signal the Collamat that a connected peripheral device like hotstamp or flatprinter is ready. If the signal is active, this means the NPN-output of the device is pulled to GND, labelling is not possible.

  • Page 32: Open-Collector Outputs

    47n 100E Relais Umax: 250VAC Imax: 1A 47n 100E Umax.: 24VDC Imax: 25 mA Z39V SFH6156-3 Figure 24: Floating outputs The following outputs are floating: Relais output indicates RUN mode Relais output indicates a WARNING message ERROR Relais output indicates an ERROR message IFEED Photocoupler, isolated FEED-signal 7.3.2 Open-Collector outputs...

  • Page 33: Functional Description Of The Outputs

    7.4.1 Mode indicator RUN The RUN relais output indicates the RUN or Stop mode of the labeler. The output is activated while the Collamat is in the labelling mode. If the Collamat is stopped the relais output is not activated.

  • Page 34: Signal Feed, Ifeed

    The signal CLOCK can be used to synchronize an external device (e.g.. Ink-Jet or Thermal Trans- fer printer) with the steppermotor. 7.4.7 Control output NSTPO (NonSToP Out) The signal NSTPO is used to link two Collamat 8600 for the nonstop mode. The wiring diagram is shown in the chapter nonstop. Page 33 / 64...

  • Page 35: Connector Layouts Of The Monitor C8600

    7.5 Connector layouts of the monitor C8600 7.5.1 Connector X3, DISPENSER To this connector the controlcable to the traction unit is attached. The signals of this connector are used especially to control the dispenser and its units. D I S P E N S E R Name In/Out Name...

  • Page 36: Connector X7, Control Signals

    7.5.2 Connector X7, CONTROL SIGNALS On the CONTROL SIGNALS connector the upper row is used to access three relais contacts for signalisation purpose. The lower row supplies a 24V voltage for external signal lamps. The maxi- mum current for the 24V is 200 mA. CONTROL SIGNALS PHOENIX CONTACT MDSTB 2,5/9-G1-5,08 Name...

  • Page 37: Connector Layouts Traction Unit C8600

    7.6 Connector layouts traction unit C8600 7.6.1 Connector X101, X102 BUS The connectors X101 and X102 are used for the connection of the buscable to the peripheral units on the modular rail. The buscable must be located inside the rail to prevent RMI. X102 X101 Figure 27...

  • Page 38: Connection Diagram

    7.7 Connection diagram P1/P2 +12V GSC1 GSC2 +12V GSC2 GSC1 +12V +12V Figure 28 Page 37 / 64 5999.545-01G 13.06.2007 WM...

  • Page 39: How To Connect A Goods Scanner

    7.8 How to connect a goods scanner The goods scanners and incremental encoders are connected to the GSC1 and GSC2 connec- tors. Figure 29 shows the connection of the standard HM Collamat AG IR goods scanner: brn/bn G N D...

  • Page 40: Goods Scanners

    7.9 Goods scanners 7.9.1 Speed measuring CS IR goods scanner LEDs Figure 32 7.9.2 NPN Reflexscanner, Lightbeam scanner +12V GSC2 GOODSCANNER G N D Figure 33 7.10 Optical label scanner +12V (LABELSCANNER) G N D +12V TCY (TRANSPARENCY) Figure 34 Page 39 / 64 5999.545-01G 13.06.2007 WM...

  • Page 41: Signalcable Connection

    7.11 Signalcable connection MONITOR-CABLE MOTOR-CABLE Screen Schirm X103 Figure 37: Connection of the signalcable Page 40 / 64 5999.545-01G 13.06.2007 WM...

  • Page 42: Adapter With Magnet

    7.12 Adapter with magnet GS070C TIME 14 Pol 3,14AT FLATCABLE RIGHT LEFT +12 V M A G N E T +12V Ph N GS070D DELAY 14 Pol 3,14AT FLATCABLE RIGHT LEFT +12 V M A G N E T +12V Ph N Figure 39 The mains voltage must be connected inside of the flap printer or inside of the dispenser.

  • Page 43: Flatprinter Board

    7.13 Flatprinter board rot / red rot, schwarz red, black schwarz / black braun / brown weiss / white Farbbandmotor Ribbonmotor Collamat Buskabel 14 polig Collamat Buscable 14 poles Figure 39 Page 42 / 64 5999.545-01G 13.06.2007 WM...

  • Page 44: Nonstop Labelling

    8 Nonstop labelling When using two Collamat 8600 it is possible to label goods with no down time. For this purpose the two monitors must be connected together by an electrical link. The necessary links are shown in figure 40. The placement of the two Collamat to each other is shown in figure 41.

  • Page 45: Setting Up Of The Nonstop Mode

    The master starts immediately to label the goods. At this mo- ment both Collamat are labelling for a while. When the first labeled good arrives at the GSC2 of the slave, the slave stops labelling. Now the cause of the stop of the slave can be serviced.

  • Page 46: Speed Measuring

    9 Speed measuring 9.1 Incremental encoder The electrical connection of an incremental encoder is described in the chapter 'Connection of the goods scanners'. Now the mechanical attachment of the conveyor to the encoder will be de- scribed. If the speedmeasuring is done by an incremental encoder, on the control panel the step width must be programmed so that the speed measuring is made correctly.

  • Page 47: Measuring Goods Scanner

    9.2 Measuring goods scanner The electrical connection of the measuring goods scanner is described in the chapter 'Connection of the goods scanners'. If the speedmeasuring is done by a measuring goods scanner, on the control panel the distance L must be programmed so that the speedmeasuring is made correctly. Figure 43 shows the placement of the scanners: CS: L = 14 mm GSC1...

  • Page 48: Motor And Motorcable

    10 Motor and motorcable Attention: The motor never must be dismantled ! For safety reasons and in order to guarantee interference suppression, the motor has to be connected to a ground conductor ! Steppermotors heat up during operation ! When connecting or disconnecting the motor, the monitor must be switched off ! When working on the motor, the monitor must be disconnected from mains ! 10.1 Motorcable...

  • Page 49: Control Of External Devices

    11 Control of external devices 11.1 Control of a Hotstamp with the IFEED signal The connection of a hotstamp printer to the IFEED signal is described below. On the CONTROL SIGNALS connector the IFEED signal can be used. It can be connected for two different types (NPN or PNP) of hotstamp inputs.

  • Page 50: Monitortest With A Diagnostic Connector

    12 Monitortest with a diagnostic connector In the firmware of the Collamat 8600 there is a selftest function for the monitor electronics. This test only may be successful with a diagnostic connector attached to the three connectors on the back plane of the monitor.

  • Page 51: Cabling

    Do the winder turn the right way ? Turn off the monitor and unplug it from mains Connect the remaining units to the connector box of the Collamat Connect the monitor to the mains voltage and turn it on Do the peripheral units work OK ?

  • Page 52: Password

    Password #### Discontinue: [ESC] Now type in 4148. The Collamat will clear now the password to 0000. The data of program num- ber 32 will be set to default values and it will start up with program 32. Note: This function is available since firmware 1.20.

  • Page 53: Fuses

    Liquid Crystal Display Light Emitting Diode not connected RS232 Standard serial data exchange protocol 16.2 Signals ERROR Errorsignal caused by any error of the Collamat FEED Signal indicating the labelling process GrouND Goods SCanner IFEED Isolated FEED signal Label LOw signal indicating the end of the label stock...

  • Page 54: Terms

    Rewinder: Device that takes the empty paperweb from the traction unit and rewinds it CE-Mark: Certification for the European market, means: Conformité Européenne Collamat: Brand name for a labeler built by HM Collamat AG C8600: Labeler type C8600 GSC: Goods SCanner...

  • Page 55: Technical Data

    17 Technical data Dispenser general data (standard values) System Units C8610 C8620 Version right/left Dispensing speed Incremental Encoder m/min 0-50 0-50 Measuring Scanner 0.5-50 0.5-50 Fixed Speed 3.0-50 3.0-50 Min. label width Max. width of the paperweb Min. label length Min.
  • Page 56 Midi-unwinder Diameter of the roll core 42 mm Max. outside diameter of roll 350 mm Max. weight of roll 10 kg Spring dancer with automatic brake Flap adapter System C8610 C8620 Max. width of paperweb 95 mm 160 mm Weight 1.9 kg 2.2 kg Version...
  • Page 57 Monitor System C8600 Mains voltage 110/120V AC, 220/230/240V AC, ±10% Power consumption 310 VA Main fuse 120V : 8AT, 230V : 4AT Display LCD, 4 lines, 20 characters each Dimensions (LWH in mm) 375 * 305 * 155 mm Ambient temperature +5-40°C Max.

  • Page 58: Dimensions - Systemdesign

    17.1 Dimensions - systemdesign min. 225 max. 375 Ø 40 A) Abwickler A) Unwinder B) Vorzugwerk B) Traction unit C) Klappenadapter C) Flap adapter D) Für Deckelmontage D) For lid dismantling Page 57 / 64 5999.545-01G 13.06.2007 WM...
  • Page 59 Monitor Für Deckelmontage For lid dismantling Ø 30 ca. 190 Page 58 / 64 5999.545-01G 13.06.2007 WM...

  • Page 60: Troubleshooting

    18 Troubleshooting 18.1 Troubleshooting Collamat 8600 The troubleshooting will proceed along the paperpath. See following figure: C O L L A M A T ENTER G U H L & S C H E I B L E R T I C K E T S U N D E T I K E T T I E R - S Y S T E M E Unit 1.
  • Page 61 1. Unwinder troubleshooting SYMPTOM DIAGNOSIS ACTION Paperweb falls off in side label- Missing side labeling kit Mount the side labeling kit to ing applications the Collamat 2. Adapter troubleshooting SYMPTOM DIAGNOSIS ACTION Labels run through Roll-up cable is broken Replace roll-up cable...
  • Page 62 2. Adapter troubleshooting SYMPTOM DIAGNOSIS ACTION Paperweb breaks behind the Paperbrake set too hard Reduce the braking force peeling bar Peeling bar is too sharp Use peeling bar with a bigger radius Add Teflon tape around the peeling bar Peeling bar touches the goods Lift the labeler/adapter away from the goods Paperweb is perforated...
  • Page 63 Handbook Motor turning direction is wrong Wrong motor cable wiring Reconnect motor cable ac- cording to the Technical Handbook Collamat labels only at 3m/min Monitor speed setting is set to Change the setting to meet default FIXED SPEED the requirements Motor makes noise and shakes.
  • Page 64 5. Monitor troubleshooting SYMPTOM DIAGNOSIS ACTION No action after power on but Missing good scanner signal Try LABEL JOG in the LA- motor is under power BELING MODE menu Monitor stopped Set it to RUN Monitor set to NONSTOP Set it to the according mode SLAVE The mains fuse often blows The mains impedance is too low Use an extended power cord...

  • Page 65: Trouble Shooting Checklist

    18.2 Trouble shooting checklist Ser.No. Monitor: Ser.No. Labeler: Machine-Type: Ser.No Control panel: Software-Version: Ser.No. Motordriver: Ser.No. Interfaceboard: Mains voltage: Frequency Hz: Temperature °C: Environment Interference level Interference level ESD Humidity % (Static): (Burst) Width: Length: Gap: Labels Thickness: Transparency: Material: Width: Thickness: Transparency:...
