Summary of Contents for Artusi ECT600C4
- Page 1 USAGE AND CARE GUIDE PRODUCT CODE: ECT600C4...
-
Page 2: Product Overview
Congratulations on the purchase of your new Ceramic Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. -
Page 3: Product Information
Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker hob centers on customers and adpots personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. -
Page 4: Using Your Ceramic Hob
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Using your Ceramic Hob To start cooking •... -
Page 5: When You Have Finished Cooking
3. Select a heat setting by touching the control. • If you don’t choose a heat setting within 1 minute, the ceramic hob will automatically switch off. You will need to start again at step 1. • You can modify the heat setting at any time during cooking. -
Page 6: Locking The Controls
Locking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls Touch the keylock control. -
Page 7: Using The Timer As A Minute Minder
Using the Timer You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. • You can set it to turn one cooking zone off after the set time is up. •... -
Page 8: Setting The Timer To Turn One Cooking Zone Off
5. When the time is set, it will begin to count down immediately. The display w ill show the remaining time and the timer indicator will flash for 5 seconds. 6. Buzzer will bips for 30 seconds and the timer indicator shows “- - “... -
Page 9: Cooking Guidelines
3.Touching the together, the timer is cancelled, and it shows ” --” in the minute display. 4. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. -
Page 10: For Stir-Frying
• Using a lid will reduce cooking times and save energy by retaining the heat. • Minimise the amount of liquid or fat to reduce cooking times. • Start cooking on a high setting and reduce the setting when the food has heated through. -
Page 11: Heat Setting
Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the cooktop to find the settings that best suit you. Heat setting Suitability •... -
Page 12: Hints And Tips
Boilovers, melts, and Remove these immediately with • Remove stains left by melts and hot sugary spills on a fish slice, palette knife or razor sugary food or spillovers as soon the glass blade scraper suitable for as possible. If left to cool on the ceramic glass cooktops, but glass, they may be difficult to beware of hot cooking zone... -
Page 13: Technical Specification
This is normal for cookware and crackling or clicking construction of your cookware does not indicate a fault. noises. (layers of different metals vibrating differently). Technical Specification Cooking Hob ECT600C4 Cooking Zones 4 zones Supply Voltage 220-240V~ Installed Electric Power 5500-6600W Product Size L×W×H(mm) 590X520X55 Building-in Dimensions A×B (mm) -
Page 14: Before Locating The Fixing Brackets
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) 50 mini Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 6 0 mm. -
Page 15: Connecting The Hob To The Mains Power Supply
screw bracket Screw hole base Adjust the bracket position to suit for different work surface’s thickness. TABLE TABLE BRACKET BRACKET Cautions 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. -
Page 16: Safety Warnings
Yellow / Green Black Brown Blue If the total number of heating unit of the appliance you choose is not less than 4, the appliance can be connected directly to the mains by single-phase electric connection, as shown below. Yellow / Green Black Brown... -
Page 17: Important Safety Instructions
Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying • out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. • Alterations to the domestic wiring system must only be made by a qualified electrician. •... -
Page 18: Cut Hazard
until the surface is cool. • Never leave metal objects (such as kitchen utensils) or empty pans on the cooktop as they can become hot very quickly. • Beware: magnetisable metal objects worn on the body may become hot in the vicinity of the cooktop. - Page 19 -CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. -WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in a fire. This appliance is labeled in compliance with European directive 20 2/ for Waste Electrical and Electronic Equipment (WEEE).
