FrSky Scout VS600 Series Instruction Manual

Instruction Manual for FrSky Scout VS600 Series

Introduction

Thank you for purchasing the FrSky video transmission device. A simple and clean design, equipped with a
switchable power output and operating band and channel. Paired with a FrSky radio transmitter, the parameters can
be adjusted conveniently through the gTrans.lua script. In addition Scout VS600 BLACK/VS600 RED has a built-in
microphone which transmits audio. To fully enjoy all the features of this device please thoroughly read the
instructions below to set up the device.

Overview

23.55 mm
Scout VS600 RED
15.5 mm
GND
VTX
+5V
Inverted S.Port
S.Port
Button
Scout VS600 Mini
FrSky Electronic Co., Ltd. www.frsky-rc.com
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
24 mm
13 mm
GREEN
RED
BLUE
Scout VS600 BLACK
GREEN
RED
BLUE
Contact us: frsky@frsky-rc.com
01140107
Version
1.0

Specifications

Model Name
Scout VS600 RED
Scout VS600 Black
Scout VS600 Mini
• Transmission Frequency: 5.8 GHz
Transmission Power: ＜0.01mW (pit mode) /25mW
•

Features

• Support S.Port
• Support inverted S.Port
• Built-in microphone（Scout VS600 Red & Black）
• Adjustable RF power
• Support set parameters by gTrans.lua /Button /FreeLink(PC)/FreeLink App.

Transmission Frequency

CH
CH1
FR（MHz）
5865
A
5733
B
C
D
5740
E
F

LED State

LED
Indication
Flash 1 time
Flash 2 times
Flash 3 times
Flash 4 times
Flash 5 times
Flash 6 times
Flash 7 times
Flash 8 times
The Scout VS600 Series has a green LED/red LED/blue LED which indicates the RF power/frequency band/chan-
nel. As you press the button key, the LED will flash, indicating the corresponding RF power level/frequency
band/channel.

Configuration method

1. Manual configuration（by the Button）
Press the button for (3s) to enter the power/channel/frequency selection mode, press the button for (3s) again
to switch between power/channel/frequency.
FrSky Electronic Co., Ltd.
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
Instruction Manual for FrSky Scout VS600 Series
L*W*H(mm) Weight(g) Available Channel
31.5*23.6*4.5 4.2 26CH
31*24*4.9 4 26CH
15.5*13.5*4 1.2 26CH
CH2 CH3 CH4 CH5
5845 5825 5805 5785
5752 5771 5790 5809
5760 5780 5800 5820
5732 5769 5806
Green Red
Power Band
Pit Mode A
25mW B
/ C
/ D
/ E
/ F
/ /
/ /
www.frsky-rc.com Contact us: frsky@frsky-rc.com
01140107
Version
1.0
Operating Voltage
2-6S
2-6S
5V
CH6 CH7 CH8
5765 5745
5828 5847 5866
5840 5860
5843
Blue
Channel
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
