Instructions for use, installation,

and connection

Glass-ceramic built-in coking hob

Table of Contents

Need help?

Do you have a question about the ECT680KRB and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorenje ECT680KRB

Page 1 Instructions for use, installation, and connection Glass-ceramic built-in coking hob...
Page 2: Table Of Contents
Glass-ceramic built-in cooking hob Dear customer! Glass-ceramic hob is intended for use in households. Our products are packed in environment-friendly materials which can be recycled, disposed of, or destroyed without imposing any burden on the environment. Instructions for use Instructions for use are intended for the user. They describe the appliance and its operation.
Page 3: Important - Read Before Using The Appliance
Important - Read before using the appliance Safety percautions • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4 • If another electrical appliance is connected to a AC power socket near the appliance, make sure the power cord does not come into contact with hot cooking zones. • Do not store temperature-sensitive items underneath the appliance, such as cleaners or detergents, spray cans etc.
Page 5: Appliance Description
Appliance description 1. Cooking zone rear left 2. Cooking zone front left 3. Cooking hob control unit 4. Cooking zone front right 5. Cooking zone rear right Cooking hob control elements (depending on the model) Control sensor keys: F Power level / residual heat displays A Coking hob on/off sensor F1 Active function decimal point B Child lock sensor...
Page 6: Cooking Zones
Cooking zones Before using the Clean the glass-ceramic surface with a damp cloth and appliance for the ﬁ rst some manual dishwashing detergent. Do not use aggressive time detergents such as abrasive cleaners that can scratch the surface, abrasive dishwashing sponges, or stain removers. Important warnings •...
Page 7 Cookware Tips on using the cookware Use high-quality cookware with a ﬂ at and stable bottom. • Transmission of heat is best when the pan bottom and the cooking zone are of the same diameter, and the pan is placed on the middle of the cooking zone.
Page 8: Operating The Cooking Zones
Operating the cooking zones • The cooking hob is ﬁ tted with electronic sensor keys which are activated, respectively, when the indicated surface of a particular sensor is touched with a ﬁ nger for at least one second. • Activation of a sensor key is conﬁ rmed by a beep. •...
Page 9 Turning off the cooking • Select the cooking zone by pressing the relevant sensor key zones (H). The decimal point (F1) next to the display for the selected cooking zone will light up. • Press the “–” (I) sensor key to set the power level to “0”. •...
Page 10 cases (power failure, a hot pan left on the cooking zone) still be hot. Be careful, as there is a risk of burning. If a power failure has occurred when the cooking zones were hot, the indicator “H” or “h” will ﬂ ash. This is to warn you that the cooking zone may still be hot, but not necessarily, depending on how long the power supply was out of order.
Page 11 Dish/cooking mode quantity power level cooking duration (min) Soup/reheating 0,5 – 1 lit A7 - 8 4 - 7 milk/reheating 0,2 – 0,4 lit A1 - 2 4 - 7 125 – 250 g rice/simmering approx. 300ml - 600ml A2 - 3 20 - 25 water 750g –...
Page 12 Power level Maximum operation time in hours Temporary cooking The STOP & GO function enables you to temporarily suspend, or progress suspension pause the cooking progress (urgent other tasks), while keeping - STOP & GO all the settings. (depending on the model) Engaging the STOP &...
Page 13 B Timer with the option to turn off the cooking zone The switch-off timer facilitates the cooking process by allowing you to set the cooking time for a particular cooking zone. In order to set the switch-off timer, the power level must already have been set (see section “Turning on the cooking zones”).
Page 14 Special warnings and • If all power levels are set to “00”, the cooking hob will be fault reports turned off automatically after 10 seconds. • If any of the keys is activated for more than 10 seconds, the cooking hob will be turned off, an alarm will sound, and the symbol “F”...
Page 15: Cleaning And Maintenance
Cleaning and maintenance Cleaning After each use of the glass-ceramic hob, wait for it to cool down and clean it; otherwise, even the smallest food residue will be burnt onto the hot surface next time you use the appliance. For regular cleaning and maintenance of the glass-ceramic surface, use special conditioning agents which form a protective layer on the surface, shielding it from dirt.
Page 16: Installation
Sugar and sugar-laden food may permanently damage the glass- ceramic surface (Figure 5); therefore, they should be removed from the glass-ceramic surface as soon as possible, although the cooking zone may still be hot (Figure 4). Any change in the color of the glass-ceramic surface does not affect its operation or the stability of the surface.
Page 17 Installing the foam Before inserting the appliance into the opening in the kitchen gasket worktop, the supplied foam gasket must be attached to the lower side of the glass ceramic (glass) cooking hob (see ﬁ gure above). Do not install the appliance without the foam gasket! The gasket should be attached to the appliance in the following way: - Remove the protective ﬁ...
Page 18: Connecting The Appliance To The Power Mains
objects should be placed into that gap. • On the furniture back wall there should be a cutout with width of at least 175 mm along the entire width of the furniture element. • Only type EVP4..,EVP2.., ovens ﬁ tted with a cooling fan may be installed underneath this cooking hob.
Page 19 ATTENTION! • Before any manipulation with the appliance (other than its regular use), disconnect it from the power mains. The appliance should be connected according to the relevant scheme (diagram), subject to the network voltage. Connect the earth (PE) wire to the clip indicated with the earth /ground symbol.
Page 20: Technical Characteristics
Technical characteristics Rating plate A Serial number B Code C Model D Type E Trademark F Technical information G Compliance indications / symbols WE RESERVE THE RIGHT TO MAKE ANY CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. SVK67,73,82CS_KARIM RASHID en (08-17)

This manual is also suitable for:

Ect680kr
