- Page 1 Floor Burnisher PE225BU Operator’s Manual...
- Page 2 FOR YOUR SAFETY DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Record This Important Information Date of Purchase Purchased From Address City State Phone Contact Machine Model Machine Serial Number Important Phone Numbers Medical Emergency...
-
Page 3: Table Of Contents
Table of Contents Safety Precautions..............4 How to Operate the Machine..........10 Technical Specifications............5 Installing / Replacing a Pad.........10 Operator Responsibility............6 Operation..........10 Machine Preparation............6 After Use...............10 Unpacking the Machine..........6 Scheduled Maintenance...........11 Transporting the Machine........6 Machine Troubleshooting..........11 Grounding Instructions..........7 Parts Manual & Warranty...........12 Extension Cords.............7 Electrical Schematic..........13 Machine Components............8... -
Page 4: Safety Precautions
DO NOT use the machine DO NOT make unauthorized modifications or alterations if it is not in proper operating condition, and report to this machine. Amano Pioneer Eclipse assumes any damage or operation faults immediately. no liabilities for injury or damage resulting from an unauthorized modification or alteration to the machine. -
Page 5: Technical Specifications
Technical Specifications: Description 225BU20 225BU20E 225BU20EB Voltage (V) Frequency (Hz) Current (A) Pad / Brush Speed 1500 rpm 1500 rpm 1500 rpm Power 1.5 hp (1.1 kW) 1.5 hp (1.1kW) 1.5 hp (1.1kW) Pad Size 20” (51 cm) 20” (51 cm) 20”... -
Page 6: Operator Responsibility
Commercial use only. Figure 1 This machine is designed and manufactured for indoor use on hard floor surfaces. Amano Pioneer Eclipse Corporation (APEC) does not recommend use of this machine in any environment other than an indoor environment. This floor machine is designed and manufactured for commercial floor use only. -
Page 7: Grounding Instructions
Grounding Instructions WARNING: To prevent possible electric shock, protect the machine from rain. Keep the machine in a dry building. 120 Volt Machines WARNING: To prevent possible electric shock, always This product must be grounded while in use to protect use a 3-wire electrical system connected to the electrical the operator from electrical shock. -
Page 8: Machine Components
Machine Components Operator Handle Grips Switch Lever Switch Levers Safety Lock Cord Hook Handle Release Lever Power Cord... -
Page 9: How To Operate The Machine
How to Operate the Machine Operator Handle Grips Use the operator handle grips to operate and move Installing the Pad the machine. The switch levers on the underside of CAUTION! Using the wrong pad on this machine the handle grips, turn the motor on and off. Locate the can overload the motor. -
Page 10: Operation
Operation After Use 1. Place the operators handle (4) in the upright (vertical) 1. Unwrap the power cord and plug it into the properly position and unplug the power cord. Wrap the power grounded outlet. cord around the operator hand grips (1) and the cord 2. -
Page 11: Scheduled Maintenance
Check machine wiring for fray or cut Check the carbon brushes of motor These items must be performed with the proper tools and training. Contact an Amano Pioneer Eclipse Factory Certified Technician unless you have the proper equipment and technical proficiency. -
Page 12: Parts Manual & Warranty
PE225BU Floor Burnisher Parts Manual Notes: ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________... -
Page 13: Electrical Schematic
Electrical Schematic - 120V Electrical Schematic - 127V & 230V ADD THIS PAGE TO PAGE 13 WITH EXISITNG WIRING SCHEMATIC THIS ONE IS FOR 127V AND 230V 225BU20EB AND 225BU20E MODELS... -
Page 14: Main Assembly
Main Assembly RF065200 093021... - Page 15 Main Assembly (continued) Item Ref. No. Description Item Ref. No. Description 39857A WHEEL 5 POLISHER SPACER, PIVOT, NYLON,1” OD X MP503700 .38” ID X .315 L MP236800 KEY, 3/16 X 1 7/8 MP503000 BRACKET, WHEEL, WELDMENT 56109699 CAM ASSY WITH GRIP BRACKET, ADJUSTMENT, BELT, 920342 NUT ESNA 3/8-16...
- Page 16 Main Assembly - 2000 RPM MODEL (225BU202) RF071300 092121...
- Page 17 Main Assembly - 2000 RPM MODEL (225BU202) Parts List ITEM PART NUMBER DESCRIPTION 39857A WHEEL 5 POLISHER MP236800 KEY, 3/16 X 1 7/8 56109699 CAM ASSY WITH GRIP 920342 NUT LK 3/8 -16 REG AS087800 WASHER WEAR CAM NB3265 NUT, LOCK, 5/16"-18, NC NB6110 WASHER, LOCK, 1/4"...
-
Page 18: Handle Assembly
Handle Assembly RF065300 11/29/16... - Page 19 Handle Assembly (continued) Item Ref. No. Description Item Ref. No. Description 61373A HANDLE TUBE MP476300_A CORD, POWER, 14/3 , YELLOW 40789A CORD INTERCONNECT 80284A SCREW, 10-32 UNF X .75 21075A HANDLE, REAR - CFP MP504400 DECAL, HANDLE, 225BU MP504200 HOUSING, BEARING, SPINDLE, 50781A CLAMP HANDLE C2K FRONT...
- Page 20 Handle Assembly - 225BU20E RF071600 060917...
- Page 21 Handle Assembly - 225BU20E Parts List ITEM PART NUMBER DESCRIPTION 80290A SCREW, 10-32 UNF X .375 AS018000 CORD, INTERCONNECT, EXPORT 50781A CLAMP HANDLE C2K HANDLE TUBE 61373A 21075A HANDLE, REAR - CFP 21074A HANDLE, FRONT - CFP 10687A INTERLOCK ASM. 80284A SCREW, 10-32 UNF X .75 980603...
- Page 22 Handle Assembly - 225BU20EB RF066700 11/30/16...
- Page 23 Handle Assembly - 225BU20EB Item Ref. No. Description 50780A HANDLE, REAR, C2K 30285A HANDLE FRONT C2K W/BLANK 50798A LEVER, SWITCH, C2K 50806A BUTTON, INTERLOCK, C2K 50799A INTERLOCK, MAIN, C2K 40109A SWITCH, MINIATURE-SPNO, C2K 50821A SPRING, COMPRESSION, C2K 50820A SPRING, EXTENSION, C2K 85383A SCREW 10-32 X 3/4 PAN HD 920722...
- Page 24 Department at 1-800-367-3550 or 1-336-372-8080. If you are (2) The machine must have been purchased from Amano Pioneer dissatisfied with the service that you receive, call or email Amano Eclipse Corporation or an authorized Amano Pioneer Eclipse Pioneer Eclipse Corporation Customer Service Department at Corporation Distributor.
- Page 26 Amano Pioneer Eclipse Corporation 1 Eclipse Rd l PO Box 909 Sparta, North Carolina 28675 l USA www.pioneereclipse.com +1-336-372-8080 1-800-367-3550 Fax +1-336-372-2913 LT075600 225BU_F © 2021 Amano Pioneer Eclipse Corporation 101921...
