O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. To make assembly easier, use the Hardware Identifier on page 7 to identify and sort all
fasteners. Check all cartons for kits. All hardware may not be located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together. Leave locknuts slightly loose until you are instructed to
tighten them.
5. Tools required for assembly: Phillips Screwdriver, 3/8 Wrench, and Two 7/16 Wrenches (adjustable
wrenches may be substituted for the wrenches).
Please Do Not Return This Product To The Store!
Contact Escalade
Phone:
1-866-873-3528
Fax:
1-866-873-3533
E-mail:
tabletennis@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
®
Sports customer service department at:
®
SPORTS PRODUCT INFORMATION
Toll – Free !
Toll – Free !
www.escaladesports.com
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
TABLE TENNIS TABLE
MODEL NO.
T8721 (ST2000)
2010 Escalade Sports
2L-5039-03(T)

Advertisement

loading
Need help?

Need help?

Do you have a question about the T8721 and is the answer not in the manual?

Questions and answers

Related Manuals for Stiga T8721

Summary of Contents for Stiga T8721

  • Page 1 TABLE TENNIS TABLE MODEL NO. T8721 (ST2000) O W N E R ' S M A N U A L 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts.
  • Page 2 For aid in identifying hardware, see hardware identifier on page 7. Figure 1 U-support 1. Lay table top #1 painted side down, on a smooth, flat surface. Use the shipping container to protect the painted surface of the table top. Plastic 2.
  • Page 3 This end is the middle of the table Figure 3 Lay out rails #25 and 26, as shown in Figure 3, around edges of table top. Line up holes in rails with pilot holes in top and secure using eighteen screws #20. See Figure 3. Lay Corner Caps #22 on table as shown in Figure 4.
  • Page 4 Figure 6 10. Attach end of linkages #4 with two holes to INSIDE of U-leg #2 as shown in Figure 6. Secure through end hole with screws #23, locknuts #15 and plastic spacers #31. Tighten hardware snug enough to keep table stable but do not overtighten.
  • Page 5 18. Repeat steps 1 through 12 on second table half. Figure 9 19. Gently tap caster sockets #12 into U-support #7 on second table DO NOT half until flange on sockets touches the edge of the tube. HIT CASTER SOCKET DIRECTLY WITH A HAMMER! SET A PIECE OF WOOD ON CASTER SOCKET AND HIT PIECE OF WOOD TO DRIVE CASTER SOCKET INTO U-SUPPORT.
  • Page 6 Figure 11 INSTALL SAFETY LATCHES #8 AS SHOWN ABOVE FOR PROPER USE OF CAUTION: TABLE! DO NOT SKIP THIS STEP! DO NOT OPERATE TABLE UNTIL SAFETY LATCHES ARE INSTALLED AND ASSEMBLY IS COMPLETE! 25. Choose a name panel #5 on either side of the table and install one safety latch #8 into the right-hand hole on that name panel as shown in Figures 11 &...
  • Page 7 OPENING AND CLOSING INSTRUCTIONS READ OPERATING INSTRUCTIONS CAREFULLY BEFORE OPERATING TABLE! DO NOT ALLOW CHILDREN TO OPEN TABLE! DO NOT CLIMB, STAND OR JUMP ON TABLE! SERIOUS OR FATAL INJURY MAY RESULT! THIS IS NOT A TOY! CAUTION: TABLE IS TO BE OPENED OR CLOSED BY ADULTS ONLY! FAILURE TO COMPLY WITH OPENING AND CLOSING INSTRUCTIONS COULD RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE.

  • Page 8: 90-Day Limited Warranty

    90 DAY LIMITED WARRANTY ® This consumer warranty extends to the original consumer purchase of any ESCALADE SPORTS Product (hereinafter referred as the "Product"). WARRANTY DURATION: This Product is warranted to the original consumer purchase of a period of ninety (90) days from the original purchase.
  • Page 9 PRODUCT PARTS LIST T8721 Key # Part# Description Qty. Table Top 4A-5468-01 8S-6640-00 U-Leg - 1 1/4" Diameter 2S-6880-01 1 1/4" U-Clip 8S-6758-00 Linkage 2S-6422-26 Name Panel Safety Strap 2S-6428-01 8S-6606-00 U-Support Safety Latch 2S-6264-02 WB-1094-00 1/4-20 x 1 ½ Hex Head Bolt 1B-4049-01 #10-24 x 3/4 Phillips Round Hd.

  • Page 10: M A N U A L D E L U S A R I O

    MESA DE TENIS NÚMERO DE MODELÓ T8721 (ST2000) M A N U A L D E L U S A R I O 1. Lea este manual cuidadosamente antes de empezar a ensamblar. Lea completamente cada uno de los pasos antes de empezar cada paso.
  • Page 11 Para identificar los tornillos etc. Vea la lista de las partes en la página 7. Figura 1 Tablero Soporte en U Coloque el tablero #1 sobre una superficie plana y lisa con el lado pintado hacia abajo. Use la caja en donde venia la mesa para proteger la pintura de la superficie de la mesa.
  • Page 12 Todos los tornillos mostrados son los (#20) Tornillos para Este extremo es lamina de metal es el centro de la mesa (Riel de 48” (Riel de 48” Figura 3 (Riel de 53” Coloque los rieles #25 y #26, alrededor de los bordes del tablero, como están mostrados en la figura 3.
  • Page 13 Una los extremos de los Tubos Conectores #4 con los dos orificios de ADENTRO de la pata en “U” #2 como están mostrados en la figura 6. Atornillelos hasta el final del orificio con los tornillos # 23, las Figura 6 tuercas de seguridad #15 los separadores de plástico #31 Asegurándose que las tuercas y tornillos estén lo suficientemente apretadas y seguras para mantener la mesa estable pero no los sobre...
  • Page 14 NO APRIETE ESTAS Repita los pasos del 1 al 12 para el segundo tablero. DOS TUERCAS #15 TODAVIA. Figura 9 Inserte cuidadosamente el casquillo de la llanta #12 dentro soporte en forma de U #7 en la Segunda mitad hasta que el borde del casquillo toque el borde del tubo.
  • Page 15 NO SOBRE AJUSTE EL PASADOR DE SEGURIDAD #8. DEBE DE GIRAR LIBREMENTE! Vista de Arriba Figura 11 Placa #5 Pasador de Seguridad #8 (el borde se extiende sobre la placa) INSTALE LOS PASADORES DE SEGURIDAD #8 COMO SE MUESTRA ARRIBA PARA EL USO APROPIADO DE LA MESA! NO OMITA ESTE PASO! NO USE LA ADVERTENCIA: MESA HASTA QUE LOS PASADORES DE SEGURIDAD ESTÉN INSTALADOS Y...
  • Page 16 INSTRUCIONES PARA ABRIR Y CERRAR LA MESA ¡LEA AS INSTRUCCIONES DE MANEJO ANTES DE MOVER LA MESA! ¡NO PERMITA QUE NIÑOS ABRAN LA MESA! NO DEBEN DE PARARSE, SUBIRSE O BRINCAR SOBRE LA MESA . PUEDEN OCURRIR LESIONES GRAVES O ADVERTENCIA! MORTALES.
  • Page 17 GARANTÍA LIMITADA POR 90 DÍAS ® Esta garantía es aplicable para consumidores de la compra original de cualquier producto ESCALADE SPORTS (en adelante denominado el "Producto"). DURACIÓN DE LA GARANTÍA: Se garantiza este Producto al comprador original por un período de (90) días a partir de la fecha de compra. COBERTURA DE LA GARANTÍA: ESCALADE SPORTS le garantiza al comprador original que cualquier producto de su fabricación está...
  • Page 18 LISTA DE PARTES REEMPLAZABLES (T8721) # Ref. # de Parte Descripción Cant. 4A-5468-01 Tablero 8S-6640-00 Pata en U de 1 1/4" 2S-6880-01 Abrazadera en U -1 1/4" 8S-6758-00 Tubo Conector 2S-6422-26 Placa 2S-6428-01 Tira de metal de Seguridad 8S-6606-00 Tubo de Soporte en U...

This manual is also suitable for:

St2000
