Owner's Operation and Instruction Manual
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY NOTICE:
If this unit is not properly installed, a fire may result.
For your safety, follow the installation instructions.
Never use make-shift compromises during the
installation of this unit. Contact local building or fire
officials about permits, restrictions and installation
requirements in your area.
CAUTION!
Please read this entire manual before you install or
use this unit. Failure to follow instructions may result
in property damage, bodily injury, or even death.
Improper Installation Could Void Your Warranty!
Installation is to be preformed by a qualified
installer. SAVE THESE INSTRUCTIONS
MODEL: HB1330E
Wood Only Central Furnace
SAVE THESE INSTRUCTIONS
Ce produit peut vous exposer à des produits chimiques, y compris le
monoxyde de carbone, qui est connu dans l'État de Californie pour causer
le cancer, des malformations congénitales et / ou d'autres problèmes de
reproduction. Pour plus d'informations, visitez www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
United States Stove Company
South Pittsburg, TN 37380
Report No.: 0215WH056E, 0215WH056S.REV001
Certified to UL 391 (R2014), and to CSA B366.1-
11 (R2015) with the Thermostatically Controlled
U.S. ENVIRONMENTAL PROTECTION AGENCY
Certified to comply with the 2016 particulate
emission standards. Not approved for sale after
227 Industrial Park Rd.
Damper Kit installed
May 15, 2020
852834D-2502H
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotblast HB1330E
Summary of Contents for Hotblast HB1330E
- Page 1 Owner’s Operation and Instruction Manual MODEL: HB1330E Wood Only Central Furnace SAVE THESE INSTRUCTIONS THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
- Page 2 CAUTION: • Power source not controlled by furnace main disconnect. • Respect all local and national codes when installing this unit. • This unit is not to be connected to a chimney flue serving another appliance. • This unit is designed to burn solid hardwood only. 40.65 21.00 26-3/4...
-
Page 3: Specifications
Weight (lbs): 350lbs This manual describes the installation and operation of the Hotblast, HB1330E wood heater. This heater meets the 2016 U.S. Environmental Protection Agency’s emission limits for wood heaters sold after May 15, 2016. Under specific EPA test conditions this heater has been shown to deliver heat at a rate of 18,850 –... -
Page 4: Tools And Materials Needed For Installation
Safety • WARNING: Do not operate with fuel loading or ash removal doors open. • Do not connect this unit to a chimney flue serving another appliance. • WARNING DANGER: Risk of fire or explosion. Do not burn garbage, gasoline, naphtha, motor oil, or other inappropriate materials. -
Page 5: Furnace Installation
Furnace Installation INSTALLATION OPTIONS The installation of this furnace includes supplying electrical power, return (fresh air) ductwork, and supply air ductwork. This furnace may be installed in two different configurations. 1. Stand alone wood furnace 2. Add-on wood furnace See kit installation section in this manual to ensure proper assembly, installation and operation of your new furnace. -
Page 6: Duct Work Installation
MAINTENANCE CLEARANCES Your furnace has recommended minimum maintenance clearance requirements. These clearances insure that there is adequate room to preform maintenance and service your furnace. DO NOT store fuel within the specified clearances. See the table and diagram below to determine the clearances for your furnace. -
Page 7: Optional Kits
CENTRAL INSTALLATION Optional Kits Thermostatically Controlled Damper Cold Air Return Enclosure Instruction... -
Page 8: Accessory Installation
Accessory Installation ASSEMBLY OF FURNACE Your furnace requires the following items to be assembled or installed THERMODISC by the service person: COVER THERMODISC Blower and Blower Control Electrical Connections 1. Remove all parts from the unit (blower, thermodisc, and all wiring) and inspect for damage, including the firebrick as some breakage could occur during shipment. -
Page 9: Electrical Installation
Electrical Installation All electrical connections should be done by a qualified electrician It is recommended to connect the furnace to its own 15 amp 120 Volt circuit from the house power supply 105°C NOTE: Wire leads from the distribution blower are usually BOTH BLACK. Makes no difference which leads from the motor(s) connects to the corresponding leads coming out of the conduit. -
Page 10: Chimney Installation
Chimney Installation CHIMNEY Your wood furnace may be hooked up with a factory built or masonry chimney, matching the diameter of the exhaust. If you are using a factory built chimney, it must comply with UL 103 or CSA-B365 standard; therefore it must be a Type HT (2100°F). -
Page 11: Masonry Chimney
MASONRY CHIMNEY Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the furnace is installed and operated. When connecting the furnace through a combustible wall to a masonry chimney, special methods are needed as explained in the “Combustible Wall Chimney Connector Pass-Throughs”... -
Page 12: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 13: Chimney Connector
CHIMNEY CONNECTOR Your chimney connector and chimney must have the same diameter as the furnace outlet. If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. The furnace pipe must be made of aluminized or cold roll steel with a minimum thickness of 0.021”... -
Page 14: Factory Built Chimney
FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. -
Page 15: Operation
Operation OPERATING THE PRIMARY AND SECONDARY AIR SETTINGS Primary air- is the driving air supply that feeds the fire in the heater. This air is introduced through the damper in the feed door to sustain the combustion. Secondary air – is the air supply that is typically introduced above the fire to effectively “re-burn” the smoke created in the primary combustion before the exhaust gasses exit the stove. -
Page 16: Do Not Burn
The top down method of fire building is recommended for this appliance. After making sure that the stove air intake controls are fully open (both air controls open to there maximum setting). Place the largest pieces of wood on the bottom, laid in parallel and close together. Smaller pieces are placed in a second layer, crossways to the first. -
Page 17: Testing Your Wood
It is EXTREMELY IMPORTANT that you use DRY WOOD only. The wood should have dried for 9 to 15 months, such that the humidity content (in weight) is reduced below 20% of the weight of the log. It is very important to keep in mind that even if the wood has been cut for one, two or even more years, it is not necessarily dry, if it has been stored in poor conditions. - Page 18 HEATING WITH YOUR WOOD FURNACE 1. Spread the fire and coals evenly towards the center of the combustion chamber before loading your furnace fully or adding more wood. 2. Avoid overfilling the combustion chamber. Air must be allowed to circulate freely through the upper portion of the combustion chamber for the stove to perform best.
-
Page 19: Over Firing
ASH DISPOSAL Whenever ashes get 3 to 4 inches deep in your firebox or ash pan, and when the fire has burned down and cooled, remove excess ashes. Leave an ash bed approximately 1 inch deep on the firebox bottom to help maintain a hot charcoal bed. -
Page 20: Power Failure Instructions
POWER FAILURE INSTRUCTIONS DO NOT add additional fuel after a power failure, remove all air filters and reduce combustion air to a minimum. Observe furnace closely until power is restored. OPERATIONAL TIPS • Get the appliance hot and establish a good coal bed before adjusting to a low burn rate (this may take 30 minutes or more depending on your wood), for an optimal low burn rate, once there is a well established fire in the furnace, close the damper on the door and open the secondary air damper to its maximum setting •... -
Page 21: Replacement Parts
Replacement Parts Ring, Flue Collar Flue Collar, 6” C.I. Gasket, Flue Collar Stub Collar 8” 22761 40246 88032 891214 Handle Assembly Assembly, Ash Door Ashpan Weldment Wooden Knob Assembly 891098 610496 610498 892767 Firebrick (4 - 1/2 X 9) Cast Grate Curtain, Smoke Shaker Grate Tool 89066... - Page 22 Replacement Parts F140 Thermodisc Cover, Junction Box Cabinet Back Cabinet Top 80714 80231 27945 25561 Cabinet Side Locking Mech, Feed Door Feed Door Hinge Bracket Hinge Spacer 25541 891097 22662 24232 Firebrick (4-1/2 x 9) Feed Door Assy. Air Damper Assy. Air Cover 89066 68217...
- Page 23 Replacement Parts Blower Gasket Right Shoulder Assembly Left Shoulder Brick Retainer 89319 610568 28043 28051 Blower Assembly Top Filler Assembly 5/8 Rope Gasket 1/2 Thermocord 80594 610570 88066 36 in 88057 50 in Firebrick, Half 4-1/2 x 4-1/2 Optional Thermostatically Optional Cold Air Return Controlled Damper Enclosure...
-
Page 24: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider: Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. -
Page 25: Limitations Of Liability
Limited Warranty The operation of this unit in a manner inconsistent with the owner’s manual instructions; (7) installation or use of components not supplied with appliance will void the warranty and is also against federal regulations. United States or any other components not expressly authorized and approved by USSC; (8) Stove Company warrants this product to be free from defects in material and modification of the appliance not expressly authorized and approved by USSC workmanship, to the original retail purchaser only, for the time period identified... - Page 26 How to order Replacement Parts / Comment commander des pièces de rechange This manual will help you obtain efficient, dependable service from your stove, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. When writing, always give the full model number which is on the nameplate attached to the stove.
