Page 1 E-MANUAL Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model _____________ Serial No. _____________...
Page 2: Table Of Contents
Contents Channel Preference • Connecting a USB Device • Connecting to the PC through network • Using the INFO button • Setting the network • Recorded TV (Now & Next guide) • Setting the Time • Videos • Using the Channel Menu • Locking Programme • Music • Using the Channel...
Page 3: Channel
Channel ❑ Using the INFO button (Now & Next guide) The display identifies the current channel and the status of certain audio-video settings. The Now & Next guide shows daily TV programme information for each channel according to the broadcasting time. ●...
Page 4: Using The Channel Menu
❑ Using the Channel Menu Press the SMART HUB button to select the Samsung Apps menu you want to use. Each screen will be displayed. Guide Favourites Channel Videos Photos Music Schedule Manager ■ Source The EPG (Electronic Programme Guide)
Page 5 Using Channel View (Sche. Mgr): Displays the Guide 2:10 Tue 1 Jun DTV Air 800 five Schedule Manager. Home and Away 18:00 - 18:30 Drama Green (-24 Hours): Viewing the list Dani is devastated when scott makes clear his views on marriage... Channel View - All Channels of programmes to be broadcasted Today...
Page 6 Information: Displays details of the selected programme. (Page): Move to next or previous page. (Watch / Schedule): When selecting the current programme, you can watch the selected programme. / When the selecting the next programme, you can reserve the selected programme. ◀...
Page 7 Schedule Manager ■ SMART HUB → → Schedule Manager ENTERE You can view, modify or delete a channel you have reserved to watch. Using the Timer Viewing You can set a desired channel to be displayed automatically at the intended time. Set the current time first to use this function.
Page 8 4. Press the buttons to set the Antenna, Channel, Repeat Start Time. ● Antenna: Select the desired antenna source. ● Channel: Select the desired channel. ● Repeat: Select Once, Manual, Sat~Sun, to set at Mon~Fri Everyday your convenience. If you select Manual, you can set the day you want. mark indicates the date is selected.
Page 9 On the Information screen, you can change or cancel a reserved information. ● Cancel Schedules: Cancel a show you have reserved to watch. ● Edit: Change a show you have reserved to watch. ● Return: Return to the previous screen. Only memorised channels can be reserved.
Page 10 Channel List ■ Channel List You can view all the channel searched. When you press the CH LIST button on No Information the remote control, Channel List screen will be displayed at once. Antenna Programme View L Ch.Mode E Watch k Page ●...
Page 11 Using the operation buttons with the Channel List. ● Red (Antenna): Switches to Air, Cable or Satellite. The option may differ depending on country. ● Yellow (Programme View Channel View): Displays the programme when digital channel is selected. Returns to the channel view. ●...
Page 12: Using The Channel
❑ Using the Channel The option may differ depending on country. Channel ■ SMART HUB → → Channel ENTERE Delete added channels or set favourites channels and use the programme guide for digital broadcasts. Change the antenna or channel settings using the menus in the top right corner of the screen.
Page 13 ● Antenna: Toggle among antenna sources. The option may differ depending on country. ● Sort: Sorting by Channel Number Channel Name. ● Edit Mode: Delete channels assigned to Favourites. Refer to “Using the Favourite Channels” for details on how to assign a channel to favourite. Setting channels you watch frequently as Favourites.
Page 14 2. Press the arrow buttons to select a channel as a Favourite, and then press ENTERE. A check appears to the left of the channel. You can select more than one channel. Pressing ENTERE again deselects the channel. 3. Select Edit Favourites at the bottom of your screen, and then press button.
Page 15 4. Highlight a group on the Favourites list, and then press ENTERE. Edit Favourites screen has five groups (Favourites 1, Favourites 2, etc.). You can add a Favourite channel to any one of the groups. Select a group using the up and down arrows on your remote. 5.
Page 16 ● Using Edit Mode to Delete a Channel from the Channel List. 1. Select the Edit Mode icon on the upper right of your screen, and then press the ENTERE button. 2. Press the buttons to select a channel, and then press ENTERE.
Page 17 4. Select OK, press ENTERE, and then press again. ENTERE The channel is deleted from the Channel List. 5. Press to exit RETURNR Edit Mode. ● All: Select all the channels. Select ◀ ▶ English...
Page 18 Using the TOOLS button with the Channel ● Upcoming programme (digital channels only): View details on the programme being aired on a selected digital channel. ● Favourites: Set channels you watch frequently as favourites. Edit 1. Select the Favourites, then press the button.
Page 19 ● / Unlock: Lock a channel so that the channel cannot be selected and Lock viewed. NOTE ● This function is available only when the is set to On. Channel Lock ● Edit Channel Name (analogue channels only): Assign your own channel name. This function may not be supported depending on the region.
Page 20 ● (when the was set to Satellite): You can search the desired Search Antenna channels according to the settings. ● (when the was set to Satellite): Rearrange the channel Reorder Antenna manager in numerical order. ● Delete: Delete a channel to display the channels you want. ◀...
Page 21 Channel Status Display Icons Icon Operations An analogue channel. A channel selected. A channel set as a Favourite 1-5. A locked channel. Reserved programme ◀ ▶ English...
Page 22: Using Favourite Channels
❑ Using Favourite Channels Favourites ■ SMART HUB → → Favourites ENTERE Shows all favourite channels. ● Edit Favourites t: You can set the selected channels to desired favourites channels. The “F” symbol wil be displayed and the channel will be set as a favourite. ◀...
Page 23 1. On the Channel screen, select a channel and press the TOOLS button. If you want to add mulitple channels, use the Edit Mode menu in the top right corner of the Channel screen. 2. Add or delete a channel in the favourite channels you want among 1, 2, 3, 4 and 5.
Page 24: Memorising Channels
❑ Memorising Channels → → MENUm Channel ENTERE Antenna (Air / Cable) ■ The option may differ depending on country. Before your television can begin memorising the available channels, you must specify the type of signal source that is connected to the TV. ◀...
Page 25 Country ■ The PIN input screen appears. Enter your 4 digit PIN number. Select your country so that the TV can correctly auto-tune the broadcasting channels. ● Digital Channel: Change the country for digital channels. ● Analogue Channel: Change the country for analogue channels. ◀...
Page 26 Auto Tuning ■ Scans for a channel automatically and stores in the TV. Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked using the Channel Lock function, the PIN input window appears. –...
Page 27 If you select Quick, you can set up the Network, Network ID, Frequency, Modulation, Symbol Rate manually by press the button on the remote control. – Network (Auto / Manual): Selects the setting mode among Network ID Auto Manual. – Network ID: When Network...
Page 28 – : Channels found will be automatically ordered Automatic Ordering for Italy following a criterion established by all the main national and local televisions. – : If you select this menu you will find others Others Ordering for Italy channels ordering directly organized from private national televisions. Automatic Ordering Others Ordering are available when antenna source...
Page 29 ● Cable Search Option (depending on the country) Sets additional search options such as the frequency and symbol rate for a cable network search. – Freq.Start / Freq.Stop: Set the start or stop frequency (differs in each country) – Symbol Rate: Displays available symbol rates.
Page 30 Manual Tuning ■ Scans for a channel manually and stores in the TV. If a channel is locked using the Channel Lock function, the PIN input window appears. ● Digital Channel Tuning: Scans for a digital channel. 1. Press the button to select New.
Page 31 ● Tuning: Scans for a analogue channel. Analogue Channel 1. Press the button to select New. 2. Set the Programme, Colour System, Sound System, Channel Search. 3. Press the button to select Store. When scanning has finnished, a channel is updated in the channel list. ◀...
Page 32 Channel mode ● (programme mode): When tuning is complete, the broadcasting stations in your area have been assigned to position numbers from P0 to P99. You can select a channel by entering the position number in this mode. ● (aerial channel mode) / (cable channel mode): These two modes allow you to select a channel by entering the assigned number for each aerial broadcasting station or cable channel.
Page 33: Using The Channel (For Satellite Tv)
❑ Using the Channel (for satellite TV) for LED 6200 series and above, Not for UK The option may differ depending on country. Channel ■ SMART HUB → → Channel ENTERE Delete added channels or set favourites channels and use the programme guide for digital broadcasts.
Page 34 Using the TOOLS button with the Channel ● Edit Favourites: Set channels you watch frequently as favourites. 1. Select the Edit Favourites, then press the ENTERE button. 2. Press the ENTERE button to select Favourite 1-5, then press the button. One favourite channel can be added in several of favourite channels among Favourite...
Page 35 ● / Unlock: Lock a channel so that the channel cannot be selected and Lock viewed. NOTE ● This function is available only when the is set to On. Channel Lock ● Edit Channel Name (analogue channels only): Assign your own channel name. This function may not be supported depending on the region.
Page 36 ● Upcoming programme (digital channels only): View details on the programme being aired on a selected digital channel. ● Search (when the Antenna was set to Satellite): You can search the desired channels according to the settings. ● Reorder: (when the was set to Satellite): Rearrange the channel Antenna manager in numerical order.
Page 37 Channel Status Display Icons Icon Operations An analogue channel. A channel selected. A channel set as a Favourite 1-5. A locked channel. ◀ ▶ English...
Page 38: Using Favourite Channels (For Satellite Tv)
❑ Using Favourite Channels (for satellite TV) Favourites ■ Shows all favourite channels. Channel All Channels Selected Item(s) : 1 Select All ● Edit Favourites t: You can set the selected channels to desired favourites channels. Edit Mode The “F” symbol wil be displayed and Edit Favourites Edit Channel Number Lock...
Page 39 1. On the Channel screen, select a channel and press the TOOLS button. If you want to add mulitple channels, use the Edit Mode menu in the top right corner of the Channel screen. 2. Add or delete a channel in the favourite channels you want among 1, 2, 3, 4 and 5.
Page 40: Memorising Channels (For Satellite Tv)
❑ Memorising Channels (for satellite TV) → → MENUm Channel ENTERE Antenna ■ The option may differ depending on country. Before your television can begin memorising the available channels, you must specify the type of signal source that is connected to the TV. ◀...
Page 41 Country ■ The PIN input screen appears. Enter your 4 digit PIN number. Select your country so that the TV can correctly auto-tune the broadcasting channels. The option may differ depending on country. ● Digital Channel: Change the country for digital channels. ●...
Page 42 Auto Tuning ■ Scans for a channel automatically and stores in the TV. Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked using the Channel Lock function, the PIN input window appears. –...
Page 43 – : Channels found will be automatically ordered Automatic Ordering for italy following a criterion established by all the main national and local televisions. – : If you select this menu you will find others Others Ordering for italy channels ordering directly organized from private national televisions. Automatic Ordering Others Ordering are available when antenna source...
Page 44 ● Cable Search Option (depending on the country) Sets additional search options such as the frequency and symbol rate for a cable network search. – Freq.Start / Freq.Stop: Set the start or stop frequency (differs in each country) – Symbol Rate: Displays available symbol rates.
Page 45 Manual Tuning ■ Scans for a channel manually and stores in the TV. If a channel is locked using the Channel Lock function, the PIN input window appears. ● Transponder: Selects the transponder using the up/down buttons. ● Scan Mode: Selects either free or all channels to store. ●...
Page 46 Satellite System ■ The PIN input screen appears. Enter your 4 digit PIN number. Satellite System is available when Antenna is set to Satellite. Before running Auto Store, set System. Then channel scan is run normally. Satellite ● Selection: You can choose the satellites for this TV. Satellite ●...
Page 47 ● Settings: Configures the outdoor equipment. – Satellite: Selects the satellite for receiving digital broadcasts. – Transponder: Selects a transponder from the list or adds a new transponder. – Mode: Selects DiSEqC mode for the selected LNB. DiSEqC – Oscillators: Sets the LNB oscillators to a lower frequency. Lower LNB –...
Page 48 ● Settings: Configures the antenna positioner. Positioner Positioner (On / Off): Enables or disables the positioned control. Positioner Type (USALS DiSEqC 1.2): Sets the positioned type between DiSEqC 1.2 and USALS(Universal Satellite Automatic Location System). – Longitude: Sets the longitude for my location. –...
Page 49 Mode: Sets the position of satellite antenna according to each satellite. User If you store the current position of satellite antenna according to a certain satellite, when the signal of that satellite is needed, the satellite antenna can be moved to pre-populated position. –...
Page 50 – Position: Rotates the antenna to the stored satellite position. Go to Stored – Antenna Position: Adjusts and stores the antenna position for the selected satellite. – Position: Stores current position as the selected positioner Store Current limit. – Signal Quality: Display the current status of broadcasting signal.
Page 51 Mode: Sets limits to the scope of movement of satellite antenna or Installer reset the position. Generally, installation guide uses this function. – Limit Position (East / West): Selects the direction of the positioner Limit. – Antenna Position: Adjusts and stores the antenna position for the selected satellite.
Page 52: Other Features
■ for LED 6500 Series and above (depending on the country) You can select a different type of Guide. ● Samsung: Uses the guide programme by provided samsung. ◀ ▶ ● Rovi On Screen: Uses the guide programme provided by Rovi International Solutions.
Page 53 Fine Tune ■ (analogue channels only) If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, fine tune the channel manually. Scroll to the left or right until the image is clear.
Page 54 Transfer Channel List ■ The PIN input screen appears. Enter your 4 digit PIN number. Imports or exports the channel map. You should connect a USB storage to use this function. ● Import from USB: Import channel list from USB. ●...
Page 55: Basic Features
Basic Features ❑ Changing the Preset Picture Mode → → → MENUm Picture Picture Mode ENTERE Picture Mode ■ Select your preferred picture type. ● Dynamic: Suitable for a bright room. ● Standard: Suitable for a normal environment. ● Natural: Suitable for reducing eye strain. ◀...
Page 56: Adjusting Picture Settings
❑ Adjusting Picture Settings Backlight Contrast Brightness Sharpness Colour Tint (G/R) ■ Your television has several setting options for picture quality control. In analogue TV, Ext., modes of the PAL system, the Tint (G/R) function is not available. When connecting a PC, you can only make changes to Backlight, Contrast, Brightness and Sharpness.
Page 57: Changing The Picture Size
❑ Changing the Picture Size → → → MENUm Picture Screen Adjustment ENTERE Screen Adjustment ■ ● Picture Size: Your cable box/satellite receiver may have its own set of screen sizes as well. However, we highly recommend you use 16:9 mode most of the time.
Page 58 – Zoom: Magnifies the 16:9 wide pictures vertically to fit the screen size. Adjusts the Position or Zoom by using u, button. – 4:3: The default setting for a movie or normal broadcasting. Do not watch in 4:3 format for a long time. Traces of borders displayed on the left, right and centre of the screen may cause image retention(screen burn) which are not covered by the warranty.
Page 59 – Screen Fit: Displays the full image without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p) signals are inputted. – Smart View 1: Reduces the 16:9 picture by 50%. – Smart View 2: Reduces the 16:9 picture by 25%. Smart View 1 is enabled only in HDMI mode.
Page 60 NOTE ● Depending on the input source, the picture size options may vary. ● The available items may differ depending on the selected mode. ● When connecting a PC, only 16:9 modes can be adjusted. ● Settings can be adjusted and stored for each external device connected to an input on the TV.
Page 61 ● If you use the function with HDMI 720p input, 1 line will be cut at Screen Fit the top, bottom, left and right as in the overscan function. Input Source Picture Size ATV, EXT Auto Wide, 16:9, Wide Zoom, Zoom, AV, Component (480i, 480p, 576i, 576p) DTV (720p, 1080i, 1080p) Auto...
Page 62 ● 4:3 Screen Size (16:9 / 4:3): Available only when picture Wide Zoom Zoom size is set to Wide. You can determine the desired picture size at the 4:3 Auto WSS (Wide Screen Service) size or the original size. Each European country requires different picture size.
Page 63: Changing The Picture Options
❑ Changing the Picture Options Advanced Settings ■ → → → MENUm Picture Advanced Settings Advanced Settings ENTERE Black Tone Dynamic Contrast Medium Advanced Settings are available in Standard Shadow Detail Movie mode. Gamma Expert Patten You can adjust the detailed setting for the screen RGB Only Mode ◀...
Page 64 ● Black Tone (Off / Darkest): Select the black level to adjust the Dark Darker screen depth. ● Dynamic Contrast (Off / High): Adjust the screen contrast. Medium ● (-2~+2): Increase the brightness of dark images. Shadow Detail ● Gamma: Adjust the primary colour intensity. ●...
Page 65 ● RGB Only Mode (Off / Blue): Displays the Red, Green Green colour for making fine adjustments to the hue and saturation. Blue ● Colour Space (Auto / Custom): Adjust the range of colours available Native to create the image. To adjust Colour, Red, Green, Blue and Reset, set...
Page 66 ● 10p White Balance (Off / On): Controls the white balance in 10 point interval by adjusting the red, green, and blue brightness. Available when the picture mode is set to Movie and when the external input is set to all input. Some external devices may not support this function.
Page 67 ● Tone: Emphasize pink “Flesh Tone”. Flesh ● Edge Enhancement (Off / On): Emphasize object boundaries. ● Motion Lighting (Off / On): Reduce power consumption by brightness control. Motion Lighting is available in Standard Movie mode. Not supported in mode. When changing a setting value of Contrast, Motion Lighting will be set to...
Page 68 ● xvYCC (Off / On): Setting the mode on increases detail and colour xvYCC space when watching movies from an external device (e.g. DVD player) connected to the HDMI or Component IN jacks. Available when the picture mode is set to Movie and when the external input is set to HDMI or Component.
Page 69 Picture Options ■ → → → MENUm Picture Picture Options Picture Option ENTERE Colour Tone Standard Digital Noise Filter Auto When connecting a PC, you can only make changes MPEG Noise Filter Auto to the Colour Tone. HDMI Black Level Nomal ●...
Page 70 ● Digital Noise Filter (Off Medium High Auto Auto Visualisation): When the broadcast signal is weak, some static and ghosting may appear. Select one of the options until the best picture is displayed. Visualisation: When changing analogue channels, displays the intensity Auto of the current signal and defines the screen noise filter.
Page 71 ● MPEG Noise Filter (Off Medium High / Auto): Reduces MPEG noise to provide improved picture quality. ● HDMI Black Level (Low / Normal): Selects the black level on the screen to adjust the screen depth. Available only in HDMI mode (RGB signals). ●...
Page 72 ● Motion Plus (Off Clear Standard Smooth Custom / Demo): Removes drag from fast scenes with a lot of movement to provide a clearer picture. The Info screen on your TV displays the resolution and frequency of the incoming signal (60Hz), but not the frequency the TV is generating for the image it is displaying by using Motion Plus function.
Page 73 Reduction: Adjusts the blur reduction level from video sources. Blur Judder Reduction: Adjusts the judder reduction level from video sources when playing films. Reset: Reset the custom settings. Reset Picture (Yes / No) ■ Resets your current picture mode to its default settings. ◀...
Page 74: Setting Up The Tv With Your Pc
❑ Setting up the TV with Your PC Set the input source to PC. Auto Adjustment ■ → → → MENUm Picture Auto Adjustment ENTERE Adjust frequency values/positions and fine tune the settings automatically. Not available when connecting with an HDMI to DVI cable. ◀...
Page 75 PC Screen Adjustment ■ → → → → MENUm Picture Screen Adjustment PC Screen Adjustment ENTERE ● Coarse / Fine: Removes or reduces picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (Coarse) and Fine-tune again.
Page 76 Depending on the version of Windows and the video card, the actual screens on your PC may differ in which case the same basic set-up information will almost always be applied. (If not, contact your computer manufacturer or Samsung Dealer.) 1. Click on “Control Panel” on the Windows start menu.
Page 77: Changing The Preset Sound Mode
❑ Changing the Preset Sound Mode → → → MENUm Sound Sound Mode ENTERE Sound Mode ■ ● Standard: Selects the normal sound mode. ● Music: Emphasizes music over voices. ● Movie: Provides the best sound for movies. ● Clear Voice: Emphasizes voices over other sounds.
Page 78: Adjusting Sound Settings
❑ Adjusting Sound Settings → → MENUm Sound ENTERE Sound Effect ■ ● SRS TruSurround HD (Off / On) (standard sound mode only) This function provides a virtual 5.1 channel surround sound experience through a pair of speakers using HRTF (Head Related Transfer Function) technology. ◀...
Page 79 ● Headphone: You can hear virtual 5.1ch surround sound over the SRS CS headphones. ● Equalizer Adjusts the sound mode (standard sound mode only). – Balance L/R: Adjusts the balance between the right and left speaker. – 100Hz 300Hz 1kHz 3kHz 10kHz (Bandwidth Adjustment): Adjusts...
Page 80 3D Audio (Off Medium / High): 3D audio technology provides the ■ immersive sound corresponding to the pop-up effect of 3D video by audio depth control in perspective. Available in only when watching 3D image. Broadcast Audio Options ■ ● Audio Language (digital channels only) ◀...
Page 81 ● Audio Format (digital channels only) When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function. Audio Format option may differ depending on the broadcast.
Page 82 ● Audio Description (not available in all locations) (digital channels only) This function handles the Audio Stream for the AD (Audio Description) which is sent along with the Main audio from the broadcaster. Audio Description (Off / On): Turn the audio description function on or off. Volume: Adjust the audio description volume.
Page 83 Additional Setting ■ (digital channels only) ● DTV Audio Level (MPEG / HE-AAC): This function allows you to reduce the disparity of a voice signal (which is one of the signals received during a digital TV broadcast) to a desired level. According to the type of broadcast signal, MPEG HE-AAC...
Page 84 ● Output: SPDIF (Sony Philips Digital InterFace) is used to provide digital SPDIF sound, reducing interference going to speakers and various digital devices such as a DVD player. ● Audio Format: During the reception of a digital TV broadcast, you can select the Digital Audio output (SPDIF) format from the options Dolby Digital.
Page 85 ● Dolby Digital Comp (Line / RF): This function minimizes signal disparity between a dolby digital signal and a voice signal (i.e. MPEG Audio, HE-AAC, ATV Sound). Select Line to obtain dynamic sound, and RF to reduce the difference between loud and soft sounds at night time. ●...
Page 86 Speaker Settings ■ ● Speaker Select (External Speaker Speaker) A sound echo may occur due to a difference in decoding speed between the main speaker and the audio receiver. In this case, set the TV to External Speaker. When Speaker Select is set to External Speaker, the volume and MUTE...
Page 87 ● Auto Volume (Off Normal / Night) To equalize the volume level on each channel, set to Normal. Night: This mode provides an improved sound experience compared to Normal mode, making almost no noise. It is useful at night. Reset Sound (Yes / No) ■...
Page 88: Preference
Preference ❑ Setting the network ■ Connecting to a Wired Network You can attach your TV to your LAN using cable in three ways: ● You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a LAN cable.
Page 89 ● You can attach your TV to your LAN by connecting the LAN port on the back of your TV to a IP Sharer which is connected to an external modem. Use LAN cable for the connection. See the diagram below. The Modem Port TV Rear Panel on the Wall...
Page 90 ● Depending on how your network is configured, you may be able to attach your TV to your LAN by connecting the LAN port on the back of your TV directly to a network wall outlet using a LAN cable. See the diagram below. Note that the wall outlet is attached to a modem or router elsewhere in your house.
Page 91 ● If you have a Dynamic Network, you should use an ADSL modem or router that supports Dynamic Host Configuration Protocol (DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway, and DNS values your TV needs to access the Internet so you do not have to enter them manually.
Page 92 Network Settings ■ Network → → → MENUm Network Network Setting Network Settings Network Status ENTERE Allshare setting Set the network connection to use various Internet services such as SMART HUB, AllShare and perform software upgrade. ● The displayed image may differ depending on the model.
Page 93 Network Setup (Auto) ■ Use the Automatic Network Setup when connecting your TV to a network that supports DHCP. To set up your TV’s cable network connection automatically, follow these steps: How to set up automatically 1. Go to Network Settings screen.
Page 94 If it fails to set automatically, check the Network Setting connection of LAN port. Wired network and Internet connection completed. MAC Address 00:12:fb:2b:56:4d If you cannot find network connection IP Address 192.168.11.4 Subnet Mask 255.255.255.0 Gareway 192.168.11.1 Retry values or if you want to set connection SEC_LinkShare DNS Server 192.168.11.1...
Page 95 Network Setting (Manual) ■ Use the Manual Network Setup when connecting your TV to a network that requires a Static IP address. Getting the Network Connection Values To get the Network connection values on most Windows computers, follow these steps: 1.
Page 96 How to set up manually To set up your TV’s cable network connection manually, follow these steps: 1. Follow Steps 1 through 2 in the “How to set up automatically” procedure. 2. Select the on network test screen. IP Settings IP Settings IP Mode Manual...
Page 97 5. Enter the Mask, Gateway, and values. Use the Address, Subnet DNS Server number buttons on your remote to enter numbers and the arrow buttons to move from one entry field to another. 6. When done, select the OK. 7. The network test screen appears, and network setting is done. ◀...
Page 98 LED 6300 series and under To connect your TV to your network wireless, you need a wireless router or modem and a Samsung Wireless LAN adapter (WIS09ABGN, WIS09ABGN2, WIS10ABGN-sold separately) , which you connect to your TV’s back or side panel USB port.
Page 99 Samsung’s Wireless LAN adapter is sold separately and is offered by selected retailers, Ecommerce sites and Samsungparts.com. Samsung’s Wireless LAN adapter supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection, the video may not be played smoothly.
Page 100 ● To use a wireless network, your TV must be connected to a wireless IP sharer (either a router or a modem). If the wireless IP sharer supports DHCP, your TV can use a DHCP or static IP address to connect to the wireless network. ●...
Page 101 If Pure High-throughput (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP, TKIP or TKIP AES (WPS2Mixed) for your wireless router, Samsung TVs will not support a connection in compliance with new Wi- Fi certification specifications.
Page 102 ● Connection Methods: You can setup the wireless network connection on five ways. – Auto Setup (Using the Auto Network Search function) – Manual Setup – WPS (PBC) – One Foot Connection – Plug & Access ◀ ▶ – Ad hoc English...
Page 103 ■ Connecting to a Wireless Network for LED 6500 Series and above To connect your TV to your network wireless, you can use a wireless network to use the Samsung Wireless LAN adapter where is built-in the TV. The LAN Port on the Wall...
Page 104 Samsung Wireless LAN adapter supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection, the video may not be played smoothly. NOTE ● To use a wireless network, your TV must be connected to a wireless IP sharer (either a router or a modem).
Page 105 If Pure High-throughput (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP, TKIP or TKIP AES (WPS2Mixed) for your wireless router, Samsung TVs will not support a connection in compliance with new Wi- Fi certification specifications.
Page 106 ● Connection Methods: You can setup the wireless network connection on five ways. – Auto Setup (Using the Auto Network Search function) – Manual Setup – WPS (PBC) – One Foot Connection – Plug & Access ◀ ▶ – Ad hoc English...
Page 107 Network Setup (Auto) ■ Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network.
Page 108 3. The function searches for available wireless networks. When done, it Network displays a list of the available networks. 4. In the list of networks, press the Network Setting button to select a network, and then press Enter Access Point Name(SSID) to connect. ENTERE button.
Page 109 6. If the wireless router has security, enter the Security key(Security or PIN), then select Next. When you enter the Security key(Security or PIN), use buttons on your remote to select number/characters. You should be able to find the Pass Phrase on one of the set up screens you used to set up your router or modem.
Page 110 Network Setup (Manual) ■ Use the Manual Network Setup when connecting your TV to a network that requires a Static IP address. Getting the Network Connection Values To get the Network connection values on most Windows computers, follow these steps: 1.
Page 111 How to set up manually To set up your TV’s wireless network connection IP Settings manually, follow these steps: IP Mode Manual 1. Follow Steps 1 through 7 in the “How to set IP Address 0 . 0 . 0 . 0 Subnet Mask 0 .
Page 112 5. Enter the Mask, Gateway, and values. Use Address, Subnet DNS Server the number buttons on your remote to enter numbers and the arrow buttons to move from one entry field to another. 6. When done, select the OK. 7. The network connection screen appears, and network setting is done. ◀...
Page 113 Network Setup (WPS(PBC)) ■ How to set up using WPS(PBC) If your router has a WPS(PBC) button, follow these steps: 1. Go to Network Setting screen. To enter it, Network Setting follow the directions of Network Setting. Select a network connection type. Wired 2.
Page 114 Ad Hoc Network Setup ■ You can connect to a mobile device supporting Ad-hoc connections without a wireless router or AP through the TV. When connected to a mobile device, you can use files on the device or connect to the Internet using the AllShare or Multimedia function.
Page 115 3. Select hoc. The message “Ad hoc service supports a direct connection with Wi-Fi compatible devices like a cell phone or PC. Other network services may be limited. Do you want to change the network connection?” is displayed. 4. Select OK, and press ENTERE. The TV searches for the mobile device. 5.
Page 116 Connection) ■ One Foot Connection make you easy to connect samsung TV and samsung wireless router by placing samsung wireless router within 1 foot(25cm) from samsung TV. If your wireless router does not support Connection, you One Foot must connect using one of the other methods.
Page 117 Select this connection type after Cancel placing the access point within 10 inches (25 cm) of your TV. Samsung Wireless LAN adapter giving a gap no larger than 25cm. ◀ ▶ ● The displayed image may differ depending on the model.
Page 118 One Foot Connection again, reset the wireless router, disconnect the Samsung Wireless LAN adapter and then try again from Step 1. You can also choose one of the other connection setup methods. 4. The network connection screen appears, and network setting is done.
Page 119 Network Setting (Plug & Access) ■ Plug & Access function make you easy to connect samsung TV and samsung wireless router by using USB memory stick. If your wireless router does not support Access, you must connect using one of the other methods.
Page 120 If you want ◀ ▶ to try using Plug & Access again, reset the wireless router disconnect the Samsung Wireless LAN adapter and then try again from Step 1. You can also choose one of the other connection setup methods. English...
Page 121 4. The network connection screen appears, and network setting is done. 5. Place the wireless router in a desired location. If the wireless router settings change or you install a new wireless router you must perform the procedure again, beginning from Step 1. Plug &...
Page 122 Samsung wireless Router is optimized HD AV streaming for Samsung DTV This is our product’s distinctive function. Samsung wireless Router can be connected with many devices, such as laptop, mobile phone, BD player etc. In case of connecting Samsung TV to Samsung wireless Router while other devices are connected, Samsung wireless Router will give Samsung TV a priority ◀...
Page 123 If Your TV Fails to Connect to the Internet Your TV may not be able to connect to the Internet because your ISP has permanently reg- istered the MAC address (a unique identifying number) of your PC or modem, which it then authenticates each time you connect to the Internet as a way of preventing unauthorized access.
Page 124: Setting The Time
❑ Setting the Time → → → MENUm System Time ENTERE Time ■ ● Clock: Setting the clock is for using various timer features of the TV. The current time will appear every time you press the INFO button. If you disconnect the power cord, you have to set the clock again. ◀...
Page 125 – Clock Mode (Auto / Manual) Auto: Set the current time automatically using the time from a digital channel. The antenna must be connected in order to set the time automatically. Manual: Set the current time manually. Depending on the broadcast station and signal, the auto time set up may not be correct.
Page 126 – Set: Set the and Time. Clock Date Available only when Clock Mode is set to Manual. You can set the Date Time directly by pressing the number buttons on the remote control. – Time Zone (Auto / Manual): Set the time zone to GMT. Available only when the Clock Mode is set to Auto.
Page 127 Using the Sleep Timer → → → → MENUm System Time Sleep Timer ENTERE ● Sleep Timer t: Automatically shuts off the TV after a preset period of time. (30, 60, 90, 120, 150 and 180 minutes). To cancel Timer, select Off. Sleep ◀...
Page 128 Setting the On / Off Timer → → → MENUm System Time ENTERE On Timer 1 ● On Timer 1 On Timer 2 On Timer Setup Three different on timer settings can be made. You must set the clock first. Time 12:00 am Volume...
Page 129 Time: Set the hour and minute. Volume: Set the desired volume level. Source: Select content to be played when the TV is turned on automatically. (USB can be selected only when a USB device is connected to the TV) Antenna (when the Source is set to TV): Select...
Page 130 NOTE ● If there is no music file on the USB device or the folder containing a music file is not selected, the Timer function does not operate correctly. ● When there is only one photo file in the USB, the Slide Show will not play.
Page 131 ● Each USB you use is assigned its own folder. When using more than one of the same type of USB, make sure the folders assigned to each USB have different names. ● It is recommended that you use a USB memory stick and a multi card reader when using On Timer.
Page 132 ● Off Timer 1 Off Timer 2 Off Timer Off Timer 1 Three different off timer settings can be Setup made. You must set the clock first. Setup: Select Off, Once, Everyday, Time 12:00 Mon~Fri, Mon~Sat, Sat~Sun Manual set at you convenience. If you select Manual, Close you can set up the day you want to activate the timer.
Page 133: Locking Programme
❑ Locking Programme → → → MENUm System Security ENTERE Security ■ The PIN input screen appears before the setup screen. Enter your 4-digit PIN. Change the PIN using the Change PIN option. ● Channel Lock (Off / On): Lock channels in channel list, to prevent unauthorized users, such as children, from watching unsuitable program.
Page 134 ● Program Rating Lock: Prevent unauthorized users, such as children, from watching unsuitable Program with a userdefined 4-digit PIN code. If selected channel is locked,the “\” symbol will be displayed. The items of differs depending on the country. Program Rating Lock ●...
Page 135 How to watch a restricted channel If the TV is tuned to a restricted channel, the will block it. Program Rating Lock The screen will go blank and the following message will appear: This channel is blocked by Program Rating Lock.
Page 136: Economical Solutions
❑ Economical Solutions Eco Solution ■ → → → MENUm System Eco Solution ENTERE ● Energy Saving (Off Medium High Picture Off) t: This adjusts the brightness of the TV in order to reduce power consumption. If you select Picture Off, the screen is turned off, but the sound remains on.
Page 137 ● Eco Sensor (Off / On): To enhance your power savings; the picture settings will automatically adapt to the light in the room. If you adjust the Backlight, the will be set to Off. Eco Sensor Backlight: When is On, the minimum screen brightness can Eco sensor be adjusted manually.
Page 138 ● No-Signal Power Off (Off min): To avoid unnecessary 15 min 30 min energy consumption, set how long you want the TV to remain on if it’s not receiving a signal. Disabled when the PC is in power saving mode. ●...
Page 139: Other Features
❑ Other Features → → MENUm System ENTERE Language ■ ● Menu Language: Set the menu language. ● Teletext Language: Set a desired language for teletext. English is the default in cases where the selected language is unavailable in the broadcast. ◀...
Page 140 Subtitle ■ Use this menu to set the Subtitle mode. ● Subtitle (Off / On): Switches subtitles on or off. ● Mode (Normal Hearing Impaired): Sets the subtitle mode. ● Subtitle Language: Sets the subtitle language. If the programme you are watching does not support the Hearing Impaired function, Normal...
Page 141 General ■ ● Game Mode (Off / On): When connecting to a game console such as PlayStation™ or Xbox™, you can enjoy a more realistic gaming experience by selecting game mode. NOTE ● Precautions and limitations for game mode – To disconnect the game console and connect another external device, Game Mode in the setup menu.
Page 142 ● is not available when the input source is set to TV or PC. Game Mode ● After connecting the game console, set Game Mode to On. Unfortunately, you may notice reduced picture quality. ● is On: Game Mode – Picture mode is set to Standard...
Page 143 ● BD Wise (Off / On): Provides the optimal picture quality for Samsung DVD, Blu- ray and Home Theatre products which support Wise. When BD Wise turned On, the picture mode is automatically changed to the optimal resolution. Available when connecting Samsung products that support BD Wise through a HDMI cable.
Page 144 ● Boot Logo (Off / On): Display Samsung logo when the TV is turned on. ● Name: Sets the TV name so you can find it easily on a mobile device. If you select User Input, you can type on the TV using the OSK (On Screen Keyboard).
Page 145 For more information on DivX® VOD, visit “http://vod.divx.com”. Network Remote Control (Off / On) ■ Turn on/off or give permission to Samsung mobile phones devices. You must ◀ have a Samsung Mobile phone/ 3” touch control/ device which supports Wireless ▶...
Page 146 Common Interface ■ ● Menu: This enables the user to select from the CAM-provided menu. Select the CI Menu based on the menu PC Card. ● Application Info: View information on the CAM inserted into the CI slot and on the “CI or CI+ CARD”...
Page 147: Picture In Picture (Pip)
❑ Picture In Picture (PIP) → → → MENUm System ENTERE ■ You can watch the TV tuner and one external video source simultaneously. (Picture-in-Picture) does not function in the same mode. NOTE ● For PIP sound, refer to the Sound Select instructions.
Page 148 ● You may notice that the picture in the PIP window becomes slightly unnatural when you use the main screen to view a game or karaoke. ● While Child Lock SMART HUB are in operation the function cannot be used. ●...
Page 149 ● PIP (Off / On): Activate or deactivate the PIP function. ● Channel: Select the channel for the sub-screen. ● Size (Õ / Œ): Select a size for the sub-picture. ã à ● Position (ã / œ): Select a position for the sub-picture. –...
Page 150: Support
❑ Support e-Manual ■ → → → MENUm Support e-Manual ENTERE You can read the introduction and instructions about the TV features stored in your TV. For the detailed information about e-Manual Screen, refer to “How to view the e-Manual” in User Manual. ◀...
Page 151 / No): Use to check for picture problems. ● Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a problem with the TV. Contact Samsung’s Call Centre for assistance. ◀...
Page 152 MUTE button. ● Yes: If you can hear sound only from one speaker or not at all during the sound test, select Yes. There may be a problem with the TV. Contact Samsung’s Call ◀ ▶...
Page 153 Adjust your antenna to increase signal strength. ● Troubleshooting: If the TV seems to have a problem, refer to this description. If none of these troubleshooting tips apply, contact the Samsung customer service centre. ◀ ▶...
Page 154 ◀ ▶ “www.samsung.com,” into the TV. Please be careful not to disconnect the power or remove the USB drive until upgrades are complete. The TV will be turned off and on automatically after completing the firmware upgrade. When software is upgraded, video and audio settings you have made will return to their default settings.
Page 155 ● Online: Upgrade the software using the Internet. First, configure your network. For detailed procedures on using the Network Setup, refer to the “Network Connection” instructions. If the internet connection doesn’t operate properly, the connection may be broken. Please retry downloading. If the problem persists, download by USB and upgrade.
Page 156 Since the power of the unit is turned on internally, the screen may be turned on slightly for the product. This phenomenon may continue for more than 1 hour until the software upgrade is complete. Contact Samsung ■ ◀...
Page 157: Advanced Features
This exciting new feature enables you to view 3D content. In order to fully enjoy this feature, you must purchase a pair of Samsung 3D Active Glasses to view 3D video (depending on the model). Samsung 3D Active Glasses are sold separately. For more detailed purchasing information, contact the retailer where you purchased this TV.
Page 158: Viewing Tv Using The 3D Function
❑ Viewing TV using the 3D function → → → MENUm Picture ENTERE IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the TV’s function. WARNING ● Some viewers may experience discomfort while viewing 3D TV such as ◀...
Page 159 ● A responsible adult should frequently check on children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest. ● Do not use the 3D Active Glasses for other purposes (such as general eyeglasses, sunglasses, protective goggles, etc.) ●...
Page 160 3D Mode Operation Turns the 3D function off. Changes a 2D image to 3D. for LED 6500 series and above 2D → 3D Side by Side Displays two images next to each other. Top & Bottom Displays one image above another. Some file format may not be supported the "2D →...
Page 161 ● 3D Perspective (-5 ~ +5): Adjust overall 3D perspective of on-screen image. for LED 6500 series and above ● (0~10): Adjust overall depth. Depth for LED 6500 series and above ● L/R Change (L/R Image Image): Swap the left and right pictures. ●...
Page 162 Support resolution (16:9 only) Resolution Frequency (Hz) 1280 x 720p 50 / 60 Hz 1920 x 1080i 50 / 60 Hz 1920 x 1080p 24 / 30 / 50 / 60 Hz Resolution supported for HDMI PC mode ◀ ▶ The resolution for HDMI PC mode is optimized to 1920 x 1080 input.
Page 163 How to watch the 3D image ● Method 1 Some 3D modes may not be available depending on the format of the image source. To watch in 3D, wear 3D Active Glasses and press the power button on the glasses. 1.
Page 164 3. Use the button to select Mode, and then press the button. ENTERE 4. Using the buttons on your remote control, select the 3D Mode of the image 3D mode you want to view. Cancel ● The displayed image may differ depending on the model.
Page 165 ● Method 2 1. Press the 3D button on your remote. and then you can view the image. 2. If you want to change 3D options (such as Perspective), press the MENU button on your remote, and then select Picture. 3.
Page 166 Supported formats and operating specifications for Standard HDMI 3D The 3D formats indicated below are recommended by the HDMI association and must be supported. Source signal format Standard HDMI 1.4 3D 1920x1080p@24Hz x 2 1920x2205p@24Hz 1280x720p@60Hz x 2 1280x1470p@60Hz 1280x720p@50Hz x 2 1280x1470p@50Hz ◀...
Page 167 Before using 3D function... NOTE ● 3D Mode is set to automatically when accessing SMART HUB functions. ● 3D Mode is set to memorised configuration value automatically, when changing the input source. ● Some Picture functions are disabled in mode. ◀...
Page 168 ● 3D Active Glasses from Samsung’s previous product (IR type) or other manufacturers not be supported. ● When the TV is initially powered on, may take some time until the 3D display is optimized. ● The 3D Active Glasses may not work properly if there is any other 3D product or electronic devices turned on near the glasses or TV.
Page 169 ● Be sure to stay within the viewing angle and optimum TV viewing distance when watching 3D pictures. ● Otherwise, you may not be able to enjoy proper 3D effects. ● The ideal viewing distance should be three times or more the height of the screen.
Page 170: Getting Started With Smart Hub
❑ Getting Started with Smart Hub Features Search All Social TV Easily search and access Share your TV viewing content from diverse sources experience with your friends (e.g. applications, Your Video, via social networking service AllShare). (SNS). Your Video Web Browser ◀...
Page 171 Smart Hub Search Your Video Samsung Apps contents and services directly from the web to your TV. The Gateway to all content integrated in one Favourites Channel Guide Record TV Web Browser Photos place: Music Videos...
Page 172 TV. Enter a keyword to search for Search media, various applications, Application service: You can Your Movie Samsung Apps or online information that experience various service by you can use on the TV. provided samsung. TV Screen: Displays the current channel.
Page 173 NOTE ● Configure the network setting before using Smart Hub. For more information, refer to “Network setting”. ● Unsupported fonts within the provider’s content will not display normally. ● Slow responses and/or interruptions may occur, depending on your network conditions. ●...
Page 174 ● If you experience a problem using a application, please contact the content provider. ● According to circumstances of the contents provider, an application’s updates or the application itself may be discontinued. ● Depending on your country’s regulations, some applications may have limited service or not be supported.
Page 175 Account Login For an application with multiple accounts, select Login to access the different accounts. Smart TV ID Press [Enter] Password Press [Enter] For a more enjoyable application experience, Remember my Smart TV id and password register and log in to your account. Login Cancel For instructions on creating an account, refer...
Page 176 1. Press the Red button in the home page. Smart Hub 2. Select by pressing the button. The account list appears. If you want to create an account, select Create Account then the create account OSD window will appear. 3. Select the desired ID, and the press the button.
Page 177 How to create a Smart Hub ID Before creating a Smart Hub ID, you should download the application first on the Samsung Apps. 1. Press the Red button. The Login screen appears. 2. Select Create Account. The Create Account screen will appear.
Page 178 Using the Keypad Pressing the TTX/MIX button on the remote while you are using the Screen Keypad enables you to change the text fields to lower case, capitalized case, upper case, numbers and icons. Using the Green button on the remote control to change the input mode. (T9/ ABC) You can change the language by using the TOOLS button.
Page 179 Method 1 4-1. For example, suppose that you want to input “105Chang”. 4-2. Press the TTX/MIX button on the remote 3 times to change the input mode from lower case to numbers. 4-3. Press the 1, 0 and 5 button in numerical order. 4-4.
Page 180 Method 2: Using the Keypad of T9 type. 4-1. For example, suppose that you want to input “105Chang”. 4-2. Press the TTX/MIX button on the remote 3 times to change the input mode from lower case to numbers. 4-3. Press the 1, 0 and 5 button in numerical order. 4-4.
Page 181 µ enter in symbol keypad screen. 6. Account created. You can use the services provided by all users of your Samsung TV with a single login by linking the users’ account to the TV ID. If you want to register a service site ID, select Register. Service Site list will appear on the ◀...
Page 182 7. Select of the Service Site you want, then press the button. Service ENTERE 8. Using number buttons, enter your application site ID and password. When done, select OK. 9. Registered successfully. If you add another service site, select Yes. then press the ENTERE button, go to step 7.
Page 183: Setting Up Smart Hub
❑ Setting up Smart Hub Settings ■ Configure Smart Hub settings from this screen. Settings Highlight Settings using the buttons Account Management and press the ENTERE button. Service Manager Reset ● Account Management Properties Register Service Account: Register login ◀ ▶...
Page 184 ● Service Manager Ticker Autorun: You can set Ticker Autorun to come on when powering on the application provides useful News, Weather, and Stock Market Ticker information. The Ticker application on Smart Hub must be downloaded to use this feature. Depending on your country, Ticker application may have a different service or...
Page 185 ● Reset: Resets settings to factory default settings. If you want reset Smart Hub Hub, Enter password. Smart ● Properties More: Display information about Smart Hub. Agreement: Display the Terms of Service Terms of Service Agreement. ◀ ▶ English...
Page 186: Using The Smart Hub Service
❑ Using the Smart Hub service Samsung Apps ■ Samsung Apps is a store for downloading applications to be used on Samsung TV/AV equipment. Users can enjoy a variety of contents such as videos, music, photos, games, useful information etc. using the downloaded applications.
Page 187 Using the colour buttons with the Samsung Apps. ● Red (Login): To log in to the internet Recommended Most downloaded Most recent Name What’s New? service. Video YouTube Game TV store Test User002 Sports Free ● Green (List View Thumbnail...
Page 188 Using the Samsung Apps by category The following categories are available: ● New?: Displays newly registered applications. What’s ● Video: Displays various video media such as movies, TV shows and short length videos. ● Game: Displays various games such as sudoku and chess.
Page 189 Other: Includes other miscellaneous services. ● Account: Displays the application list and your cyber cash balance. Starting in the middle of 2010 (US and Korea only), you can purchase cyber- cash for buying applications through tv.samsung.com. ● Help: If you have questions about Smart Hub, check this section first.
Page 190 Web Browser ■ For LED 6500 series and above (May not be available, depending on your country.) Using the Web Browser function provided by the SMART HUB, you can surf the Internet on your TV. ◀ ▶ English...
Page 191 When the Web Browser opens, the cursor is in Tab Mode. In Tab Mode, the cursor highlights text or objects, or surrounds them with a blue rectangle. To move the cursor in Tab Mode, use the buttons. Press ENTERE to select. To scroll the screen up or down, use the buttons.
Page 192 has a series of icons across the top of the screen. With these Web Browser icons, you can easily use the Browser. The icons are described below, starting with the icon on the far left of the screen. ● Back: Moves to the previous web page. If there is no saved previous web page, this icon will not work.
Page 193 / Stop: Refreshes the current page or stops the current connection from Refresh loading. Home: Goes to the URL you specified as your the home page. Zoom: You can select a zoom level of 50%, 75%, 100%, 125%, 150%, 200%, 400% Fit to Screen.
Page 194 When you highlight a page, the button appears on the right. Access the Options Options by selectng the Options button, and then pressing ENTERE. In the Options pop-up you can Delete the selected page from the history list, Delete All pages from the History list, or the selected page to Bookmarks.
Page 195 list: Displays images of open windows (the list). You can add Windows Windows the current page to the list (using Add a new page), select and access a page in the list, select and close a page in the list, or close all pages. The selected page is the enlarged page in the Centre.
Page 196 Using the Coloured and function buttons with the Web Browser ● Red (Back): Moves to previous page. If there is no saved previous web page, this button will not work. ● Green (Zoom): You can select a screen size of 50%, 75%, 100%, 125%, 150%, 200%, 400% Fit to...
Page 197 ● TOOLS (Options): Displays the icons from the top of the page in a toolbar in the middle of the screen. Press RETURN to close. ● (Scroll Up / Down): You can scroll the page up or down. ●  ●...
Page 198 ● Tools: Provides an easy-to-read page by enlarging the main text. Reading ● Clean Site: When Clean Site is on, you can only access the web pages registered in Site. Use Clean Site to restrict your children’s access to Clean appropriate web pages.
Page 199 ● Site: Lets you add the currently displayed web site to the Clean Add Current Site list. Manage: Lets you key in URLs to add to the List and Clean Site Clean Site delete sites from the Clean Site List. If you turn Clean Site on and have not added any sites to the...
Page 200 ● Option: You can configure options. Web Browser Set as homepage: You can set the home page. – Most visited: Set the most frequently visited URL as the home page. – Current Page: Sets the current page as the home page. –...
Page 201 – Ad Blocker (On / Off): Turns the on or off. Ad Blocker – Block current page: Adds the current page to the blocked list. – Manage blocked sites: Display the Advertisement Block Site screen. You can add a website for which advertisements Management should be blocked by directly keying in the URL, or you can delete a website from the list.
Page 202 Encoding: You can set the Encoding setting for webpages to Automatic or Manual. – Auto select (On / Off): Select the Encoding settings for webpages automatically. – Settings: Select the Encoding settings for webpages manually. Select an encoding format from the encoding format list. Pointer: You can set the speed of the cursor when the cursor is set to Pointer Mode.
Page 203 Communicate with people around the world! ● The displayed image may differ depending on the model. For more information, download the Skype ◀ ▶ user's manual from “www.samsung.com". Other company's TV Cameras are not compatible with Skype on your TV. English...
Page 204 [Legal Statement] Due to the various capabilities of products featuring the Samsung Smart Hub - Content Service, as well as limitations in the available content, certain features, applications, and services may not be available on all devices or in all territories.
Page 205 IS WITH YOU. THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND ANY CONTENT ◀...
Page 206 ▶ interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability.
Page 207: About Allshare
❑ About AllShare™ AllShare™ connects your TV and compatible Samsung mobile phones / devices through a network. You can play media contents including videos, photos and music saved on your mobile phones or the other devices (such as your PC) by controlling them on the TV via the network.
Page 208: Setting Up Allshare
❑ Setting Up AllShare™ → → → MENUm Network AllShare Settings ENTERE AllShare Settings ■ ● Media (On / Off): Enables or disables the media AllShare Settings function. When the media function is on, Media Media contents play can be controlled by a mobile phone or other devices that support DLNA DMC.
Page 209 Media ■ Shows a list of mobile phones or connected devices which have been set up with this TV for using the Media function. The Media function is available in all devices which support DLNA DMC. ● Allowed / Denied: Allows/Blocks the the devices. ●...
Page 210 Using the Media Function An alarm window appears informing the user that the media contents (videos, photos, music) sent from a mobile phone will be displayed on your TV. The contents are played automatically 3 seconds after the alarm window appears. If you press the RETURN or EXIT button when the alarm window appears, the media contents are not played.
Page 211 ● To turn off the media contents transmission from the mobile phone, set Media in the AllShare Settings. ● Contents may not be played on your TV depending on their resolution and format. ● ENTERE buttons may not work depending on the type of media content.
Page 212 What is Anynet+? Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
Page 213 For the method of connecting external devices, refer to the supported user manual. NOTE ● Connect the Optical cable between the DIGITAL AUDIO OUT (OPTICAL) jack on your TV and the Digital Audio Input on the Home Theatre. ● When following the connection above, the Optical jack only outputs 2 channel audio.
Page 214 ● You can connect only one Home Theatre. ● You can connect an Anynet+ device using the HDMI cable. Some HDMI cables may not support Anynet+ functions. ● Anynet+ works when the AV device supporting Anynet+ is in the standby or on status.
Page 215 Anynet+ Menu The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+ Menu Description View TV Changes Anynet+ mode to TV broadcast mode. Device List Shows the Anynet+ device list. Recording: (*recorder) Starts recording immediately using the recorder.
Page 216 Anynet+ Menu Description (device_name) Title Menu Shows the title menu of the connected device. E.g. If a DVD recorder is connected, the title menu of the DVD recorder will appear. Depending on the device, this menu may not be available. Stop Recording: (*recorder) Stops recording.
Page 217: Anynet
❑ Setting Up Anynet+ → → → MENUm System Anynet+ (HDMI-CEC) ENTERE Anynet+ (HDMI-CEC) (Off / On) ■ To use the Anynet+ Function, Anynet+ (HDMI-CEC) must be set to On. When the Anynet+ (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated.
Page 218 Auto Turn Off (No / Yes) ■ Setting an Anynet+ Device to turn off automatically when the TV is turned off. Auto Turn Off is set to Yes, running external devices will turn off at the same time as the TV powers off. However, a device may not turn off if recording is in progress.
Page 219: Switching Between Anynet+ Devices
❑ Switching between Anynet+ Devices 1. Press the TOOLS button to select Anynet+ (HDMI-CEC). And then press the ENTERE button to select Device List. If you cannot find a device you want, select Refresh to refresh the list. 2. Select a device and press the ENTERE button.
Page 220 ● Switching to the selected device may take up to 2 minutes. You cannot cancel the operation during the switching operation. ● If you have selected external input mode by pressing the SOURCE button, you cannot use the Anynet+ function. Make sure to switch to an Anynet+ device by using the Device List.
Page 221: Listening Through A Receiver
❑ Listening through a Receiver You can listen to sound through a receiver (i.e Home Theatre) instead of the Speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. If your receiver supports audio only, it may not appear in the device list. The receiver will work when you have properly connected the optical in jack ◀...
Page 222 Using the ARC function You can listen to sound through a receiver connected HDMI cable without the need for a separate optical cable. 1. Select and set to On. Receiver 2. Press the EXIT button to exit. To use the ARC function, a receiver which supports the HDMI-CEC and ARC features must be connected to the HDMI IN 2 (ARC) port.
Page 223: Using The Media Contents
❑ Using the Media Contents Enjoy photos, music and/or movie files saved Search Your Video Samsung Apps on a USB Mass Storage Class (MSC) device. 1. Press the SMART HUB button. 2. Press the button to select Favourites Channel Guide...
Page 224 ❑ Connecting a USB Device 1. Turn on your TV. TV Rear Panel 2. Connect a USB device containing recorded tv, photo, music and/or movie files to the USB port on the back or side panel of the USB Drive 3.
Page 225 ❑ Connecting to the PC through network You can play pictures, music and videos saved on your PC through a network connection in the SMART HUB mode. 1. For more information on how to configure your network, refer to “Network Menu”.
Page 226 2. Using a LAN cable, connect between the external modem and the PC onto which the AllShare PC Software will be installed. ● You can connect the TV to the PC directly without connecting it through a Sharer (Router). ◀ ▶...
Page 227 Functions that are not supported when connecting to a PC through a network: ● Background Music Background Music Setting functions. ● Sorting files by preference in the Photos, Music, and Videos folders. ● (REW) or (FF) button while a movie is playing. �...
Page 228 When you use media contents mode through a network connection, depending on the functions of the provided server: ● The sorting method may vary. ● function may not be supported. Scene Search ● The Resume, which resumes playing of a video, may not be supported. –...
Page 229 Before using media contents functions... It might not work properly with unlicenced multimedia files. Need-to-Know List before using media contents ● MTP (Media Transfer Protocol) is not supported. ● The file system supports FAT16, FAT32 and NTFS. ● Certain types of USB Digital camera and audio devices may not be compatible with this TV.
Page 230 ● Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. ● Connect a USB HDD to the dedicated USB 1 (HDD) port.
Page 231 ● MP3 files with DRM that have been downloaded from a non-free site cannot be played. Digital Rights Management (DRM) is a technology that supports the creation, distribution and management of the content in an integrated and comprehensive way, including the protection of the rights and interests of the content providers, the prevention of the illegal copying of contents, as well as managing billings and settlements.
Page 232 ● If the TV has been no input during time set in Time, the Auto Protection Screensaver will run. ● The power-saving mode of some external hard disk drives may be released automatically when connected to the TV. ● If a USB extension cable is used, the USB device may not be recognized or the files on the device may not be read.
Page 233 Screen Display Move to the file you desired using the up/down/right/left buttons and then press the ENTERE (Play) button. The file is played. � Home: Return to content Music Device name: Displays a home. connected device name. Change Content/Device: Upper Folder Sweet Candy Changes the content type or connected device.
Page 234: Recorded Tv
If you format the device, all files will be deleted. Before formatting your device to the tv, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data ◀...
Page 235 Timer Recording Schedule Manager) ■ SMART HUB → → Schedule Manager ENTERE Allows you to make a reservation to record a program scheduled for broadcast. Set the current time first to use this function. Using the Timer Recording function (digital channels only) 1.
Page 236 3. Press the button to select the Timer Recording. We recommend using a USB HDD with at least 5400 rpm, but a USB HDD of RAID type is not supported. A USB storage device cannot record until it completes the Device Performance Test.
Page 237 To record a current broadcasting program Allows you to record a program currently being broadcasted. Set the current time first to use this function. 1. When you watch a broadcast program, press the (REC) button on the � remote to record. A pop up window will appear. We recommend using a USB HDD with at least 5400 rpm, but a USB HDD of RAID type is not supported.
Page 238 Using the Timeshift function If you missed a live broadcast, you can see from the recorded broadcast using this feature. 1. When you watch a broadcast programme, press the (Play) button on the � remote to start the Timeshift function. 2.
Page 239 mode operates for a maximum of 90 minutes. Timeshift After the Timeshift mode function has run for the maximum time, the time information will be fixed to “01:30:00”. function is not supported for analogue channels. Timeshift functions are disabled for channels locked with Timeshift Channel Lock.
Page 240 Before using the Timeshift and a record function... Recorded videos are DRM (digital rights management) protected and cannot be played on a PC or other TVs. Note that files saved on the TV cannot be used after the main board is changed. NOTE ●...
Page 241 ● If the 5% free memory space limit of the USB storage device is reached, the current recording process will be closed. ● When recording is performed by both the PVR (Personal Video Recorder) function and a device that supports the HDMI-CEC feature, recording by the PVR function takes precedence.
Page 242 ● If the USB device has failed the Test, the USB device Device Performance must go through the Device Format Device Performance Test again before you record with the or Channel. Guide ● Timeshift functions can only be used with a USB storage device that completed the Device Performance Test.
Page 243 ● If you press (REC) on the remote control while the screen is Channel � being displayed or record with Timer Recording, the TV may start or stop recording 1 or 2 seconds later than you intended due to the time needed to process the command.
Page 244 Playing Recorded TV Program 1. Press the button to select the desired file in the file list. 2. Press the ENTERE button or (Play) button. � ● The selected file is displayed on the top with its playing time. ● During playing the recorded TV program, you can search using the button.
Page 245: Videos
Videos ■ SMART HUB → → Videos ENTERE Playing Video 1:02:15 / 2:04:10 3/15 1:02:15 / 2:04:10 1. Press the button to select the desired file in the file list. 2. Press the ENTERE button or (Play) � button. ◀ ▶...
Page 246 ● The selected file is displayed on the top with its playing time. ● If video time information is unknown, play time and progress bar are not displayed. ● During playing the video, you can search using the button. ● You can use (REW) and (FF) buttons during playback.
Page 247 In this mode, you can enjoy movie clips contained on a Game, but you cannot play the Game itself. ● Supported Subtitle Formats Name File extension Format MPEG-4 time-based text .txt SAMI .smi HTML SubRip .srt string-based SubViewer .sub string-based ◀...
Page 248 ● Supported Video Formats Frame rate Bit rate File Extension Container Video Codec Resolution Audio Codec (fps) (Mbps) DivX 3.11 / 4.x / 5.1 / 6.0 1920x1080 6 ~ 30 MP3 / AC3 XviD 1920x1080 6 ~ 30 *.avi / LPCM / H.264 BP / MP / HP 1920x1080 6 ~ 30...
Page 249 Frame rate Bit rate File Extension Container Video Codec Resolution Audio Codec (fps) (Mbps) H.264 BP / MP / HP 1920x1080 6 ~ 30 ADPCM / *.3gp 3GPP AAC / HE- MPEG4 SP / ASP 1920x1080 6 ~ 30 MPEG1 352x288 24 / 25 / 30 AC3 / MPEG...
Page 250 Other Restrictions NOTE ● Video content will not be played, or not be played correctly, if there is an error in the content or the container. ● Sound or video may not work if the contents have a standard bitrate/frame rate above the compatible Frame/sec listed in the table above.
Page 251 Video Decoder Audio Decoder • • Supports up to H.264, Level 4.1 Supports up to WMA 7, 8, 9, STD • • H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 WMA 9 PRO does not support 2 channel excess and AVCHD are not supported.
Page 252 Playing movie file continuously (Resume Play) If you exit the playing Videos function, it can be played later from the point where it was stopped. Resume function does not support multiple users. (It will have only memorised the point where the most recent user stopped playing.) 1.
Page 253: Music
Music ■ SMART HUB → → Music ENTERE Playing Music Music Playlist 13/30 Music_1 Singer I Love You 1. Press the button to select the Music_2 Ming Singer Music_3 Love Singe R&B desired music file in the file list. Love 2011-01-01 Ming usic_4...
Page 254 Creating My Playlist 1. On the Music screen in the SMART HUB menu, press the button to select Edit Mode, and then press the ENTERE button. 2. Press the button to select the tracks you want to add and press the ENTERE button.
Page 255 4. Press the button. The message ENTERE Selected items added to My Playlist. is displayed. 5. The newly created or updated playlist will be in the main page. Music Playing My Playlist Select the My Playlist folder and it will play automatically. Press the button to select a different music file within the play list.
Page 256 Playing the selected music files 1. On the Music screen in the SMART HUB menu, press the button to select Edit Mode, and then press the ENTERE button. 2. Press the button to select the desired music file in the file list, and then ENTERE button.
Page 257 NOTE ● The check box mark appears to the left of the selected files. ● To select all the files in the current page, select Select All at the top. ● To cancel a selection, press the ENTERE button again. 3.
Page 258: Photos
Photos ■ SMART HUB → → Photos ENTERE Viewing a Photo (or Slide Show) Normal Friends.jpg 1024 X 768 2011/01/03 1. Press the button to select the desired file in the file list. 2. Press the ENTERE button. ● When you press the (Play) button �...
Page 259 Music files can be automatically played during the slide show if the Background is set to On. Music cannot be changed until the BGM has finished loading. Background Music ◀ ▶ English...
Page 260 ❑ Media Contents - Additional Function Sorting the file list To sort files in the file list, select the Sorting by using the button. And then press the ENTERE button. Recorded Category Operations Videos Music Photos Displays the whole folder. You can view the file name and thumbnail by Folder View >...
Page 261 Recorded Category Operations Videos Music Photos Earliest Sorts and shows files by the earliest > > > Date date. Sorts the music file by artist in Artist > alphabetical order. Sorts the music file by album in Album > alphabetical order. Genre Sorts music files by the genre.
Page 262 Videos / Music / Photos Play Option menu The following functions are enabled during playback. Recorded Category Operations Videos Music Photos Return to the file list. List > > > > Previous / Next Go to previous / next photo file. >...
Page 263 Recorded Category Operations Videos Music Photos You can search the movie using Time Search > buttons at intervals of 10 seconds. You can view a subtitle. You can select Subtitle a specific language if the subtitle file > > contains multiple languages. You can play movie and music files Repeat Mode >...
Page 264 Recorded Category Operations Videos Music Photos Displays the Subtitle Setting. You can Subtitle Setting > > set up a subtitle option. You can start or stop. Alternatively, the Play / Pause (Play) or (Pause) button on the � � > >...
Page 265 Recorded Category Operations Videos Music Photos Background You can start or stop a background > Music On music. You can set and select background Background music when watching a photo file or > Music Setting slide show. You can zoom into images in full Zoom >...
Page 266 ■ Data Service for Italy Allows the user to use information (text, still images, graphics, documents, software, etc.) transmitted via broadcast media. Auto Run Data Service (On / Off) Sets whether or not to automatically run data service. Auto Run Data Service automatically runs data service without user intervention.
Page 267 Using Data Service If the channel you are currently watching provides data service, you can enjoy a variety of data services by pressing the or red button. Provided Data Service information may vary depending on broadcast. While using data service, changing the channel using the numeric buttons may not be possible depending on the service.
Page 268 2. Press the red button. The data service screen will be displayed. 3. Move to a desired option by pressing the button on the data service screen and then press ENTERE. The selected service will be started. If a Colour button of a certain function appears on the screen, you can use the offered function by pressing the corresponded button.
Page 269 Main Data Service buttons and their functions Button Operation Displays the Data Service list and immediately starts Data Service. (Data Service) RETURNR Returns to the previous screen. Perform functions corresponding to each Colour button image displayed on the screen during Data Service.
Page 270 Switches to teletext mode or Returns to the previous screen. TTX/MIX Operations may differ depending on the service provider. Moves the Data Service menu up, down, left and right. ENTERE Runs a selected item. Stops a running EXITe Data Service. ◀...
Page 271 HbbTV for France / Germany You will be able to access services from entertainment providers, online providers and CE manufactures through the HbbTV. This service may be supported in other countries. Some broadcating may not support the HbbTV. 1. HbbTV is turned off by default. To use HbbTV, go to →...
Page 272 5. If the current channel is compatible with both the HbbTV and non-HbbTV text- input modes, activate TTX by pressing the TTX key twice. ● When the screen indicates (with the red button, etc.) that HbbTV is being accessed. ● Press the TTX button once to enter the HbbTV text-input mode.
Page 273: Other Information
Other Information ❑ Troubleshooting ■ Troubleshooting for SMART HUB Problem Possible Solution Some application contents only The Application content language may be different from the appear in English. How can I change application user interface language. the language? The ability to change the language depends on the service provider.
Page 274 Web Browser ■ 1. To open Browser, press the SMART HUB button. And select Browser by using buttons, and then press the ENTERE. may be displayed differently with PC. Web Browser 2. The is not compatible with a Java application. Web Browser 3.
Page 275 7. Scrolling a web page that allows only part (and not the whole) of the page to be scrolled may cause corrupted characters. 8. ActiveX is not supported. 9. Some options cannot be accessed in Tab mode. (To access such options, switch to Pointer mode.) 10.
Page 276 13. Copy and Paste are not supported. 14. When writing emails or posting messages, some functions (Such as changing the size or colors.) may not be supported. 15. The number of bookmarks and logs that can be saved is limited. 16.
Page 277 22. If you import the bookmark file to a Computer from a TV, the bookmark file will be saved in “Samsung SmartTV Bookmark” folder. 23. If the time is not set in the menu (System → Time → Clock), the history ◀...
Page 278 24. Visited web site history is saved in chronological order and It will be removed from the list according to oldest page accessed. 25. Some video or audio content may not play during Flash playback depending on the video / audio codec supported. ◀...
Page 279 ■ Troubleshooting for Anynet+ Problem Possible Solution • Check if the device is an Anynet+ device. The Anynet+ system Anynet+ does not work. supports Anynet+ devices only. • Only one receiver (home theatre) can be connected. • Check if the Anynet+ device power cord is properly connected. •...
Page 280 Problem Possible Solution • Check if the Anynet+ device is properly connected to the TV and I want to start Anynet+. check if the Anynet+ (HDMI-CEC) is set to in the Anynet+ Setup menu. • Press the TOOLS button to display the Anynet+ menu and select a menu you want.
Page 281 Problem Possible Solution • Check whether or not the device supports Anynet+ functions. The connected device is not displayed. • Check whether or not the HDMI cable is properly connected. • Check whether is set to in the Anynet+ Anynet+ (HDMI-CEC) setup menu.
Page 282 If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www.samsung.com”, then click on Support. Issues Solutions and Explanations Picture Quality First of all, please perform the Picture Test and confirm that your TV is properly displaying test image.
Page 283 Issues Solutions and Explanations • If you have an analogue cable/set top box, upgrade to a digital set top The TV image does not look as good as it did in the store. box. Use HDMI or Component cables to deliver HD (high definition) picture quality.
Page 284 Issues Solutions and Explanations • If you’re using a component connection, make sure the component Colour is wrong or missing. cables are connected to the correct jacks. Incorrect or loose connections may cause colour problems or a blank screen. • Adjust the Picture options in the TV menu (go to...
Page 285 Issues Solutions and Explanations Sound Quality First of all, please perform the to confirm that your TV audio Sound Test is properly operating. (go to MENU - Support Self Diagnosis Sound Test) If the audio is OK, the sound problem may caused by the source or signal. •...
Page 286 Issues Solutions and Explanations • Check the cable connections. Make sure a video cable is not connected The speakers are making an inappropriate noise. to an audio input. • For antenna or cable connections, check the signal strength. Low signal level may cause sound distortion.
Page 287 Issues Solutions and Explanations • Check cable connections (remove and reconnect all cables connected to There is no picture/Video. the TV and external devices). • Set your external devices’ (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.
Page 288 PC. Network Connection ◀ ▶ • The Samsung Wireless USB dongle is required to use a wireless network. The wireless network connection for LED6490 and under failed. • Make sure the Network Connection is set to Wireless. •...
Page 289 Issues Solutions and Explanations Recording / Timeshift • See the manual for the USB device to check that the USB device supports recording. • If the USB device has a lock, ensure it is off. The USB device is not recognized or a Device •...
Page 290 Issues Solutions and Explanations • Check that a USB device is connected. • Check that the channel is a recordable digital channel. The recording function does • If the signal is weak or does not exist, the recording function will not work.
Page 291 Issues Solutions and Explanations • A scheduled recording is disabled for certain operations (formatting, A scheduled recording has failed. performance test, error checking, deleting) that access the file system of a USB device. • If there is no USB device connected, the TV will not record even if the scheduled time is reached.
Page 292 Programme the Cable/Set top box remote control to operate the TV. The cable/set top box remote control doesn’t turn the TV on Refer to the Cable/Set user manual for the SAMSUNG TV code. or off, or adjust the volume. English...
Page 293 Issues Solutions and Explanations • Check the supported resolution of the TV, and adjust the external A “Mode Not Supported” message appears. device’s output resolution accordingly. • This smell is normal and will dissipate over time. There is a plastic smell from the •...
Page 294 Issues Solutions and Explanations • If the TV is in the mode, it will reset audio and picture Store Demo Your settings are lost after 30 minutes or every time the TV is settings every 30 minutes. Change the settings from Store Demo mode turned off.
Page 295 Issues Solutions and Explanations • If you are using a CAM CARD (CI/CI+), check that it is installed into the The message “Scramble signal” or “Weak Signal/No Signal” common interface slot. appears. • If there is still a problem, pull the CAM CARD out of the TV and insert it into the slot again.
Page 296: Connecting To A
❑ Connecting to a COMMON INTERFACE slot ■ Attaching the CI Card Adaptor Attach the adapter as shown below. To connect the CI CARD Adapter, follow these steps. TV Rear We recommend attaching the adapter before installing 1. Insert the CI CARD Adapter into the two holes on the product 1 . Please find a two holes on the rear of the TV.
Page 297 2. Connect the CI CARD Adapter into the COMMON INTERFACE port on the product 2 . 3. Insert the “CI or CI+ CARD” We recommand that you insert the CI card before you mount the TV on a wall. It may be difficult to insert after the mounting.
Page 298 Using the “CI or CI+ CARD” ■ To watch paid channels, the “CI or CI+ CARD” must be inserted. ● If you don’t insert the “CI or CI+ CARD,” some channels will display the message “Scrambled Signal”. ● The pairing information containing a telephone number, the “CI or CI+ CARD”...
Page 299 NOTE ● You must obtain a “CI or CI+ CARD” from a local cable service provider. ● When removing the “CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI or CI+ CARD” may cause damage to it. ●...
Page 300: Teletext Feature
❑ Teletext Feature (depending on the country) The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed.
Page 301 Activates the Teletext mode for the current channel. Press the button twice to overlap the Teletext mode with the current broadcasting screen. Press it one more time to exit (Teletext on / mix /off) teletext. Stores the Teletext pages. (store) Displays the teletext on the upper half of the screen in double-size.
Page 302 Colour buttons (red, If the FASTEXT system is used by the broadcasting company, the different topics on a green, yellow, blue) Teletext page are colour-coded and can be selected by pressing the coloured buttons. Press the colour corresponding to the topic of your choice. A new colourcoded page is displayed.
Page 303 Displays the next Teletext page. (page up) Displays the previous Teletext page. (page down) Displays the index (contents) page at any time while you are viewing Teletext. (index) Displays the hidden text (answers to quiz games, for example). To display the normal screen, press it again.
Page 304 Typical Teletext page Part Contents Selected page number. Broadcasting channel identity. ◀ ▶ Current page number or search indications. Date and time. Text. Status information. FASTEXT information. English...
Page 305 ❑ Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system <TV Rear> when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer.
Page 306 To lock the product, follow these steps: 1. Wrap the Kensington Lock cable around a large, stationary object such as desk or chair. 2. Slide the end of the cable with the lock attached through the looped end of the Kensington Lock cable.
Page 307: Licence
❑ Licence TheaterSound, SRS and symbol are trademarks of SRS Labs, Inc. TheaterSound technology is incorporated under license form SRS Lab, Inc. Manufactured under licence from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under licence under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;...
Page 308 Trademark: Rovi and Rovi On Screen Guide are trademarks of Rovi Corporation and / or its subsidiaries. License: The Rovi On Screen Guide system is manufactured under license from Rovi Corporation and / or its subsidiaries. Patent: The Rovi On Screen Guide system is protected by patents and patent applications filed in the US, Europe, and other countries including one or more of the United States patents 6,396,546;...
Page 309 DivX Certified® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certified® and associated logos are trademarks of DivX, Inc. and are used under licence. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified® device that plays DivX video.
Page 310 e-Manual Guide ❑ How to view the e-Manual You can read the introduction and instructions about the TV features stored in your TV. Basic Features Changing the Preset Picture Mode → → → MENUm Support e-Manual Adjusting Picture Settings ENTERE Changing the Picture Size Changing the Picture Options Setting up the TV with Your PC...
Page 311 Screen Display Current on-air Change the category. broadcasting. Press button to select category you Basic Features want. Changing the Preset Picture Mode Displays the sub-menu list. Adjusting Picture Settings Press ENTERE button to select sub-menu you want. Changing the Picture Size ◀...
Page 312: E-Manual Guide
Using the Help Display the e-Manual Guide & the Product Guide by pressing Help. ❑ How to view the e-Manual You can read the introduction and Sync media from multiple devices with AllShare instructions about the TV features stored in Basic Features AllShareTM syncs your digital devices so you can enjoy music, movies and photos from your PC,...
Page 313 How to toggle between the e-Manual and the corresponding menu(s). Picture ❑ Changing the Preset Picture Mode Picture Mode Standard → → → MENUm Picture Picture Mode ENTERE ■ Picture Mode Backlight Select your preferred picture type. ● Dynamic: Suitable for a bright room. E-MANUAL Contrast ●...
Page 314 Viewing the Contents ❑ Changing the Preset Picture Mode Contents Area: You can view → → → MENUm Picture Picture Mode ENTERE the corresponding contents, if Picture Mode ■ you selected a sub-menu. To Select your preferred picture type. move previous or next page, ●...
Page 315 Using the Zoom mode When you view the e-Manual instruction, select ❑ Changing the Preset Picture Mode to magnify the screen. You can scroll → → → Zoom MENUm Picture Picture Mode ENTERE Picture Mode ■ through the magnified screen by using the Select your preferred picture type.
Page 316 How to search a keyword by using index page 1. If you want to search a keyword, select Index to open the Index screen. 2. Press the button to select a character order you want, and then press button. ENTERE 3.
Page 317 Product Guide Cinema-quality 3D experience 3-Dimensional TVs add new depth and dimension to create larger-than-life experiences. 3D Active Glasses sync up with the 3D TV to produce 3D images that virtually leap off the screen. Favourite shows can even be transformed to 3D in real time for the ultimate ▶...
Page 318 Sync media from multiple devices with AllShare AllShare™ syncs your digital devices so you can enjoy music, movies and photos from your PC, camera and mobile devices, on your larger TV screen. Connects you to multiple PCs, as well. ◀ English...

Samsung UE-37D6500 Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Samsung UE-37D6500

Summary of Contents for Samsung UE-37D6500

Table of Contents
