Alula RE210P Quick Start Manual

Resolution Compatibles
The Indoor Motion Sensor
or when the external contact is opened. It is battery
powered and requires no installation tools. A Pyroflex
sensor with HighBar
leading pet immunity and catch performance.

Features

• Industry-leading pet immunity and catch performance
• Supports both motion zone and an external contact zone
• Mountable on walls or in corners
• 5 year warranty

Enroll

by placing the panel into wireless enrollment mode and
then tripping the tamper three times.

Enrollment Tips

• Program as an RF type (Supervised RF)
• Loop 1 = Motion
• Loop 2 = External Contact
• Loop 4 = Tamper

Install

using the included 3M VHB
sensor on a wall or in a corner. The tape should be applied
to the back when wall mounting or to the back bevels when
corner mounting. Alternatively, screw mounting can be
done by punching out the screw mounting holes.

Installation Tips

• Mount 7.5 to 9.5 feet from the floor for an
optimal balance between catch performance
and pet immunity.
• Remove the cover and circuit board before
trying to punch out the screw mounting holes.
• Ensure the bug foam stays intact and
snug around the IR sensing element when
re-installing the circuit board.
External Contact (not evaluated by ETL)
• Use a normally-closed contact because the
motion sensor will transmit an alarm when it
sees the external contact open.
• Do not use end-of-line resistors.
Verify proper enrollment and operation using your control panel's installation manual.
RE210P Indoor Motion Sensor
-Pet Immune Honeywell
alarms when motion is sensed
signal processing allows for industry-
™
tape to adhere the motion
®
Compatible
™
™
Mounting Screw Holes
Ceiling
Floor
I
