ImageQuest L70A
TFT LCD Color Monitor
User's Guide
Click
www.imageQuest.co.kr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L17C0D080 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai L17C0D080

Summary of Contents for Hyundai L17C0D080

  • Page 1 NEXT ImageQuest L70A TFT LCD Color Monitor User's Guide Click www.imageQuest.co.kr...
  • Page 2 BACK U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION NEXT RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Kind of equipment COLOR MONITOR Type-Designation L17C0D080 to which this declaration relates is in conformity with the following standard(s) or other normative document(s) Safety : EN 60950 : 1992 + A1, A2, A3, A4, A11...

  • Page 4: Table Of Contents

    BACK L70A 17" TFT LCD Color Monitor NEXT Contents 1. Introduction ........1/22 2. Safety Information ......1/22 3. Installing the monitor ....4/22 3-1. Packing List .........4/22 3-2. Selecting a suitable location ....5/22 3-3. Connecting the monitor .....5/22 USB Hub ..........9/22 3-4. Setting the refresh rate ......8/22 Preset Timing Table ......9/22 3-5.

  • Page 5: Introduction

    BACK L70A 17" TFT LCD Color Monitor NEXT 1. Introduction This manual contains instructions for installing and operating ImageQuest L70A. ImageQuest L70A is a highly ergonomic color display unit. • 17" viewable SXGA LCD • High quality screen re-scaling capability •...
  • Page 6 BACK L70A 17" TFT LCD Color Monitor NEXT Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~35°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.
  • Page 7 BACK L70A 17" TFT LCD Color Monitor NEXT Cleaning and Maintenance • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning. •...

  • Page 8: Installing The Monitor

    BACK L70A 17" TFT LCD Color Monitor NEXT 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Japan Power Cord Signal Cable American/Canada Europe DVI-D Cable (Option) South Africa Australia USB Cable Korea AC/DC Power adapter Compact Disc Above power cord can be changed upon different voltage areas.

  • Page 9: Selecting A Suitable Location

    BACK L70A 17" TFT LCD Color Monitor NEXT 3-2. Selecting a suitable location • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. • Place the monitor in a position where no light shines directly onto or is reflected on the screen.
  • Page 10 BACK L70A 17" TFT LCD Color Monitor NEXT Turn on the power to the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information. 15 pin D-sub cable (Analog RGB) DVI-D cable (Digital TMDS) 6/22...

  • Page 11: Usb Hub

    BACK L70A 17" TFT LCD Color Monitor NEXT USB hub The USB hub(Bus-powerd mode hub) have 1 upstream port and 2 downstream ports. The upstream port can be connected to the root hub of host PC or other downstream port. Two(2) downstream ports allow to connect another USB device such as USB mouse, joystick, printer etc.

  • Page 12: Setting The Refresh Rate

    BACK L70A 17" TFT LCD Color Monitor NEXT LED Indicator Soft Power Switch 3-4. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98. rate Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’...

  • Page 13: Preset Timing Table

    BACK L70A 17" TFT LCD Color Monitor NEXT Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed. ANALOG R.G.B INPUT The recommended setting is a resolution of 1280x1024 and a refresh rate of 60Hz.

  • Page 14: Vesa Mounting

    BACK L70A 17" TFT LCD Color Monitor NEXT DIGITAL R.G.B INPUT Resolution Horizontal Frequency Refresh rate 640 x 480 31.5 KHz 60 Hz 800 x 600 37.9 KHz 60 Hz 1024 x 768 48.4 KHz 60 Hz 1280 x 1024 63.9 KHz 60 Hz 3-5.
  • Page 15 BACK L70A 17" TFT LCD Color Monitor NEXT Desk Mount Wall Mount 11/22...

  • Page 16: Adjusting The Picture

    BACK L70A 17" TFT LCD Color Monitor NEXT 4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. In case of applying Analog RGB Input 1280X1024 V:60.0/H:63.9 BRIGHTNESS 12/22...
  • Page 17 BACK L70A 17" TFT LCD Color Monitor NEXT In case of applying Digital TMDS Input 1280X1024 V:60.0/H:63.9 BRIGHTNESS 13/22...

  • Page 18: Using The On Screen Display

    BACK L70A 17" TFT LCD Color Monitor NEXT 4-1. Using the On Screen Push the MENU button to call the OSD to the screen. The resolution and Display frequency are displayed at the top of the menu box for your information. Push the button to choose the item you want to adjust.

  • Page 19: Osd Adjustments

    BACK L70A 17" TFT LCD Color Monitor NEXT 4-3. OSD Adjustments The OSD adjustments available to you are listed below. BRIGHTNESS You can play the movie Adjust the brightness of the screen. file to see how to adjust the picture image by CONTRAST clicking each icon or title hereunder.
  • Page 20 BACK L70A 17" TFT LCD Color Monitor NEXT MISCELLANEOUS RECALL Recall the saved color data. OSD TIMER You can set the displayed time of OSD Menu window on the screen by using this adjustment. OSD POSITION Adjust the OSD menu's horizontal or vertical position on the screen. AUTO ADJUST You can adjust the shape of screen automatically at the full screen pattern.
  • Page 21 BACK L70A 17" TFT LCD Color Monitor NEXT CLOCK PHASE PHASE Adjust the noise of the screen image. CLOCK Adjust the horizontal size of the entire screen image. INPUT SELECT This menu used to choose the desired input signal source. There are two available signal source.

  • Page 22: Display Power Management

    BACK L70A 17" TFT LCD Color Monitor NEXT 5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power Your computer may have power management features which enable the computer consumption or monitor to enter a power saving mode when the system is idle.

  • Page 23: Troubleshooting

    BACK L70A 17" TFT LCD Color Monitor NEXT 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by reading followings. Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on.
  • Page 24 BACK L70A 17" TFT LCD Color Monitor NEXT Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section OSD shape or quality Adjustment(4-3).
  • Page 25 BACK L70A 17" TFT LCD Color Monitor NEXT Problem Possible solution The power LED is a LED Indicator can be orange color on changing of video mode or orange color Input Signal(D-sub/DVI). Check the Resolution and the frequency on the video part of your computer.

  • Page 26: Specifications

    BACK L70A 17" TFT LCD Color Monitor 7. Specifications 17"viewable, Diagonal, Pixel pitch 0.26 mm, AM-TFT Brightness 25msec, 250cd/m Response Time 25msec Display area 337.92 X 270.336 mm Number of color 16,2 million colors Input signals R.G.B Analog, Digital TMDS(DVI-D), Frequency rate Horizontal : 31.0 to 80.0KHz, Vertical : 56 to 75Hz Maximum bandwidth...
