High Resolution Camera
User Manual
HCD-6070R
HCV-6070R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCD-6070R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wisenet HCD-6070R

Summary of Contents for Wisenet HCD-6070R

  • Page 1 High Resolution Camera User Manual HCD-6070R HCV-6070R...
  • Page 2 High Resolution Camera User Manual Copyright ©2017 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we'll introduce our model description. ■ HCD-6070R/HCV-6070R SERIES • NTSC MODEL • PAL MODEL HCD-6070R HCD-6070RP HCV-6070R HCV-6070RP ■ MODEL DESCRIPTION •...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water on top of the camera. doing so may cause personal injury due to fire, electric shock, or falling objects. 7. Do not install the unit in humid, dusty, or sooty locations. doing so may cause fire or electric shock.
  • Page 6 safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
  • Page 7 important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.
  • Page 8 important safety instructions 17. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or near the kitchen table. This may cause damage to the product.

  • Page 9: Table Of Contents

    contents INTRODuCTION Features Components and Accessories Component names and functions INSTALLATION Before installation Installation Adjusting the monitoring direction for the camera CONNECTION Connecting to Monitor Connecting to Power Using Coaxial Communications CAMERA OPERATION Menu Configuration Menu Setup TROubLESHOOTING Troubleshooting SPECIFICATIONS Specifications Dimension English_9...

  • Page 10: Introduction

    introduction FEATuRES y High Resolution Use of a 2.1 mega pixel CMOS device provides clear pictures with a resolution of 1920x1080. y Excellent Sensitivity - Color : 0.11Lux (F1.6, 1/30sec) B/W : 0Lux(IR LED on) y SSNR4 Function High performance DSP Chip removes noises of GAIN resulting from the low light level and shows a vivid, high definition video even in the dark place.

  • Page 11: Components And Accessories

    COMPONENTS AND ACCESSORIES Check if the following items are included in the product package. <HCD-6070R> Camera Quick Manual Screws Template Video Output Cable English_11...
  • Page 12 introduction <HCV-6070R> Camera Quick Manual Template Tapping Screw Machine Screws L Wrench Card-type moisture Video Output Cable absorbent 12_ introduction...

  • Page 13: Component Names And Functions

    COMPONENT NAMES AND FuNCTIONS HCD-6070R ⓭ ⓬ ⓫ ❿ Dome Cover Shield Case Rotate base : control rotating angle of camera. Vari-focal Lens Module : 3.2 ~ 10mm (F1.6). Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.
  • Page 14 introduction HCV-6070R ⓬ ⓫ ❿ Dome Cover Rotate base : control rotating angle of camera. Vari-focal Lens Module : 3.2 ~ 10mm (F1.6). Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.

  • Page 15: Installation

    Before installing your camera, you have to adjust the lens focus, zoom, and switch settings. y y When installing your camera, don’t allow any person to approach the installation site. INSTALLATION Disassembling(HCD-6070R) 1. Use one hand to hold the camera’s bottom part and turn the cover counterclockwise with another hand to separate it.

  • Page 16: Installation

    Installation Disassembling(HCV-6070R) Using the L-wrench provided, loosen 3 screws by turning them counterclockwise and separate the dome cover. L Wrench Dome Cover 16_ Installation...
  • Page 17 Installation(HCD-6070R) 1. Attach the installation template to the selected area and punch 2 holes as shown in the fi gure. 케이블 구멍 2. Use the 2 supplied screws to fi x the camera to the 2 punched holes. y Set the <TOP FRONT> mark imprinted on the camera to face the direction of camera monitoring.
  • Page 18 Installation Installing the camera on a ceiling or wall(HCV-6070R) 1. Drill holes on the ceiling by matching to the holes on the case bed, and insert plastic anchors (HUD 5) (not included) fully into the holes. Fix the case bed on the ceiling by using screws .
  • Page 19 3. Adjust the lens in a desired direction by referring to the “Adjusting the monitoring direction for the camera”section. 4. Close the dome cover. To ensure waterproofing, tight up the fixing bolts using the L-wrench. Dome Cover L Wrench The installation should be done by qualified service personnel or system installers. If the ceiling material is not strong enough to hold the installation screws, the camera may fall off.

  • Page 20: Adjusting The Monitoring Direction For The Camera

    Installation ADJuSTING THE MONITORING DIRECTION FOR THE CAMERA <HCD-6070R> Tilt Lens rotation <HCV-6070R> Tilt Lens rotation 20_ Installation...
  • Page 21 ` Adjusting the monitoring direction You can adjust the camera direction only when the camera is fixed on the ceiling. Where, rotating the camera unit to the left or right is called Pan, adjusting the tilt is called Tilt, and turning the lens on its axis is called Rotation. y - The effective range of pan is a total of 350 degrees.

  • Page 22: Connection

    CONNECTING TO MONITOR Connect the Video OUT port on the rear panel of the camera to a AHD DVR. ALARM NETWORK BACKUP POWER AHD DVR HCD-6070R Monitor ALARM NETWORK BACKUP POWER AHD DVR HCV-6070R Monitor y As the connecting method varies with the instruments, refer to the manual supplied with the instrument.

  • Page 23: Connecting To Power

    CONNECTING TO POWER You can connect power as shown in the following figure. Power Input Terminal HCD-6070R Power Input Terminal HCV-6070R When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm...

  • Page 24: Using Coaxial Communications

    Be sure to connect power only after all the installation is complete. uSING COAXIAL COMMuNICATIONS y Coaxial Communications System y OSD Control method CAMERA MENU/ENTER UP KEY DOWN DOWN KEY LEFT LEFT KEY RIGHT RIGHT KEY ● : BNC HCD-6070R HCV-6070R 24_ connection...
  • Page 25 - Video Cable The camera's video output port is connected to the DVR with a BNC coaxial cable, shown below. Recommended Cable Distance Specification 500m 5C2V It is recommended that pure copper coax cable is used and not copper coated steel, as this will cause issues with the communication over the coaxial cable.

  • Page 26: Camera Operation

    ◦ SPECIAL DAY/NIGHT DEFOG PRIVACY ◦ ◦ MOTION RETURN ◦ ◦ ◦ EXIT SAVE NOT SAVE RESET MENu SETuP For function setting, you can use the function setting switch inside the dome cover. Function Setup switch <HCD-6070R> 26_ camera operation...
  • Page 27 MAIN SETuP  1. VIDEO FORMAT Select the Change the status function using 2. PROFILE bASIC using the Function the Function Setup switch. 3. WHITE bAL Setup switch. 4. EXPOSuRE 5. bACKLIGHT 6. SPECIAL 7. EXIT SAVE 1. Press the Function Setup switch. y Main SETUP menu is displayed on the monitor screen.
  • Page 28 camera operation PROFILE 1. When the SETUP menu screen is MAIN SETuP displayed, select ‘PROFILE’ by using 1. VIDEO FORMAT the Function Setup switch so that the  2. PROFILE bASIC arrow indicates ‘PROFILE’ . 3. WHITE bAL 2. Select a desired mode using the 4.
  • Page 29 White bal (White balance) Use the White Balance function to adjust the screen color. 1. When the SETUP menu screen is MAIN SETuP displayed, select ‘White Bal’ by using 1. VIDEO FORMAT the Function Setup switch so that the 2. PROFILE bASIC arrow indicates ‘White Bal’...
  • Page 30 camera operation EXPOSuRE 1. When the SETUP menu screen is displayed, select ‘EXPOSURE’ by using the Function Setup switch so that the arrow indicates ‘EXPOSURE’ . 2. Select a desired mode using the EXPOSuRE SETuP Function Setup switch.  bRIGHTNESS IIIIIIIIII IIIIIIIIII y bRIGHTNESS : Adjusts the video...
  • Page 31 y AGC (OFF/LOW/MIDDLE/HIGH/VERY HIGH) : The higher the gain level, the brighter the screen - but the greater the noise. y SSNR4 : This function reduces the background noise in a low luminance environment. - OFF : Deactivates SSNR4. Noise is not reduced. - ON : Activates SSNR4 so that noise is reduced.
  • Page 32 camera operation y HLC (High Light Compensation) : This function masks the strong light to minimize HLC SETuP white out due to over exposure and preserve much ▶ LEVEL M I D D L E of the on-screen details when the camera aims a LIMIT NIGHT ONLY strong light source.
  • Page 33 SPECIAL 1. When the SETUP menu screen is MAIN SETuP displayed, select ‘SPECIAL’ by using 1. VIDEO FORMAT the Function Setup switch so that the 2. PROFILE bASIC arrow indicates ‘SPECIAL’ . 3. WHITE bAL 2. Select a desired mode using the 4.
  • Page 34 camera operation - FONT COLOR : You can change the OSD font color. (White, Yellow, Green, Red, Blue) - LANGUAGE : You can select the menu language according to your requirements. - RETURN : Return to the SPECIAL menu. y COAX : You can select whether to use COAX communication. y IMAGE ADJ If the SPECIAL menu screen is displayed, use the Function Setup switch so that the ❶...
  • Page 35 y DAY/NIGHT: You can display pictures in color or in black and white. If the SPECIAL menu screen is displayed, use the Function Setup switch so that ➊ the arrow indicates ‘DAY/NIGHT’. Select a desired mode using the Function Setup switch according to the picture ➋...
  • Page 36 camera operation y DEFOG : You can use the defog mode to allow the camera to automatically detect the fog density of the screen and display a clear image despite smog, fog or general poor visibility. If the SPECIAL menu screen is displayed, use the Function Setup switch so that the ➊...
  • Page 37 y MOTION : This product generates signals each time an object movement is detected in the four areas of the screen so efficient monitoring can be achieved. If the SPECIAL menu screen is displayed, use the Function Setup switch so that the arrow ➊...
  • Page 38 camera operation - If there is little movement near the screen edge - If multiple movements keeps occurring randomly, such as scene switching or sudden light changes - If an object fixed in the same location keeps moving - Moving away from the camera or approaching the camera. Little location change on the screen.

  • Page 39: Troubleshooting

    troubleshooting TROubLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.

  • Page 40: Specifications

    specifications SPECIFICATIONS HCD-6070RN/HCD-6070RP HCV-6070RN/HCV-6070RP Video Imaging Device 1/2.8” 2M CMOS Total Pixels 1,945(H) x 1,109(V) 2.16M pixels Effective Pixels 1,945(H) x 1,097(V) 2.13M pixels Scanning System Progressive Scan Color : 0.11Lux (F1.6) (30IRE) Min. Illumination B/W : 0Lux(IR LED on) S / N Ratio 52dB (AGC off, Weight on) Video Output...
  • Page 41 HCD-6070RN/HCD-6070RP HCV-6070RN/HCV-6070RP Privacy Masking Off / On (8 zones rectangle) Gain Control Off / Low / Middle / High / Very High White balance ATW / Outdoor / Indoor(4,500K° ~ 8,500K°) / Manual / AWC (1,800K° ~ 10,500K°) Electronic Shutter Speed 1 sec ~ 1/12,000 sec Reverse Off / H-Rev / V-Rev / HV-Rev...

  • Page 42: Dimension

    DIMENSION Unit: mm (inch) <HCD-6070R> 42_ specifications...
  • Page 43 Unit: mm (inch) <HCV-6070R> English_43...
  • Page 44 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
