then fix the bracket by using the locking
pin provided. When extracting the win-
dow bracket and joining the two pieces
pay attention you do not cover the hole.
Other set-up methods:
• Thanks to the locking pin, it's possible to
use the window bracket also for sliding
windows. Position the hole of the bracket
so to allow a correct installation of the
exhaust hose (see figure D)
Keep the air hoses as short and free of
curves as possible to avoid constrictions.
French window
• After having screwed the window outlet
17
into the air exhaust hose
the French window slightly and position
the window outlet
E.
6
Pre p a r i n g f o r u s e
C
.
D
12
, open
17 as shown in figure
Keep the air hoses as short and free of
curves as possible to avoid bottlenecks.

SEMI-PERMANENT INSTALLATION

If required, your appliance can also be
installed semi-permanently (Fig. F).
11.8 in.
30 cm
Proceed as follows:
• Drill a hole (ø134 mm / 5,27 in.) in an out-
side wall or through a window pane.
Respect the height and dimensions of the
hole given in figures F and G.
NOTE: As special tools are required for instal-
lation, we suggest you have the appliance
installed by specialized personnel.
E
11.8 in.
30 cm
