- Page 1 26MMAS6064 1-866-661-1218 www.tsicustomerservice.com Twin-Star International, Inc. Delray Beach, FL 33445 26MMAS6064REV.1 MP#MYS...
- Page 2 Thank you for purchasing a Nous vous remercions d’avoir acheté Gracias por comprar un producto Twin-Star International product, un produit Twin-Star International, de Twin-Star International, designed in the U.S.A. We hope conçu aux États-Unis. Nous espérons diseñado en los E.U.A.
- Page 3 SERVICIO DEPENDABLE UN SERVICE À DE ATENCIÓN CUSTOMER LA CLIENTÈLE AL CLIENTE SERVICE FIABLE FIABLE ¿Tiene preguntas? Nuestro Centro Questions? Nos centres d’appels sont Questions? Our message centers de mensajes está disponible 7 días disponibles 7 jours sur 7 et 24 heures are available 7 days a week, 24 de la semana, 24 horas del día con sur 24 avec notre ligne d’assistance...
- Page 4 MAXIMUM LOAD 47.6 kg / 105 lb CHARGE MAXIMALE DE MAXIMUM LOAD 47.6 kg / 105 lb 13.6 kg / 30 lb CARGA MÁXIMA CHARGE MAXIMALE DE 47.6 kg / 105 lb 13.6 kg / 30 lb CARGA MÁXIMA 13.6 kg / 30 lb MAXIMUM LOAD 6.8 kg / 15 lb CHARGE MAXIMALE DE...
- Page 5 26MMAS6064 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
-
Page 6: Safety Information
SAFETY INFORMATION INFORMACIÓN DE INFORMATION DE SÉCURITÉ SEGURIDAD Please read and understand Assurez-vous de lire et de Lea y comprenda this entire manual before comprendre l’intégralité du completamente este manual attempting to assemble, présent manuel avant de tenter antes de intentar ensamblar, operate or install the product. - Page 7 HARDWARE/QUINCAILLERIE/FERRETERÍA [x12] [x2] PH-BKTWHT003 PH-SPNPCSPLB2 [x18] [x44] Ø8x30mm Ø3x12mm PH-SCRBLK007 PH-DWLNTL001 [x2] [x2] Ø4x15mm PH-SCRBLK009 PH-BKTBLK007 [x8] [x1] Ø4x50mm Touch-up Pen PH-SCRBLK006 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 8 HARDWARE/QUINCAILLERIE/HARDWARE Model: TS-0843-0200/0261/0287/0303 Ref: Transformer Date: 26, Apr, 2016 Y17-OP-001 Y16-RC-0843 Y16-PC-0843V1 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 9 [x8] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 10 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 11 [x8] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 12 [x8] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 13 [x24] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 14 [x8] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 15 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 16 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 17 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 18 NOTE: IF YOU WILL BE USING THE 26MMAS6064 (OPTION 1), CONTINUE FOR FURTHER INSTRUCTIONS. IF YOU WILL BE USING THE 26MMAS6064 (OPTION 2), PLEASE SKIP TO STEP 13. NOTE: SI VOUS UTILISEZ LE 26MMAS6064 (OPTION 1), CONTINUEZ POUR D’AUTRES INSTRUCTIONS. SI VOUS UTILISEZ LE 26MMAS6064 (OPTION 2), VEUILLEZ PASSER À...
- Page 19 [x4] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 20 [x16] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 21 Wall Pared WARNING: You must install the tip restraint hardware to help prevent any accidents or damage to the unit. We strongly recommend attaching the tip restraint hardware to a wall stud and your unit. For all other wall types, please visit your local hardware store to obtain the proper hardware.
- Page 22 [x2] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 23 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 24 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 25 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 26 [x4] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 27 READ BEFORE INSERT INSTALLATION LIRE AVANT D’INSTALLER LE FOYER LEA ANTES DE LA INSTALACIÓN DEL HOGAR VEUILLEZ LIRE TOUTES LES PLEASE READ ALL “ELECTRIC LEA ATENTAMENTE TODAS LAS INSTRUCTIONS D’INSTALLATION DU FIREPLACE INSERT” INSTRUCTIONS INSTRUCCIONES DEL “HOGAR FOYER ÉLECTRIQUE ENCASTRABLE PRIOR TO INSTALLING ELECTRIC ELÉCTRICO”...
- Page 28 MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 29 [x2] [x2] MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 30 Wall Pared WARNING: You must install the tip restraint hardware to help prevent any accidents or damage to the unit. We strongly recommend attaching the tip restraint hardware to a wall stud and your unit. For all other wall types, please visit your local hardware store to obtain the proper hardware.
-
Page 31: Care & Maintenance
CARE / SOIN / CUIDADO / MAINTENANCE ENTRETIEN MANTENIMIENTO Care and Maintenance Soin / Entretien Cuidado / Mantenimiento • Use a soft, clean cloth that will not • Lors de l’époussetage, utilisez un • Use un paño suave y limpio que no scratch the surface when dusting. - Page 32 REPLACEMENT PARTS 26MMAS6064 PIECES DE REMPLACEMENT 26MMAS6064 PARTES DE REPESTO 26MMAS6064 [x4] [x4] PH-BKTBLK010 PH-PLTBLK001 [x8] PH-LVRBLK001 Y16-SG-08430380 OPTICAL BLUE LINE IN Y16-SBR-0843 Y16-SBL-0843 TREBLE VOLUME BASS Y14-PID01-PG Y16-MP-0843U MP#MYS 26MMAS6064REV.1 www.tsicustomerservice.com...
- Page 33 Sound System: TS-0843 PRODUCT SPECIFICATIONS Adapter Input AC100-240V, 50/60Hz Adapter Output DC15V 2.5A Power Consumption 30 Watts Standby Power Consumption < 1 W WIRING TS-0843U-0200 1. OPTICAL IN - Input for digital fiber-optic cable. 丝印：877C 2. AUX IN R/L - Input for RCA cable (not included). + 磨砂面 底色：BLACK 3. DC IN - Input for the power supply. Date:26.April,2016 DC 15V IN Fig.1 Back Panel...
- Page 34 丝印：877C Date:26.April,2016 OPERATION INSTRUCTIONS Control Panel The speaker can be operated by either the remote control or the control panel. 26MMAS6064REV.1 www.tsicustomerservice.com MP#MYS...
- Page 35 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION The POWER button supplies power to all the functions of POWER the unit. To scroll through the different input options: SOURCE BT - Bluetooth® Search for other smartphones and devices. The blue flashing light indicates the unit is searching for devices with a WPAN (Bluetooth®) function activated.
- Page 36 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION Press button on the remote to switch to Bluetooth® input. BLUE Press LINE button on the remote to switch to Aux In input. LINE IN LINE OPTICAL OPTICAL Press OPTICAL button on the remote to switch to Optical input.
- Page 37 OPERATION INSTRUCTIONS Learning Function The learning function allows your Sound System to be controlled by your TV remote control (Note: Remote must send infrared signals). Any unused button on your TV remote control can be used to control the Sound System. For example, when you connect your TV to the Sound System using the RCA Stereo cables or Digital Fiber Optic Cable, the TV volume and mute will no longer be controlled by the remote that came with it. Some TV remotes also come with extra buttons. These buttons can also be used for any of the learning options below. Some of the programmable functions need to be selected from the remote contol as noted below. Note: It is able to learn most IR protocols, not all remote can be programmed. To start the learning function: • While powered on, press for 5 seconds to enter learn mode. SEL will start flashing. • Select the function to learn on the control panel or remote. o The function (below) will flash. Point your TV remote at the flashing LED on the sound System and hold down the button you want it to learn from. o When learning is complete, the function goes solid for 3 seconds (stops flashing) and SEL will now start flashing. o You can now select the next function to learn or end the process by pressing the for 5 seconds.
-
Page 38: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION 1. Sound is distorted. 1a. D ecrease the volume. 1b. If the iPhone/iPod original sound source is of poor quality, distortion and noise are easily noticed with high-power speakers. Try a different audio source such as a music CD. 1c. If you are using an external sound source like an older generation iPod, try reducing the output volume on the device itself. 1d.Try changing the bass and treble settings using the remote control. 2. Unit gets warm after extended 2a. T urn the unit off for a period of time or lower the volume. play at high volume. CARE AND MAINTENANCE Warning: 1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 2. Only a qualified service person should repair this product. 3. Do not use outdoors. 4. Do not insert or allow foreign objects to enter the system as this may cause an electric shock, fire or damage to the appliance. 5. Use this appliance only as described in the manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury to persons. 26MMAS6064REV.1 www.tsicustomerservice.com MP#MYS... - Page 39 Replacing the Remote Control Battery When the remote control stops operating or its range seems reduced, it is time to replace the battery with a new one. 1. The battery compartment is located on the back end of the remote. 2. Press and slide the battery door open and remove the old battery. 3. Insert 1pc CR2025 battery, checking that the + and - sides of the battery match inside the battery compartment. 4. Replace the battery compartment door. CAUTION: • Always purchase the correct size and grade of battery most suitable for the intended use. • Replace all batteries of a set at the same time. • Clean the battery contacts and also those of the device prior to battery installation. • Ensure the batteries are installed correctly with regard to polarity (+ and -). • Remove batteries from equipment which is not to be used for an extended period of time. • Remove used batteries promptly. Note: Caution do not ingest batteries. If batteries are swallowed, immediately call poison control. Disposal of Used Batteries Battery may contain hazardous substances which could be endangering to environment and human health. This symbol marked on the battery and/or packaging indicates that used battery shall not be treated as municipal waste. Instead, it shall be left at the appropriate collection point for recycling.
-
Page 40: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Media Console with Sound Bar is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this Media Console with Sound Bar in accordance with the installation and operating instructions furnished with the product at all times. Any unauthorized repair, alteration, willful abuse, accident or misuse of the product shall nullify this warranty. This warranty is non-transferable, and is made to the original owner, provided that the purchase was made through an authorized supplier of the product. The warranty is limited to the repair or replacement of part(s) found to be defective in material or workmanship, provided that such part(s) have been subjected to normal conditions of use and service, after said defect is confirmed by the manufacturer’s inspection. The manufacturer may, at its discretion, fully discharge all obligations with respect to this warranty by refunding the wholesale price of the defective part(s). Any installation, labor, construction, transportation, or other related costs/expenses arising from defective part(s), repair, replacement or otherwise of same, will not be covered by this warranty, or shall the manufacturer assume responsibility for same. The owner/user assumes all other risks, if any, including the risk of any direct, indirect or consequential loss or damage arising out of the use, or inability to use the product, except as provided by law. All other warranties – expressed or implied –with respect to the product, its components and accessories, or any obligations/liabilities on the part of the manufacturer are hereby expressly excluded. The manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other liabilities with respect to the sale of the product. The warranties as outlined within this document do not apply to non accessories used in conjunction with the installation of this product. 10. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
