3.
Carefully insert the M.2 SSD with heat sink into the M.2 slot of your motherboard at an angle of about
30°. Now fix heat sink and M.2 SSD with the delivered screw.
Note: Please make sure that the M.2 SSD and the M.2 socket fit together (e.g. M-Key NVMe M.2 SSD and
M-Key socket on motherboard).
4.
Finally plug the 4 pin fan plug to a free 4 pin socket on your motherboard. The fan will run all the time
when connected. The fan is NOT temperature controlled and speed is NOT adjustable!
Manual IB-M2HSF-703
