Tally Dascom DL-210
Power Supply Input
Output
SDRAM
Memory
FLASH
Standard
Interface
Optional
Software
Dimensions
Casing Color
Weight
Physical Spec.
Operating
condition
Storage condition
Safety
Safety
EMC
Standard
Certificate
Optional kit
Reliability TPH lifetime
1.3

Print Media Types

Important •Dascom strongly recommends the use of Dascom-brand supplies for
continuous high-quality printing.
Your printer can use various types of media:
• Standard media—Most standard (non-continuous) media uses an adhesive backing that sticks
individual labels or a continuous length of labels to a liner.
• Continuous roll media—Most continuous roll media is direct thermal media (similar to FAX paper)
and is used for receipt or ticket style printing.
• Linerless media—Linerless labels have an adhesive backing, but they are wound onto a core
without a liner. The media typically is perforated and may have black marks on the bottom surface of
the media to indicate label separations. The top surface of linerless media labels have a special
coating that keeps the labels from sticking to each other. The printer must be equipped with a
special Linerless option to be able to use linerless media to keep the media from sticking to the
printer.
• Tag stock—Tags are usually made from a heavy paper (up to 0.0075in./0.19mm thick). Tag stock
does not have adhesive or a liner, and it is typically perforated between tags.
For more information on basic media types, see the following table.
The printer typically uses roll media, but you can use fan-fold or other continuous media too. Use the
correct media for the type of printing you require. You must use direct thermal media. When
printing without a ribbon, you must use direct thermal media. When using ribbon, you must use
thermal transfer media.
External power adapter
AC 100V-240V, 50-60Hz
24V DC, 3A
8MB
8MB
USB (2.0 Full-Speed)
Serial (RS-232, DB25)
Parallel Centronics (IEEE-1284)
Ethernet: 10M/100M
Bluetooth: SPP
Driver (Windows 32bit/64bit), Bartender, SDK system
230(W)×290(D)×176(H)mm
Black
Approx 3kg
5～40℃/20～95%RH (non-condensing)
-20～60℃/≤95%RH (non-condensing)
UL, CE, FCC, CCC
Class B
CCC, CE, FCC, UL, Energy star
Cutter, Peeler
150km
(Condition: use specific thermal roll paper and the print rate is 12%)
3
