- Page 1 Nest Easel 781P, 785P, 785E-DD ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 06/02/2022 1 of 11...
-
Page 2: Parts List
Parts List Hardware P1 - Board A - M6 x 15mm Screw B - M6 x 30mm Screw P2 - Lower Leg C - M6 x 60mm Screw P3 - Upper Leg D - M6 Interior Threaded Post P4 - Middle Tray E - 2”... - Page 3 WARNINGS AND DISCLAIMERS Review full assembly instructions and check that all parts are present before beginning assembly. Heavy or large furniture may require multiple persons in order to properly assemble. If you have questions regarding assembly, contact the manufacturer before continuing. Damage due to incorrect assembly may not be covered by warranty.
- Page 4 Attach Middle Tray (P4) to two (2) Lower Legs (P2) at desired height using two (2) STEP 1 M6 x 60mm Socket Screws (C). Attach each of the Upper Legs (P3) to the each of the Lower Legs (P2) using four (4) STEP 2 M6 x 15mm Socket Screws (A).
- Page 5 Insert Markerboard (P1) into Middle Tray (P4). Make sure the four small holes on marker STEP 3 board are on the top. Slide Top Support (P5) over Markerboard (P1) and secure to the two Upper Legs(P3) STEP 4 using two (2) each M6 x 60mm Socket Screws (C). UPDATED AS OF: 06/02/2022 5 of 11...
- Page 6 Attach Book Rack Front Panel (P6) and Book Rack Back Panel (P7) to the two Lower Leg STEP 5 Frames (P2) using four (4) M6 x 30mm Socket Screws (B) and four (4) M6 Interior Threaded Posts (D). Attach all four (4) Locking Casters (E) to the lower legs. Tighten the Casters using STEP 6 Caster Wrench (K).
- Page 7 Peel the paper from the back of adhesive pad on Plastic Chart Support (F). Attach 2 Plastic STEP 7 Chart Supports on each side of board. Insert 2 pins on back side of Chart Support (F) through holes in markerboard (P1). Complete THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 06/02/2022...
- Page 8 Panel Wings ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 06/02/2022 8 of 11...
- Page 9 Parts List Hardware P1A - Wing Panel A1 - M6 x 15mm Screw B1 - M6 Interior Threaded Post P2A - Plastic Hanger UPDATED AS OF: 06/02/2022 9 of 11...
- Page 10 With hardware from Nest Easel, screw two Plastic Reciever (G) onto the outside of the STEP 1 Upper Legs (P3) with two #10 - 1” Wood Screws (H) and two #10 - 1/2” Wood Screws (I). Repeat with the other side of the whiteboard. Attach two Plastic Hangers (P2A) to the side of the Wing Panel using two (2) M6 STEP 2 Interior Threaded Post (B1) and two (2) M6 x 15mm Socket Screws (A1).
- Page 11 Peel the paper from the back of adhesive pad on Plastic Chart Support (F). Attach 2 Plastic STEP 7 Chart Supports on each side of board. Insert 2 pins on back side of Chart Support (F) through holes in markerboard (P1). Complete THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 06/02/2022...
