- Page 1 WHYNTER FREESTANDING ICE MAKER MODEL # : FIM-450HS Instruction Manual Congratulations on your new WHYNTER product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PARTS AND FEATURES SAFETY PRECAUTIONS REQUIREMENTS OPERATION USING THE CONTROL PANEL INSTALLING THE WATER LINE DRAINING THE UNIT LEVELING THE ICE MAKER CLEANING AND MAINTENANCE SPECIFICATIONS TROUBLESHOOTING 11 - 12 WARRANTY INFORMATION... -
Page 3: Parts And Features
FEATURES With the Whynter FIM-450HS Ice Maker, you can produce up to 44 lbs of ice per day, while buffering up to 7.7 lbs of ice; making this ice maker the perfect solution for convenient and fresh ice. This efficient direct plumbing ice maker allows you a constant supply of bullet-shaped ice at a much higher rate relative to manual fill ice makers. -
Page 4: Safety Precautions
TO REDUCE THE RISK OF FIRE, ELECTRICAL WARNING SHOCK, OR INJURY WHEN USING YOUR ICE MAKER, FOLLOW THESE BASIC PRECAUTIONS: READ ALL INSTRUCTIONS BEFORE USING THE ICE MAKER. WARNING: RISK OF DANGER TO SMALL CHILDREN AND SMALL ANIMALS. ENTRAPMENT AND SUFFOCATION DANGER IF NOT PROPERLY SECURED. -
Page 5: Requirements
Do not remove any safety, warning, or product information labels from your ice maker. Before you begin Preparing the Ice Maker for use before you plug the ice maker in to a power supply, be sure to let it stand upright for at least 24 hours to allow the compressor’s oils to settle. Unpacking the Ice Maker Carefully remove the packaging materials. -
Page 6: Operation
OPERATION Discard the first batch of ice produced by the freestanding ice maker. Direct sunlight may cause the ice full infrared sensor to malfunction. If the unit continues to produce ice even though the basket is full, you may need to move the unit away from the sunlight Before using your ice maker, it is strongly recommended to clean it thoroughly. -
Page 7: Installing The Water Line
How the Freestanding Ice Maker Produces Ice After the unit is powered on, the ice maker begins with rotating the ice case into a horizontal water fill position under the evaporator rods. The water pump is engaged and fills the ice case with water. Water overflows for a few seconds before the compressor turns on. -
Page 8: Draining The Unit
Draining the unit This unit operates in a gravity drain system which clears excess water from the ice maker to ensure a continuous supply of ice. A water drain hose is provided with this unit. Firmly attach the drain hose to the drain outlet. -
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE The ice maker must be thoroughly cleaned if it has been left unused for a long time DO NOT turn the ice machine upside down to dry! This will cause the oils from the compressor to shift, which can result in the machine breaking or becoming inoperable. -
Page 10: Specifications
SPECIFICATIONS Description of product Freestanding Ice Maker Voltage/Frequency AC 115V~60Hz Ice-Making / Ice-Harvest rated current 1.2A / 3.5A Color Stainless Steel Ice Storage capacity 7.7 lbs Ice-making capability 44 lbs/ day * Refrigerant R134a 14 7/8” x 18 13/16” x 23 3/16” Dimensions (Width x Depth x Height) Weight 60 lbs... -
Page 11: Troubleshooting
The gravity drain is directed in an upward direction – The gravity The ice storage bin is The unit is overfilling the ice making tray – Contact Whynter filled with water drain must be directed in a downward direction. - Page 12 Ensure water pressure is a minimum Water overflow 14.7 psi and a maximum of 55 psi Defective Water Sensor Inspect water sensor. Contact Whynter Service Department for details Drain line elevated Ensure gravity drain line is directed downward ...
-
Page 13: Warranty Information
ONE YEAR LIMITED WARRANTY This WHYNTER Ice maker is warranted, to the original owner within the 48 continental states, for one year from the date of purchase against defects in material and workmanship under normal use and service. Should your ice maker prove defective within one year from the date of purchase, return the defective part or unit, freight prepaid (within two months of purchase;...
