Specifications - Canon EF 70-200mm Instructions Manual

Specifications

Focal Length/Aperture
Lens Construction
Minimum Aperture
Angle of View
Min. Focusing Distance
Max. Magnification
Field of View
Filter Diameter
Max. Diameter and Length 80 x 176 mm/3.15 x 6.93 inch
Weight
Hood
Lens Cap
Case
The lens length is measured from the mount surface to the front end of the lens. Add 24.2 mm when
● ●
including the lens cap and dust cap.
The size and weight listed are for the lens only, except as indicated.
● ●
Aperture settings are specified on the camera.
● ●
All data listed is measured according to Canon standards.
● ●
Product specifications and appearance are subject to change without notice.
● ●
70-200mm f/4
15 groups, 20 elements
f/32
Diagonal: 34° - 12°, Vertical: 19°30' - 7°, Horizontal: 29° - 10°
1.0 m/3.28 ft.
0.27x (at 200 mm)
Approx. 354 x 236 - 129 x 87 mm/13.94 x 9.29 - 5.08 x 3.43 inch (at 1.0 m/3.28 ft.)
72 mm
Approx. 780 g/27.5 oz
ET-78B
E-72 II
LP1224
ENG-17
