- Page 1 CAP-502MJZ USB 3.0 Full HD Video Capture Device with HDMI 2.0a loopout & Audio User Manual rev: 200515 Made in Taiwan...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ......................... 1 FEATURES ......................... 1 PACKAGE CONTENTS ...................... 1 SPECIFICATIONS ......................2 PANEL DESCRIPTIONS ..................... 3 CONNECTION DIAGRAM ....................3 USB PIN DEFINITION ......................4 WARRANTY ........................5... -
Page 3: Introduction
INTRODUCTION The CAP-502MJZ USB 3.0 Full HD Video Capture Device with HDMI 2.0a loopout & Audio provides a professional way to capture HDMI video signals. It adopts USB 3.0 interface, which can realize high- speed transmission. Besides, the HDMI input and loopout can support up to 4K2K@60. With this device, users can connect to 4K2K@60 source and capture Full HD (1080p60) video. -
Page 4: Specifications
SPECIFICATIONS Model Name CAP-502MJZ Technical Role of usage Video Capture Device Input Video bandwidth Single-link 600MHz [18Gbps] Output Video bandwidth Up to 350MBps (USB) Video support(USB) Up to 1080p60 Video support(Loopout) Up to 4K2K60 HDMI Embedded Audio & Stereo audio Input... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS 1. HDMI IN: Connect to a HDMI source 2. LED INDICATOR: Input signal indicator LED 3. STEREO AUDIO IN: Connect to analog stereo audio source 4. Micro-USB Port: Connect to the +5V DC power supply unit 5. STEREO AUDIO OUT: Audio extracts from HDMI input 6. -
Page 6: Usb Pin Definition
USB PIN DEFINITION VBUS SSRX- SSRX+ SSTX- SSRX+ Shield SHELL SHELL... -
Page 7: Warranty
WARRANTY The SELLER warrants the CAP-502MJZ USB 3.0 Full HD Video Capture Device with HDMI 2.0a loopout & Audio to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order...
