Connecting the Digital Home Receiver
TV and VCR with RF Connectors Only
Coaxial cable
1
2
From
wall oulet
10
1
Connect the coaxial cable from the wall outlet (Cablevision cable
network signal) to the Digital Home Receiver's
2
Connect the Digital Home Receiver's
(or
) jack.
VHF/UHF IN
RF IN
3
Connect the VCR's
(or
) jack.
VHF/UHF IN
RF IN
4
Connect one end of the AC power cord to the Digital Home
Receiver's
jack, then connect the plug end to an AC outlet.
AC IN
5
Set your VCR's channel switch (usually on the rear panel) to
channel 3.
VCR
TO TV/VCR
(or
) jack to the TV's
VHF/UHF OUT
RF OUT
4
AC cord
3
jack.
CABLE IN
jack to the VCR's
TV
