GLACIER C350ap
PH-C350ap_BK01
PACKAGE CONTENTS
4x
C350ap Block
4x
DISCLAIMER
- This product is intended for advanced users.
Please consult with a quali ed technician for installation. Phanteks
assumes no liability for any damages occurring as a result of using
Phanteks cooling products.
INSTALLATION for socket AM4
Socket Screws for:
- AM4
Acetal Stando
Thermal Compound
(PH-NDC_01)
WARNING
- Power down the system before installation.
- Do not disassemble the waterblock. Warranty will be voided.
- Perform a leak test before turning on the system.
- Check our website for the latest installation guide.
STEP 1. REMOVE THE ORIGINAL PLASTIC CLAMPS
Use a Philips-head screwdriver to remove the four (4) screws
(in red). Remove the plastic clamps from the motherboard and
make sure the original AMD backplate stays in place.
STEP 2. INSTALLING THE SOCKET SCREWS
Place and tighten the four (4) included socket screws by hand
on the AM4 socket.
STEP 3. INSTALLING THE ACETAL STANDOFFS
Place the four (4) included Acetal Stando s onto the
socket screws.
MANUAL V1.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Phanteks GLACIER C350AP
Summary of Contents for Phanteks GLACIER C350AP
- Page 1 - This product is intended for advanced users. - Power down the system before installation. Please consult with a quali ed technician for installation. Phanteks - Do not disassemble the waterblock. Warranty will be voided. assumes no liability for any damages occurring as a result of using - Perform a leak test before turning on the system.
- Page 2 STEP 4. APPLYING THERMAL COMPOUND Make sure the CPU is clean and clear of any residual traces of thermal paste. Apply a dot (4-5mm size) of Phanteks thermal compound on the center of the CPU surface. STEP 5. INSTALLING THE C350ap Block Remove the protective lm on the copper base rst.
