Summary of Contents for Audio Technica ATW-1702
- Page 1 System 10 Portable Camera-Mount Wireless Digital Wireless System Installation and Operation ATW-1701 UniPak Transmitter System ® ATW-1702 Handheld Microphone System...
- Page 2 System 10 Portable Camera-Mount Wireless Installation and Operation wireless microphones have low-power transmitters (less than 0.05 watts output) which are unlikely CAUTION RISK OF ELECTRIC SHOCK mic transmitter typically is placed against the body, we suggest attaching it at the belt, rather than DO NOT OPEN in a shirt pocket where it may be immediately adjacent to the medical device.
-
Page 3: Receiver Installation
System 10 Portable Camera-Mount Wireless Installation and Operation Receiver Installation Power Connection Location NOTE: Use only the supplied AC adapter and power cord to power or For best operation the receiver should be at least 3' (1 m) above the charge receiver. - Page 4 System 10 Portable Camera-Mount Wireless Installation and Operation ATW-T1002 Transmitter Setup Controls and Functions Battery Selection and Installation Two alkaline AA batteries are recommended. When inserting the battery, observe correct polarity as marked inside the battery compartment. Power / Battery / Mute Status Indicator Level Control System ID Display...
- Page 5 System 10 Portable Camera-Mount Wireless Installation and Operation Microphone / Instrument Level Control Pairing Switch Screwdriver System ID Display Battery Compartment Figure G — ATW-T1001 UniPak Transmitter ® UniPak Transmitter Battery Installation ® 1. Slide off the battery cover. 2. Carefully insert two fresh AA alkaline batteries, observing polarity markings.
-
Page 6: System Operation
System 10 Portable Camera-Mount Wireless Installation and Operation System Operation Peak Indicator. If the Peak indicator does light, turn the “VOL ” control slightly counterclockwise until the Peak indicator no longer lights with maximum audio input to the transmitter. Turn down the headphone volume control and the camera/mixer level before starting up the wireless system. -
Page 7: System Frequencies
System 10 Portable Camera-Mount Wireless Installation and Operation 6. Repeat for each additional transmitter. Remember to switch off all 3. The transmitter and the receiver should be as close together as con- veniently possible, but not less than 6' (2 m). transmitters already paired before adding a new one and to use a 4. -
Page 8: Overall System
System 10 Portable Camera-Mount Wireless Installation and Operation OVERALL SYSTEM UNIPAK TRANSMITTER ® Operating Frequencies 2.4 GHz ISM band (2400 to 2483.5 MHz) RF Output Power 10 mW Dynamic Range >109 dB (A-weighted), typical Spurious Emissions Following federal and national regulations Total Harmonic Distortion <0.05% typical Input Connection...
