- Page 1 B AT T E R Y C H AR G E R BATTERY CHARGER Installation and User Manual...
- Page 2 No other use is allowed without a written authorization supplied by ZIVAN S.r.l. ZIVAN S.r.l. will be not responsible for inaccuracies contained in this manual due to print or translation errors. ZIVAN S.r.l. has the right to make changes or improvements, also for the user interest, without prejudicing the essential characteristic of operation and safety.
-
Page 3: Installation And Safety Instructions
Verify that the selected charging curve is suitable for the type of battery to be re-charged. In case of doubt, consult Your retailer. ZIVAN S.r.l. will not accept any responsibility in case of mistaken choice of the charging curve that may cause irreversible damage to the battery. -
Page 4: Operating Principle
Battery charger NG3 Operating principle The battery charger considerably affects battery life and performances, which is the main part of every electric vehicle. A non controlled traditional battery charger (rectifier) provides a simple direct AC/DC conversion. Disadvantages of this solution are: •... -
Page 5: Led Indicator
Battery charger NG3 LED Indicator 100% RED LED shows that the battery is in the initial charging phase. YELLOW LED shows that the battery charger has reached 80% of charge. GREEN LED shows that the battery has reached 100% of charge. START Further information can be found in the description of the Charging Curve. -
Page 6: Auxiliary Contacts
Battery charger NG3 Auxiliary Contacts AUX1 AUX2 Technical Features: changeovers contacts 0,3A 125VAC 0,3A 110VDC 1A 30VDC faston 6,3 × 0,8 mm Connector: Unless otherwise stated, the auxiliary contacts provide the following functions: Section Function Description AUX1 Mains Presence When the equipment is switched on, the contact Normally Open (NO) CLOSES and instead the contact Normally Closed (NC) OPENS. -
Page 7: Mechanical Dimensions
Battery charger NG3 Mechanical dimensions N.B. All dimensions are expressed in mm. Drilling details Advised Installation 399 430 N.B. All dimensions are expressed in mm. D01058-02... -
Page 8: Technical Features
Battery charger NG3 TECHNICAL FEATURES Ta=25°C unless otherwise specified Mains side Description Symbol Test Condition Value and/or Unit Range Supply Voltage 230 ± 10% Veff Frequency 50 ÷ 60 Absorbed Maximum Current P = P Aeff Inrush Current Vin = 230Veff <... -
Page 9: Protection And Safety
Battery charger NG3 General Description Symbol Test Condition Value and/or Unit Range ∆ Operating range of temperature from -20 to +50 °C Maximum relative humidity Switching frequency 30 ± 5% η Efficiency At each operation > 85% condition Maximum size a×b×c Without connecting 430×220×90... - Page 11 Battery charger NG3 D01058-02...
