- Page 1 Ultrasonic Thickness Gauge MT150/160 User’s Manual MITECH CO., LTD. www.ponpe.com www.mitech-ndt.com...
-
Page 2: Table Of Contents
CONTENTS 1 Overview................................3 1.1 Product Specifications..........................3 1.2 Main Functions............................4 1.3 Measuring Principle..........................4 1.4 Configuration.............................4 1.5 Operating Conditions..........................5 2 Structure Feature............................. 5 2.1 Main Screen.............................. 5 2.2 Keypad Definitions........................... 6 3 Preparation................................ 6 3.1 Transducer Selection..........................6 3.2 Condition and Preparation of Surfaces.................... -
Page 3: Overview
1 Overview The model MT150/MT160 is a digital ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01 millimeters. It is suitable for a variety of metallic and non-metallic materials. -
Page 4: Main Functions
1.2 Main Functions Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials. Transducer models are available for special application, including for coarse grain material and ... -
Page 5: Operating Conditions
1.5 Operating Conditions Operating Temperature: －20℃～＋60℃; Storage Temperature：-30℃～＋70℃ Relative Humidity ≤90％； The surrounding environment should avoid of vibration, strong magnetic field, corrosive medium and heavy dust. 2 Structure Feature ULTRASONIC THICKNESS GAUGE POWER: 2 X 1.5V 1 The main body... -
Page 6: Keypad Definitions
2.2 Keypad Definitions Turn the instrument Sound velocity on/off calibration Turn on/off the EL Enter backlight Probe-Zero Plus; operation Turn on/off Scan mode Unit switch between Minus; Metric and Imperial Turn on/off system beep mode Data Save or Data... - Page 7 Additionally, care must be taken when performing a “Probe-Zero” or “Calibration to Known Thickness” with a high temperature transducer. Selection of the proper transducer is often a matter of tradeoffs between various characteristics. It may be necessary to experiment with a variety of transducers in order to find one that works well for a given job.
-
Page 8: Condition And Preparation Of Surfaces
3.2 Condition and Preparation of Surfaces In any ultrasonic measurement scenario, the shape and roughness of the test surface are of paramount importance. Rough, uneven surfaces may limit the penetration of ultrasound through the material, and result in unstable, and therefore unreliable, measurements. The surface being measured should be clean, and free of any small particulate matter, rust, or scale. -
Page 9: Sound Velocity Calibration
At this point, the instrument has successfully calculated its internal error factor, and will compensate for this value in any subsequent measurements. When performing a “probe zero”, the instrument will always use the sound velocity value of the built-in probe-disc, even if some other velocity value has been entered for making actual measurements. -
Page 10: Making Measurements
Press the key again, so that The M/S (or IN/μS) symbols are flashing. Use the key and the key to adjust the sound velocity value up or down, until it matches the sound velocity of the material to be measured. You can also press the key to switch among the preset commonly using velocities. -
Page 11: Scan Mode
4.6 Changing Resolution MT160 has selectable display resolution, which is 0.1mm and 0.01mm. This function is not available for MT150, which is fixed to 0.1mm. Press down the key while turning on the gauge will switch the resolution between “High” and “Low”. -
Page 12: Memory Management
At the end of the inspection process, or end of the day, the user may require the readings be transferred to a computer. The following steps outline this procedure. This function is only available for MT160, and not for MT150. Before printing, please insert one connection plug of the print cable (Optional parts) into the socket on the up-left of the main body, and insert the other plug into the communication socket of the mini-printer. -
Page 13: Beep Mode
Use the key and the key to select the desired file. Press the key to print the selected file. This operation will send all the data in current file to the mini printer via RS232 port and print them out. -
Page 14: Appendix A Sound Velocities
Appendix A Sound Velocities Material Sound Velocity in/µs Aluminum 0.250 6340-6400 0.233 Steel, common 5920 0.226 Steel, stainless 5740 0.173 Brass 4399 0.186 Copper 4720 0.233 Iron 5930 0.173-0.229 Cast Iron 4400－5820 0.094 Lead 2400 0.105 Nylon 2680 0.142... - Page 15 Measuring hot surfaces The velocity of sound through a substance is dependant upon its temperature. As materials heat up, the velocity of sound through them decreases. In most applications with surface temperatures less than about 100 ℃...
- Page 16 A wide variety of couplant materials may be used in ultrasonic gauging. Propylene glycol is suitable for most applications. In difficult applications where maximum transfer of sound energy is required, glycerin is recommended. However, on some metals glycerin can promote corrosion by means of water absorption and thus may be undesirable.
-
Page 17: User Notes
Warranty ： The product is guaranteed for one year since purchased. Log www.mitech-ndt.com or follow our company official public platform to register for maintenance. Please fill the blanks as required, if the product is not registered for maintenance, it will follow the date of manufacturer.
