Wi-Fi Interface: Setting Up Instructions

Information for users

The following steps explain how to connect the Wi-Fi interface to a Router.
KEY (LED LIGHTS):
1
2
Download and install Wi-Fi Control App to your compatible Apple or
Android smartphone/tablet (search term: Mitsubishi Wi-Fi Control).
THERE ARE TWO OPTIONS OF CONNECTING
Option 1 - Access Point Mode Pairing
3
Activate Access Point Mode on your
Wi-Fi interface by using a small object
to press and hold the MODE Button
for 7 seconds.
: ON : OFF
ERR
NET
MODE
UNIT
RESET MODE
: Flashing
Ensure the Wi-Fi interface is
connected correctly as per the
previous section, 'Connecting the Wi-
Fi interface'.
UNIT LED should be flashing green
only.
4
When Access Point Mode is enabled
on the Wi-Fi interface, MODE LED
starts flashing orange (every 5
seconds).
Complete the setting up in the Access
Point Mode with in 10 minutes.
ERR
NET
MODE
UNIT
RESET MODE
