FOLLOW NEXT STEPS FOR THE CORRECT INSTALLATION OF THIS RECEIVER.
STEP 1: CONNECTIONS
The coaxial cable, with satellite signal, must be connected to the "IF IN" connector. The "TV SCART"
connector must be connector to the TV set.
Depending on the type of installation, the receiver should be connected and confi gured following next
examples.
Example 1 – Basic System
Example 3 – Combined with terrestrial
QUICK INSTALLATION GUIDE
QUICK INSTALLATION GUIDE
PAG. 3
Example 2 – DISEqC switches
Example 4 – Motorized system
