Piscine Solide V35026 Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
V35026
DISC OVERY
POOL MODEL
INSTALLATION MANUAL - OVAL POOLS
G:\RnD\01-Projets\Discovery\Discovery 15x22light 2D.3dm
11.13

Advertisement

loading
Need help?

Need help?

Do you have a question about the V35026 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Piscine Solide V35026

Summary of Contents for Piscine Solide V35026

  • Page 1 V35026 DISC OVERY POOL MODEL INSTALLATION MANUAL - OVAL POOLS G:\RnD\01-Projets\Discovery\Discovery 15x22light 2D.3dm 11.13...
  • Page 3 Above Ground Pool SAfety PleASe reAd before inStAllAtion Failure to heed these warnings can result in permanent injury, warning paralysis From a broken neck, electrocution or drowning. this pool is not designed For diving or jumping! dangerous injury can result, shallow water! your pool contains a large quantity of water, and is deep enough to present inherent dangers to life and health unless the follow- ing safety rules are strictly observed.
  • Page 5 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION Read all instructions completely before you begin. A. DETERMINE THE LOCATION OF YOUR POOL 1. The Terrain Pay special attention to choosing the right location for your pool: • Choose a large area, as flat and level as possible and well drained.
  • Page 6 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION A. CONT. DETERMINE THE LOCATION OF YOUR POOL 2. Things to Avoid Do not locate your pool near or on any of the following (Images 3a to 3c) • Overhanging tree branches. Overhanging branches •...
  • Page 7 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION A. CONT. DETERMINE THE LOCATION OF YOUR POOL 4. Tools Needed List of required materials • Straight wood plank • Material that provides a permanent base (ex. Crushed stone) • Fine sand (void of debris) •...
  • Page 8 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION PARTS LISTING - EXPLODED VIEW Discovery RRR Important Note: PDSC-YE52RRBXRXX01 Make sure you have all the parts necessary before you Yard Extender start installation. Oval No Diving or Jumping. Observe all Safety Rules...
  • Page 9 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION PARTS LISTING - CONTENTS Product Description : Discovery Oval Revised Sept 2012 Product Code : PDSC-YE52RRBXRXX01 Quantity required for installation (by pool size) Index# Description Part # Length 1219 1223 1522 1526 1530 1833...
  • Page 10 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. PREPARE THE FOUNDATION OF YOUR POOL 1. Mark out the Area The next following steps will show you how to mark out the area you need for the oval pool. This marked area will be larger than the pool size itself, but this space is needed.
  • Page 11 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL Mark areas along both straight sides of your oval. Use pegs and string as a guide for the can of spray paint to mark straight lines. (Image 5) You now have the space marked out that is needed for your oval pool.
  • Page 12 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL Example on how to mark out pool area for an 18 x 33 Please be sure to use your pool’s footprint for your pool size on the last pages of this Section1.
  • Page 13 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL 3. Make the area flat and level Remove all the high spots with a shovel, hoe or rake. To make sure your pool is stable, compact the ground well before adding the sand.
  • Page 14 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION C. PRE-ASSEMBLY OF THE T JOINTS (BUTTRESS) 1. Assembling the buttress joints Insert the horizontal sleeves in the buttress joints. Outside of Pool On each side insert two or three (depending on the Inside of Pool side) 6.35 cm (2.5”) mechanical screws with nuts.
  • Page 15 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION C. CONT. PRE-ASSEMBLY OF THE T JOINTS (BUTTRESS) Insert the three 6.35 cm (2.5”) screws with nuts in Outside of Pool the vertical sleeve. (Image 14) Inside of Pool IMPORTANT: If your pool has steel bottom plates, Do not permanently fasten the vertical sleeve with screws.
  • Page 16 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section Section GROUND PREPARATION D. GROUND PREPARATION FOR THE BUTTRESS 1. Measuring for the buttress trenches In order to measure where trenches need to be dug for the placement of the buttress, you must first draw a perpendicular line in order to create a perfect 90 degree angle.
  • Page 17 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 2. Digging the buttress trenches Odd number of trenches; If your oval pool contains an even number of buttresses, please proceed with next step. If your oval pool contains an odd number, position the buttress temporarily on the straight center line from the middle.
  • Page 18 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 3. Install Patio Stones (Blocks) Insert and level two concrete slabs or their equivalent, which should measure about 20 cm x 40 cm x 10cm (8” x 16” x 2”), allowing one of the slabs to extend past the inside end of the T.
  • Page 19 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 4. Finish trenches & patio stone installation Continue to finish one by one the remaining trenches with patio blocks for the buttress installation. It is important to finish one side of the oval only.
  • Page 20 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION E. ASSEMBLING THE BUTTRESS STRAPS AND PRESSURE PLATES 1. Assemble the buttress straps and brace Place a steel strap and a pressure plate on the buttress base, 1.14 m (45”) from centre to centre, place only one screw, but do not secure it tightly.
  • Page 21 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION E. ASSEMBLING THE BUTTRESS STRAPS AND PRESSURE PLATES Once both sides of the buttresses have been installed perfectly, check that all is measured again perfectly. (Image 28) Add the remaining straps that join across to other straps.
  • Page 22 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 19 12'-1 5/16" 2'-2 1/8" 3 places 4'-11 3/4" 6 places 15'-5 15/16" 1-18 No Diving or Jumping. Observe all Safety Rules...
  • Page 23 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 23 12'-1 5/16" 2'-2 1/8" 4 places 4'-11 3/4" 8 places 15'-5 15/16" 1-19 No Diving or Jumping. Observe all Safety Rules...
  • Page 24 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 x 26 14'-10 15/16" 4'-11 3/4" 9 places 18'-3 9/16" 1-20 No Diving or Jumping. Observe all Safety Rules...
  • Page 25 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 X 30 14'-10 15/16" 4'-11 3/4" 16 places 18'-3 9/16" 1-21 No Diving or Jumping. Observe all Safety Rules...
  • Page 26 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 18 x 33 17'-11 3/8" 2'-2 1/8" 10 places 4'-11 3/4" 15 places 21'-4" 1-22 No Diving or Jumping. Observe all Safety Rules...
  • Page 27 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS 1. Bottom plates - straight section To install the bottom plate in the straight section, place it on the inside of the horizontal T. Insert the end of each bottom rail into the bottom plate.

  • Page 28: Important Note

    IMPORTANT NOTE There are three types of bottom rails; 1- Straight Section 2- Round Section 3- Transition (End of the Straight Section). To differentiate which bottom rail is which; • The Straight Section will measure the shortest in length • The Transition Section will measure will measure longer than the straight section, but shorter than the round section. • The Round Section will be the longest measurement. Straight Section Transition Section Round Section No Diving or Jumping.
  • Page 29 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS 3. Patio Stones (Optional) Contact your Dealer: Please contact your dealer for more information about using patio stones. Concrete patio stones may be placed at the base of each upright of your pool.
  • Page 30 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF OF BOTTOM PLATES AND BOTTOM RAILS 4. Measure the perimeter of your pool Measure the perimeter of your pool and hammer nails into the ground to keep the bottom rails into place.
  • Page 31 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF OF BOTTOM PLATES AND BOTTOM RAILS 5. Fill inside the pool area Fill sand under the pressure plates first, make sure it is well compacted. Pour sifted sand in the centre of your pool.
  • Page 33 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. SETTING UP THE POOL WALL Do not attempt to install the pool wall in the wind, wait for a calm day. It takes at least 3 people to install the pool wall. 1.
  • Page 34 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. CONT. SETTING UP THE POOL WALL 3. Join the ends of the pool wall Line up the holes in the two ends of the pool wall. (Image 4) Now that you have installed the wall you can be faced with three scenarios.
  • Page 35 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. CONT. SETTING UP THE POOL WALL To fasten the wall joint, overlap the two steel bars, one on the inside and the other on the outside. Tighten the mechanical screws on the inside and the nuts on the outside.
  • Page 36 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL B. ASSEMBLING THE COVE 1. Make the cove If you are using sand, bank the sand against the wall to form a cove of 3” to 6” (7.5cm to 15cm) high and 8”...
  • Page 37 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL B. CONT. ASSEMBLING THE COVE A vacuum cleaner can later be used to remove the air from between the liner and the wall. This technique enables you to remove folds in the liner. (Image 12) However the following precautions should be taken: Do not use an industrial vacuum cleaner which...
  • Page 38 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. INSTALL THE POOL LINER 1. Set the liner in place Open the carton. Do not use anything sharp to open the carton. Unpack and unfold the liner and spread it out in the sun to warm it up.
  • Page 39 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER - OVERLAP Please ensure to follow instructions that match the type of liner you may have. 2. Fasten the liner place (OVERLAP ONLY) Starting at the liner wall seam, hang the liner over the wall making sure that the seam is straight up and down, perpendicular to the floor.
  • Page 40 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER - OVERLAP After all the wrinkles in the liner are removed, trim any extra length of plastic coping so there is no overlap. (Image 19) Roll up any excess liner hanging below the plastic coping and tape it in place near the top of the pool...
  • Page 41 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER - HUNG/J OR V-BEAD 4. Fasten the liner in place (HUNG/J or V-BEAD LINER ONLY) With a V-Bead liner you will not use the plastic coping strips.
  • Page 42 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER - BEADLOCK/SNAPBEAD 3. Fasten the liner place (BEADLOCK/SNAPBEAD LINER ONLY) With a snap bead liner you will not use the plastic coping strips. Instead, you should have received a beaded liner track (referred to as a “coping bead receiver”...
  • Page 43 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME A. INSTALLATION OF THE UPRIGHTS - Straight Section 1. Install the uprights - straight section NOTE: The wall joint is hidden behind the upright on most pools. This assures that the skimmer and skimmer return holes are not obstructed.
  • Page 44 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME A. INSTALLATION OF THE UPRIGHTS - Round Section 1. Install the uprights - round section Before installing the uprights, slide onto each upright, from the base, a base crown. (Image 5) Insert an upright into the bottom plate.
  • Page 45 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME B. INSTALLATION OF ANCHOR PINS ON TOP LEDGE 1. Insert pins in anchoring slots Each anchoring slot has an assigned letter. Image 5) Insert the pins into the appropriate anchoring slots of the top ledge index system.
  • Page 46 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF ANCHOR PINS ON TOP LEDGE No Diving or Jumping. Observe all Safety Rules...
  • Page 47 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF ANCHOR PINS ON TOP LEDGE No Diving or Jumping. Observe all Safety Rules...
  • Page 48 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF ANCHOR PINS ON TOP LEDGE No Diving or Jumping. Observe all Safety Rules...
  • Page 49 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF ANCHOR PINS ON TOP LEDGE No Diving or Jumping. Observe all Safety Rules...
  • Page 50 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF ANCHOR PINS ON TOP LEDGE No Diving or Jumping. Observe all Safety Rules...
  • Page 51 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME D. INSTALLATION OF TOP LEDGE AND LEDGE COVER 1. Install the top ledges Install the first top ledge on the wall making sure the upright is levelled and situated in the middle of the top ledge hole.
  • Page 52 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME D. CONT. INSTALLATION OF TOP LEDGE AND LEDGE COVER For easier installation of the top ledges, alignment notches have been added close to each pin (male part of the top ledge). (Image 12) These notches will help you locate the central alignment slot corresponding to each pool size.
  • Page 53 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME D. CONT. INSTALLATION OF TOP LEDGE AND LEDGE COVERS To make the pieces fit together, you may have to use the adjustment points provided for this purpose and move the top ledge to the left or right.

  • Page 54: Important Safety Information

    GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME E. FILL YOUR POOL WITH WATER 1. Finish filling the pool Turn off the vacuum and carefully remove it from the pool. Fill the pool with water to 2” (5cm) below the lowest opening.

  • Page 55: Pool Maintenance

    POOL MAINTENANCE Section MAINTAINING YOUR POOL POOL MAINTENANCE Keep your pool wall and frame clean. Always wash away any deposits of pool chemicals which land on the frame of your pool. Wash periodically with a mild soap solution (no abrasives). At least once a year use a clear non-yellowing household wax on all metal components.

  • Page 56: Winterizing Your Pool

    POOL MAINTENANCE Section WINTERIZING YOUR POOL WINTERIZING YOUR POOL Along with the cool nights of autumn comes the end of the swimming season. During the winter your pool is subject to more stress than in the summer, and any breakage that is caused by incorrect winter procedures is not subject to any warranty with this company.

  • Page 57: Winterizing Instructions

    POOL MAINTENANCE Section WINTERIZING YOUR POOL WINTERIZING INSTRUCTIONS For areas where water freezes make sure to follow these instructions before the water is frozen, otherwise do not touch the frozen water, this may damage the pool. Towards the end of the summer season or around mid-August, check for leaks by verifying if the pool’s water level is stable.
  • Page 58 POOL MAINTENANCE Section WINTERIZING YOUR POOL WINTERIZING INSTRUCTIONS CONTINUED To maintain water quality, use a winter kit which contains an algicide and chlorine especially designed for this purpose. When it’s time for spring cleaning, this will save you hours of work and reduce the cost of chemicals needed to restore your water quality.
  • Page 59 POOL MAINTENANCE Section SPRINGTIME CLEANING OF YOUR POOL PREPARING YOUR POOL IN THE SPRING At the end of winter, allow the ice in the pool to thaw completely. When the temperature reaches approximately 10 °C (50 °F), you have to restart your filtration system, since algae and bacterial form more quickly as it gets warmer.
  • Page 60 POOL MAINTENANCE Section SPRINGTIME CLEANING OF YOUR POOL PREPARING YOUR POOL IN THE SPRING CONTINUED When the pH and alkaline levels are ideal, apply a shock-treatment or chlorinate your water. Let it filter for 24 hours and again verify both the pH and free chlorine l evels. NOTE: Add chemical products to your pool after sunset, as sunlight rapidly destroys chlorine.
