RM6XX0
User Manual
All rights reserved. Product description and product specifications are subject to change without notice.
For latest product information, please visit Acnodes' website at www.acnodes.com
14628 Central Ave. Chino, CA 91710
© Copyright 2019 Acnodes Corp.
7U / 8U / 9U Rackmount Monitor
17" / 19" / 20" TFT LCD Display
DVI-D & VGA Video Input
Tel: 909.597.7588
Fax: 909.597.1939
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Acnodes RM60 Series
Summary of Contents for Acnodes RM60 Series
- Page 1 DVI-D & VGA Video Input User Manual All rights reserved. Product description and product specifications are subject to change without notice. For latest product information, please visit Acnodes’ website at www.acnodes.com 14628 Central Ave. Chino, CA 91710 Tel: 909.597.7588 Fax: 909.597.1939...
- Page 2 Legal Information First English printing, July 2019 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents RM6170 | RM6190N | RM6210 < Part. 1 > Package Content Structure Diagram & Dimension P.1 - 4 Installation < Part. 2 > Specifi cations / OSD / Remote Controller Product Specifi cations P.6 - 9 On-screen Display Operation ( OSD ) P.10 - 11 <...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content RM6170 or RM6190N or RM6210 X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 < 1.2 > Structure Diagram RM6170 Front view RM6190N RM6210 Rear view Power adapter LCD panel LCD membrane...
- Page 6 < 1.2 > Dimension - RM6170 Front View Side View UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 480 x 54.2 x 310 mm 529 x 124 x 495 mm 6.1 kg 8.2 kg...
- Page 7 < 1.2 > Dimension - RM6190N Front View Side View UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 480 x 53.3 x 354.8 mm 539 x 129 x 529 mm 5.7 kg 8 kg...
- Page 8 < 1.2 > Dimension - RM6210 Front View Side View UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 480 x 63.5 x 399 mm 583 x 124 x 529 mm 8.4 kg 10.7 kg...
- Page 9 < 1.3 > Installation RM6170 | RM6190N Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided. Step ■ Fix the LCD into the rack. RM6210 Step ■...
- Page 10 < Part 2 > < 2.1 > Product Specifications - RM6170 | RM6190N RM6170 RM6190N Panel Manufacturer Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024 Brightness ( typ.
- Page 11 Operating Temperature 0 to 55°C degree Environmental Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random RM6170 RM6190N Physical Specifi...
- Page 12 < Part 2 > < 2.1 > Product Specifications - RM6210 Manufacturer Panel Panel Size ( diagonal ) 20-inch TFT color LCD Display pixel ( dots x lines ) 1600 x 1200 Brightness ( typ. ) Contrast Ratio ( typ. ) 800:1 Color 16.7 M...
- Page 13 Operating Temperature 0 to 55°C degree Environmental Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Product ( W x D x H ) 480 x 63.5 x 399 mm Physical Specifi...
- Page 14 < 2.2 > On-screen Display Operation ( OSD ) RM6190N Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen...
- Page 15 < 2.2 > On-screen Display Operation ( OSD ) OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc:...
- Page 16 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input The SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed with displays, input module can support up to 1080p @ 60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 17 ( Multi-display Control ) More control is always good. Especially when it is necessary and easy. Acnodes provides MCS solution to control the OSD of various LCD display up to 64 units. The RS-232C is used for the communication between the PC and the first display via a 15 feet serial cable while the CAN bus is used...
- Page 18 < 3.3 > Options : AV2.2D Upgrade ( DVI-D TMDS single link ) - DVI-D ( S-Video + Composite, BNC ) - AV ( Built-in Dual Stereo Speakers, 2W x 2 ) - Audio ( 3.5mm audio jacks for audio in & out ) Audio DVI-D Power...
- Page 19 < 3.5 > Options : AV3.0 Upgrade ( HDMI 1.3, CEA-861-D ) - HDMI ( DVI-D TMDS single link - DVI-D ( S-Video + Composite, BNC ) - AV ( Built-in Dual Stereo Speakers, 2W x 2 ) - Audio ( 3.5mm audio jacks for audio in &...
- Page 20 < 3.6 > Options : Touchscreen & Driver 17" / 19" USB Touchscreen Specifi cation 17” 19” 17” 19” Model e-Resistive e-Capacitive 5-Wire Resistive Capacitive Technology Single Single Touch Point Stylus or Finger Finger Method ≤ 50g / Stylus=R0.8 ≤ 50g Activation Force 35 million touches 300 million touches...
- Page 21 < 3.6 > Options : Touchscreen & Driver TRB & TCB Driver Please follow the below steps to setup the touch screen: Step 1. Run the bundled CD disc Step 2. Double click the Setup.exe Step 3. Follow the installation instruction to fi nish the setup Step 4.
- Page 22 < 3.7 > Options : DC Power Model 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 50 mA 35 mA - Full load...
- Page 23 < 3.8 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MS3470W8-33P MIL - DTL - 26482 MIL - type DC Power ( Male ) Connector MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
