INSTALLATION MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating
your set and retain it for future reference.
32LY340C-UA
42LY340C-UA
47LY340C-UA
55LY340C-UA
42LY540S-UA
47LY540S-UA
55LY540S-UA
32Y340H-UA
39Y340H-UA
42Y340H-UA
47Y340H-UA
55Y340H-UA
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG 32LY340C-UA
Summary of Contents for LG 32LY340C-UA
- Page 1 INSTALLATION MANUAL LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32LY340C-UA 42LY540S-UA 32Y340H-UA 42LY340C-UA 47LY540S-UA 39Y340H-UA 47LY340C-UA 55LY540S-UA 42Y340H-UA 55LY340C-UA 47Y340H-UA 55Y340H-UA www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DigiTAL SigNAgE MEDiA PLAyEr Digital Signage Media Player Overview iNSTALLATiON MENu Introduction Public Display Settings TV Manager - 1. USB - 2. Diagnostics Password Change Set ID Setup Configuration Setup Multi Timer Lock Mode External Speaker HCEC Setup SuperSign Server Setup... -
Page 3: Digital Signage Media Player
DigiTAL SigNAgE MEDiA PLAyEr Digital Signage Media Player Overview (* Only for LY540S series) The Digital Signage Media Player can play content produced and distributed by SuperSign Elite-W. Supported content types consist of photographs, videos, external inputs such as TV broadcasts, texts, and music. -
Page 4: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 5: Public Display Settings
Public Display Settings y Image shown may differ from your TV. Installation Menu (V 3.0) Public Display Settings (V 3.0) ▲ LG Hotel Mode Setup Public Display Settings Public Display Mode ► ◄ TV Manager • Power On Status Password Change •... - Page 6 Operation’ and ‘Local Key Operation’ will be worked by below. (4-1) ir Operation Decide whether work the LG remote control or not. y Able to set Normal, Use PWR Only, Block All y When ‘IR Operation’ is set to Block All, all normal remote keys don’t work. Use PWR Only (Block except power) makes block all remote keys except power key.
- Page 7 (4-2) Local Key Operation Decide to operate 'Local/Front Key' working behavior by setting ‘Local Key Operation’ as Normal, Use PWR Only, Block All. y When 'Local Key Operation' is set to Block All, all local keys don’t work. If value is Use PWR Only, it blocks all local keys except power key.
- Page 8 Channel Change (5-3) Decide to change channel or not by setting ‘Channel Change' as ‘Yes’(Change Possible) or ‘No’(Change Impossible) when present source is TV. y When ‘Channel Change' is set to No (Change Impossible) » Channel Key, Numeral Key, List Key, Q.View Key don't work and entering 'Channel Menu' in the Main Menu OSD is impossible.
- Page 9 (6) Power Management The Power Management feature will turn off the television receiver if no input control command is received from either the Local or IR Key within a selected hours. y Activity on either of these inputs shall restart the ‘Power Management’ timer and check key time interval again.
- Page 10 (8-5) A/V Setting If ‘A/V Setting’ is changed from ‘No’ to ‘Yes’, parameters that are set before entering ‘Installation Menu’ are applied whenever turn on power. y Following Parameters are applied to basic. » Picture section - PSM mode, Picture Data (Contrast, Brightness, Color, Sharpness, Tint) »...
- Page 11 (10) Factory reset Factory reset returns all the parameters to the default settings. • Factory Reset Confirm y Press ‘Enter key’ to proceed factory reset. and confirmation message window will be shown. All user settings and channel settings will be reset. Still Continue? y When select ‘Yes’, all television settings except UTT value should write to the default settings.
- Page 12 Public Display Settings (Value Range Table) item Enable Disable initail Public Display Mode Power On Status *STD Volume Start Volume Off, Minimum Volume ~ Maximum Volume Maximum Volume Minimum Volume ~ 100 Minimum Volume 0 ~ Maximum Volume Key Management IR Operation Work (0) / Use PWR Only (1) / Bock All (2) Work (0)
-
Page 13: Tv Manager
TV Manager 1. USB Ez Download Ez Download is a function that enables users to download the desired items all at once, such as EPK (software update file), TLL (see Send to USB descriptions for more information regarding file types), Logo Image, etc (TLX, MICOM for Pro:Centric). * Splash images and EPK files should be copied into the folder named LG_DTV on the USB. - Page 14 Select the EPK option (software update) and then use the green and yellow buttons to download either SPI Boot or LG Boot Logo. If you checked the LG Boot Logo checkbox, then the Splash image, if selected, will be unchecked. Also, if you select the LG Boot Logo and proceed with the download, the existing Splash image will be deleted.
- Page 15 USB Cloning An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead.
- Page 16 Receive From USB y Image shown may differ from your TV. Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) Public Display Settings TV Manager Password Change...
- Page 17 Send To USB y Image shown may differ from your TV. Plug USB memory card into the USB port of the TV. button to select the TV Manager option and then press the OK button. Use the Installation Menu (V 3.0) Public Display Settings TV Manager Password Change...
- Page 18 CABLE IN Use the button to select the TV Manager option and then press the OK button. RS-232C IN Installation Menu (V 3.0) (CONTROL & SERVICE) LG Hotel Mode Setup TV Manager Password Change Set ID Setup Configuration Setup Multi Timer...
-
Page 19: Diagnostics
2. Diagnostics Diagnostics Setup introduction This diagnostic function provides current status information of the TV in XML file format using a USB device. If the user sets a signal standard level, SignalTrace checks the signal strength status of the digital channel that the user tuned to. It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format. - Page 20 (3) Saving signal status information of digital channels through SignalTrace in XML format y Go to Installation menu -> TV Manager -> Diagnostics -> Diagnostics Setup y Set the level value in Signal Tracer Set. (Disable, 10 to 90) TV Manager Diagnostics Setup Diagnostics Setup Signal Tracer Set...
-
Page 21: Password Change
Password Change y Image shown may differ from your TV. - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V 3.0) Public Display Settings TV Manager Password Change Password Change Password Change Change Password Set ID Setup Confirm Password Configuration Setup... -
Page 22: Set Id Setup
Set ID Setup Installation Menu (V 3.0) Public Display Settings Set ID Setup TV Manager Password Change Set ID Lock ◄ ► Set ID Setup Set ID setup Set ID Configuration Setup Previous Multi Timer Lock Mode External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the Set ID Setup. -
Page 23: Configuration Setup
Configuration Setup y Image shown may differ from your TV. Configuration Setup Installation Menu (V 3.0) Number of RCU Public Display Settings Splash Offset Time +0 Sec TV Manager Big UI Display Password Change ◄ ► USB Auto Playback Set ID Setup Disable Configuration Setup 15Min Auto Off... - Page 24 For the audio signal, the priority order is the RGB -> AV -> Audio In component ports. (8) Screen Saver Cube y When ‘Screen Saver Cube’ is set to ‘No’, TV will do not display LG Screen Cube. (9) Video Mute y When 'Video Mute' is set to 'Yes', for Blank.
-
Page 25: Multi Timer
Multi Timer Installation Menu (V 3.0) Public Display Settings TV Manager Multi Timer Password Change Multi Timer ◄ ► Set ID Setup On Timer Configuration Setup Off Timer Multi Timer Multi Timer Previous Lock Mode External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the Multi Timer. -
Page 26: Lock Mode
Lock Mode Installation Menu (V 3.0) Public Display Settings Lock Mode TV Manager Enable Data Service ◄ ► Password Change Enable Set ID Setup Factory Reset Enable Configuration Setup Previous Multi Timer Lock Mode Lock Mode External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the Lock Mode. -
Page 27: External Speaker
External Speaker Installation Menu (V 3.0) Public Display Settings TV Manager External Speaker Password Change Fixed ◄ ► Volume Control Set ID Setup 1 Watt Output Configuration Setup Multi Timer Previous Lock Mode External Speaker External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the External Speaker. - Page 28 Speaker output SETUP Connect the external speaker to the external speaker out jack on the TV. EXTERNAL SPEAKER OUT RIGHT LEFT NOTE y External speaker must be used three plug(SE : Single Ended, Stereo) as shown in the drawings and external speaker fully inserted with external Speaker Jack.
-
Page 29: Hcec Setup
HCEC Setup Installation Menu (V 3.0) Public Display Settings HCEC Setup TV Manager CEC Mode Default ◄ ► Password Change IR Decoding Set ID Setup Device ID Configuration Setup StandBy Multi Timer Lock Mode HTNG HotelMode External Speaker Previous HCEC Setup HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the... - Page 30 (c) Stand By y Sets the sending and receiving scenario of OpStandBy(0x0c) command. y The detailed scenario is described on the table below. Send receive Send Only Receive Only * Send : TV sends OpStandBy(0x0c) when TV is turned off. * Receive : TV is available to be turned off by OpStandBy(0x0c) (2) HTNg HotelMode y If the following options are selected because of the HTNG command:...
-
Page 31: Supersign Server Setup
SuperSign Server Setup (* Only for LY540S series) Installation Menu (V 3.0) Public Display Settings TV Manager SuperSign Server Setup Password Change Play Name Press OK Set ID Setup Server IP Setting Press OK Configuration Setup Server IP Status Multi Timer Not connected Lock Mode Previous...
