Fault Messages - BWT AQA perla XL Installation And Operating Manual

Fault
01.07.14
10:45:21
Drain 2 overflow
Fault
01.07.14
10:45:21
AQA Stop triggered
Info (Help button)
Press the question mark
8.14

Fault messages

Fault messages are indicated by a red screen and
a short description of the fault.
Example: Overflow fault
Acknowledge the fault
If a persistent problem arises, disconnect the mains
plug and turn the handwheel on the Multiblock mod-
ule to close it all the way (this opens the bypass for
the water supply).
Contact the after-sales service staff if the fault is
still displayed.
Example: AQA Stop triggered
The floor sensor has detected water or continuously
flowing water has exceeded the amount specified.
Resolve the issue.
Dry the floor sensor if necessary.
Hold down the Enter button for 5 seconds.
Alternatively, remove the mains plug, wait 10 sec-
onds and then plug back in.
The control valve will open again to let water
through.
EN
81
81
