KA01184C/07/EN/01.15
71284412
Valid as of:
Softwareversion 01.05.02
Products
Brief Operating Instructions
Liquistation CSF39
Automatic sampler for liquid media
These Instructions are Brief Operating Instructions; they are not
a substitute for the Operating Instructions pertaining to the
device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation via:
• www.endress.com/device-viewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liquistation CSF39 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Liquistation CSF39

Summary of Contents for Endress+Hauser Liquistation CSF39

  • Page 1 These Instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation via: • www.endress.com/device-viewer • Smart phone/tablet: Endress+Hauser Operations App...
  • Page 2 Liquistation CSF39 Order code 00X00-XXXX0XX0XXX Ser. No.: X000X000000 TAG No.: XXX000 Serial number www.endress.com/deviceviewer Endress+Hauser Operations App Endress+Hauser...

  • Page 3: Table Of Contents

    Table of contents Liquistation CSF39 Table of contents 1 Document information............5 1.1 Warnings .

  • Page 4: Document Information

    Liquistation CSF39 Document information Document information Warnings The structure, signal words and safety colors of the signs comply with the specifications of ANSI Z535.6 ("Product safety information in product manuals, instructions and other collateral materials"). Safety message structure Meaning This symbol alerts you to a dangerous situation.

  • Page 5: Documentation

    Liquistation CSF39 Documentation The following manuals which are available on the product pages complement these Operating Instructions: • Brief Operating Instructions Liquistation CSF39 • Operating Instructions Memosens, BA01245C – Software description for Memosens inputs – Calibration of Memosens sensors – Sensor-specific diagnostics and troubleshooting •...

  • Page 6: Basic Safety Instructions

    Designated use Liquistation CSF39 is a stationary sampler for liquid media. The samples are taken discontinuously using a vacuum pump or peristaltic pump and are then distributed into sample containers and optionally refrigerated.

  • Page 7: Operational Safety

    IT security measures in line with operators' security standards and designed to provide additional protection for the device and device data transfer must be implemented by the operators themselves. Support in the performance of this task can be requested from Endress+Hauser. Endress+Hauser...

  • Page 8: Incoming Acceptance And Product Identification

    Liquistation CSF39 Incoming acceptance and product identification Incoming acceptance and product identification Incoming acceptance 1. Make sure the packaging is undamaged.  Inform your supplier of any damage to the packaging. Keep the damaged packaging until any issues have been resolved.

  • Page 9: Product Identification

    To find out the version of your device, enterthe order code indicated on the nameplate into the search screen at the following address: www.endress.com/order-ident Scope of delivery The scope of delivery comprises: • 1 Liquistation CSF39 with: – The ordered bottle configuration – Optional hardware • Accessories kit For peristaltic or vacuum pump: –...

  • Page 10: Certificates And Approvals

    Liquistation CSF39 Incoming acceptance and product identification Certificates and approvals Declaration of Conformity The product meets the requirements of the harmonized European standards. As such, it complies with the legal specifications of the EC directives. The manufacturer confirms successful testing of the product by affixing to it the mark.

  • Page 11: Installation

    Installation Liquistation CSF39 Installation Installation conditions 4.1.1 Dimensions a0013080 Fig. 1: Dimensions of plastic version of Liquistation CSF39 without/with stand. Engineering unit mm (in). Suction line connection Endress+Hauser...
  • Page 12 Liquistation CSF39 Installation a0013082 Fig. 2: Dimensions of stainless steel version of Liquistation CSF39 without/with stand. Engineering unit mm (in). Suction line connection Endress+Hauser...
  • Page 13 Liquistation CSF39 4.1.2 Mounting location For version with pump a0011693 Fig. 3: Mounting conditions for Liquistation CSF39 for open channels Correct The suction line must be routed with a downward slope to the sampling point. Incorrect The sampler should never be mounted in a place where it is exposed to aggressive gases, e.g.
  • Page 14 Liquistation CSF39 Installation 7. Do not mount the device directly over the inlet channel of a municipal wastewater treatment plant. Note the following when mounting the sampler: 1. Place the device on a level surface. 2. Protect the device from additional heating (e.g. from heaters).
  • Page 15 Installation Liquistation CSF39 4.1.3 Mechanical connection Foundation plan 730 (28.7) 311 (12.2) 305 (12.0) 255 (10.0) 302 (11.9) 214 (8.43) 786 (30.9) a0012761 Fig. 4: Foundation plan. Engineering unit mm (in). Fasteners (4 x M10) Cable inlet Outlet for condensate and overflow > DN 50 Sample supply from below >...

  • Page 16: Mounting The Device

    Liquistation CSF39 Installation 4.1.4 Connection for sampling • Maximum suction height: Vacuum pump: Standard 6 m (20 ft), 8 m (26 ft) optional Peristaltic pump: standard 8 m (26 ft) • Maximum hose length: 30 m (98 ft) • Hose connection diameter: Vacuum pump: 10 mm (3/8"), 13 mm (1/2"), 16 mm (5/8") or 19 mm (3/4") internal diameter...
  • Page 17 Installation Liquistation CSF39 Gland for the suction line Suction line a0013704 Fig. 5: Sample supply from below Connecting the suction line in the version with the vacuum pump 1. Unscrew the thread adapter nut (item 3). 2. Unscrew the hose gland (item 4) from the side panel.
  • Page 18 Liquistation CSF39 Installation a0013708 a0013707 Fig. 7: Suction line connected from below Fig. 6: Connecting the suction line from the side (as-delivered state) Hose Fixing clip for hose gland Thread adapter nut Hose gland Connecting the suction line in the version with the peristaltic pump 1.

  • Page 19: Post-Installation Check

    Installation Liquistation CSF39 Post-installation check • Make sure the suction line is securely fitted to the device. • Perform a visual inspection to ensure the suction line is routed correctly from the sampling point to the device. • Ensure that the distribution arm is correctly engaged.

  • Page 20: Electrical Connection

    Liquistation CSF39 Electrical connection Electrical connection WARNING Device is energized Incorrect wiring can result in injury or fatality ‣ The electrical connection must only be carried out by a certified electrician. ‣ Technical personnel must have read and understood the instructions in this manual and must adhere to them.

  • Page 21: Connecting The Sampler

    Electrical connection Liquistation CSF39 5.1.2 Remote operation via Ethernet/web server FieldCare / Webbrowser Ethernet CM442R/ CM442 / FXA291 CM444R/ CM444 / CM448R CM448 / CSF39 CA80 A0024607 Fig. 11: Modbus TCP and/or Ethernet Connecting the sampler NOTICE The device does not have a power switch ‣...
  • Page 22 Liquistation CSF39 Electrical connection 5.2.1 Routing the cables • Route the cables behind the rear panel of the device so that they are properly protected. • Cable glands are available for the cable entries (up to 8, depending on the version).
  • Page 23 Electrical connection Liquistation CSF39 5.2.3 Removing the rear panel of the dosing compartment Open the dosing compartment door to remove the rear panel of the dosing compartment. a0012803 a0012826 Fig. 12: Screw above the dosing compartment Fig. 13: Lift up the top rear panel and pull it back to...
  • Page 24 Liquistation CSF39 Electrical connection 5.2.5 Removing the cover on the power unit WARNING Device is energized Incorrect wiring can result in injury or fatality ‣ Make sure the device is disconnected from the power source before you remove the cover of the power unit.
  • Page 25 Electrical connection Liquistation CSF39 5.2.6 Power supply terminal assignment The power supply is connected via plug-in terminals. Connect the ground to one of the ground connections. Rechargeable batteries are available as an option (for battery type see section Technical Data).
  • Page 26 Liquistation CSF39 Electrical connection 5.2.7 Cable terminals Plug-in terminals for Memosens and PROFIBUS/RS485 connections a0012691 a0012692 a0012693 Fig. 18: Press the screwdriver against Fig. 19: Insert the cable until the limit Fig. 20: Remove the screwdriver (closes the clip (opens the terminal)

  • Page 27: Connection Compartment In The Controller Housing

    Electrical connection Liquistation CSF39 Connection compartment in the controller housing The controller housing has a separate connection compartment. Release the 6 housing screws to open the connection compartment: a0012843 Fig. 24: Release 6 housing screws with a Phillips screwdriver to open the display cover a0013238 Fig.
  • Page 28 Liquistation CSF39 Electrical connection 5.3.1 E basic module a0016535 Fig. 26: E basic module Indicator LEDs SD card slot Voltage connection Slot for the display cable Alarm relay connection Service interface Power supply for digital fixed cable sensors Connections for 2 Memosens sensors...
  • Page 29 Electrical connection Liquistation CSF39 5.3.2 Sampler controller The connections for the sampler controller are in the controller housing, see section "Connection compartment in the controller housing". Analog inputs and binary inputs/outputs a0012988 Fig. 28: Position of the terminals Analog inputs 1 and 2...
  • Page 30 Liquistation CSF39 Electrical connection a0015214 Fig. 30: With two-wire transmitter, e.g. Liquiline M CM42 a0015212 Fig. 31: With four-wire transmitter, e.g. Prosonic S FMU90 Binary inputs a0013381 Fig. 32: Assignment of binary inputs 1 and 2 Binary input 1 (191/192)
  • Page 31 Electrical connection Liquistation CSF39 When connecting to an internal voltage source, use the terminal connection on the rear of the dosing chamber. The connection is located on the lower terminal strip (on the far left, + and -), see the "Power supply terminal assignment" section.
  • Page 32 Liquistation CSF39 Electrical connection Binary outputs with relay option a0016343 Fig. 36: Relay Binary output 1 Binary output 2 The left relay is activated with binary output 1, while the right relay is activated by binary output a0016348 Fig. 37: Connection example for binary output with relay...

  • Page 33: Terminal Assignment For Input/Output Signals

    Electrical connection Liquistation CSF39 Terminal assignment for input/output signals The following signals can be configured for external sampler control: Input signals • 2 analog signals 0/4 to 20 mA • 2 binary signals > 100 ms pulse width or edge •...
  • Page 34 Liquistation CSF39 Electrical connection 5.5.2 Connecting sensors with Memosens protocol a0012459 a0012460 Fig. 38: Sensors without additional supply voltage Fig. 39: Sensors with additional supply voltage a0016197 Fig. 40: Sensors with and without additional supply voltage at sensor module 2DS...
  • Page 35 Electrical connection Liquistation CSF39 5.5.3 Sensor connection Before you connect a sensor to the controller, you must first route it via the back panel to the controller housing towards the front. See the "Removing the rear panel of the dosing compartment"...
  • Page 36 Liquistation CSF39 Electrical connection a0016356 Fig. 43: Terminal strip Endress+Hauser...

  • Page 37: Connecting Additional Inputs, Outputs Or Relays

    Electrical connection Liquistation CSF39 Connecting additional inputs, outputs or relays WARNING Module not covered No shock protection. Danger of electric shock! ‣ If you are modifying or extending your hardware, always fill the slots from top to bottom. Do not leave any gaps.

  • Page 38: Post-Connection Check

    Liquistation CSF39 Electrical connection Post-connection check WARNING Wiring errors Incorrect wiring puts the safety of people and the measuring point at risk. The manufacturer does not accept any responsibility for errors that result from failure to comply with the instructions in this manual.

  • Page 39: Operation Options

    Operation options Liquistation CSF39 Operation options Overview 6.1.1 Display and operating elements Navigator (jog/shuttle and press/hold function) Soft keys (function depends on the menu) Display (red background in the event of an A0025501 Fig. 46: Overview of operation (example) error) 6.1.2 Display...

  • Page 40: Access To The Operating Menu Via The Local Display

    Liquistation CSF39 Operation options Access to the operating menu via the local display 6.2.1 Operation concept a0013353-de a0013354-de Fig. 48: Pressing the soft key: selecting the menu directly Fig. 49: Turning the navigator: moving the cursor in the menu a0013355-de a0013356-de Fig.

  • Page 41: Configuration Options

    Operation options Liquistation CSF39 6.2.2 Locking or unlocking operating keys Locking operating keys 1. Press the navigator for longer than 2 s.  A context menu for locking the operating keys is displayed. You have the choice of locking the keys with or without password protection. "With password"...
  • Page 42 Liquistation CSF39 Operation options 6.3.3 Numerical values • You are changing a variable. • The maximum and minimum values for this variable are shown on the display. • Set a value within this range. • Example: Menu/Display/Operation/Contrast 6.3.4 Actions • You trigger an action with the appropriate function.
  • Page 43 Operation options Liquistation CSF39 6.3.6 Tables • Tables are required in order to represent mathematical functions. • To edit a table, use the navigator to move through the rows and columns and change the cell values. • You only edit numerical values. The controller automatically takes units of measure into account.

  • Page 44: Commissioning

    Liquistation CSF39 Commissioning Commissioning Function check WARNING Incorrect connection, incorrect supply voltage Safety risks for staff and incorrect operation of the device ‣ Check that all connections have been established correctly in accordance with the wiring diagram. ‣ Make sure that the supply voltage matches the voltage indicated on the nameplate.
  • Page 45 Commissioning Liquistation CSF39 7.2.3 Display settings Path: Menu/Operation/Display Function Options Info Display Contrast 5 to 95 % Adjust the screen settings to suit your working environment. Factory setting Backlight="Automatic" 50 % The backlighting is switched off automatically after a short time if a button is not pressed. It switches back on Backlight.
  • Page 46 Liquistation CSF39 Commissioning Path: Menu/Operation/Display Function Options Info Number of lines 1 to 8 Specify the number of measured values displayed. Factory setting Line 1 As the following functions are the same for all the lines, they are only described once.

  • Page 47: Basic Setup

    Commissioning Liquistation CSF39 Path: Menu/Operation/Display Function Options Info Show summary of current program The bottle statistics of the sampler are displayed. The statistics appear for each individual bottle after the program is started. For more information, see the "Bottle statistics" section.

  • Page 48: Sampling Program

    Liquistation CSF39 Commissioning Sampling program a0024843-de 7.4.1 Manual sampling 1. Manual sampling is triggered by the "MAN" soft key. This pauses any program currently running.  The current bottle configuration and the current sample volume are displayed. The distributor position and sample volume can be changed.
  • Page 49 Commissioning Liquistation CSF39 7.4.2 Programming for automatic sampling Create a simple sampling program in the general overview under "Select sampling program/New/Basic" or in the "Menu/Setup/Sampling programs/Setup program/New/Basic" menu: • Enter the "Program name". • The settings from the "Basic setup" for bottle configuration and bottle volume are displayed.
  • Page 50 Liquistation CSF39 Commissioning Endress+Hauser...
  • Page 51 71284412 www.addresses.endress.com...
