Check that...
• You have correctly identified the wires.
• The connections are tight.
Commissioning
• Refit the base onto the product using screws (A).
• Locate the product over the drilled holes and fix in
position using screws (C).
Fitting/replacing bulbs
• This system contains non-replaceable parts and
cannot be serviced. If damage occurs the part should
be scrapped.
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Safety information
For your safety, always switch off the supply before cleaning.
The LED's are protected by a lens. This part must be replaced immediately should the lens become
cracked or damaged. This fitting must not be used without the lens in place.
Replace Cracked
Shade
www.saxbylighting.com
• No loose strands have been left out of the connection
block.
• Adjust the floodlight head to the desired angle.
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use.
Iss.1 09052012
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
Magma Flood Light
43784
Advertisement
Table of Contents
Related Manuals for Saxby Lighting Magma 43784
Summary of Contents for Saxby Lighting Magma 43784
- Page 1 Check that... Instruction leaflet • You have correctly identified the wires. • No loose strands have been left out of the connection • The connections are tight. block. Magma Flood Light Commissioning 43784 • Refit the base onto the product using screws (A). • Adjust the floodlight head to the desired angle. • Locate the product over the drilled holes and fix in • Replace fuse or circuit breaker and switch on. Your position using screws (C).
- Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before • The product must be mounted onto a concrete base installation of a new product. Before removing the or paving slab. It should not be directly installed on existing fitting, carefully note the position of each set the soil. Details of fixing positions are given below in Warning of wires. Fig 1. Verify the base fits before drilling. • Drill and plug (B) the at the marked positions. • Decide on the optimum location for the product. This is a Class 1 product and must be earthed. The unit cannot be dimmed. • Wire as detailed below. • Undo the three screws (A), and set side. Remove Please read these instructions carefully before This system contains non-replaceable parts and base plate.
