- Page 1 X2245 X2244 Please keep this instruction sheet for future reference, as it contains important information. Adult assembly is required. Required tools: Hammer, Phillips Screwdriver and Scrap Block of Wood (not included). Age: 2 - 6 years; Weight Limit: 60 lbs (27 kg). www.fisher-price.com...
- Page 2 Consumer Information WARNING TO AVOID SERIOUS INJURY: • Continuous adult supervision is required. Cap Nut #8 x " (1,9 cm) Screw – 4 • Never use near cars and other motor vehicles, near streets, steps, sloped driveways, hills, roadways, alleys, swimming pools or other bodies of water. #8 x 3" (7,6 cm) Screw – 1 • Always wear shoes. • Never allow more than one rider. FASTENERS SHOWN ACTUAL SIZE Parts • Please save all packaging material until assembly is complete to ensure that no parts are discarded. • Please wipe each part with a clean, dry cloth before assembly. • Some parts shown are assembled to both sides of the trike. • Tighten the assembled screws with a Phillips screwdriver. Do not over-tighten the screws. Handlebar Seat Seat Retainer Straight Axle Fork Rear Wheel 2 Hubcaps 2 Covers 2 Fork Covers Frame Cap Nut 2 Pedals...
- Page 3 Assembly CAUTION Rear Wheel Indented Side Up Cap Nut This product contains small parts Hubcap in an unassembled state. Adult assembly is required. Straight Axle Frame Cover Hubcap Assembled Rear Wheel Cap Nut Rear Wheel Assembly Tool Indented Side Down Hubcap • Place a scrap block of wood on a flat surface. • Turn the frame on its side with the exposed end of the Straight Axle straight axle up. • Place the cap nut assembly tool under the assembled rear wheel and onto the cap nut. • Slide a rear wheel (indented side up) onto the end of the • Slide a hubcap (peg side up) onto the straight axle. straight axle. • Slide a rear wheel (indented side down) onto the • Slide a hubcap (peg side down) onto the straight axle. straight axle. • Place a cap nut on the end of the straight axle. • Tap the cap nut with a hammer. Gently pull the rear wheel up to be sure the cap nut is securely attached to the straight axle.
- Page 4 Assembly Pedal Hubs Pedal Axle Pedal Front Wheel Hole Pedal Axle Front Wheel Assembly • While holding the pedal hubs on the pedal axle, insert the pedal axle through the hole in the center of the front wheel. • Push the pedal hubs into the center of the front wheel until • Place a scrap block of wood under the front wheel assembly they are flush with the surface of the front wheel. with the exposed end up. • Fit a pedal on the pedal axle. • Tap the pedal with a hammer until it is secure. Pedal Hub Pedal Axle Fork Arms Fork Cover Pedal Hub Groove Pedal Axle • Place the front wheel assembly between the fork arms. Make sure the pedal axle fits into the groove at the bottom of each fork arm. • Turn the front wheel assembly over. • Place a fork cover over the pedal axle on one fork arm. • Insert a pedal hub onto the top of the pedal axle and into • Insert two #8 x " (1,9 cm) screws through the fork cover the hole in the center of the front wheel.
- Page 5 Assembly Seat Retainer Handlebar Seat Frame Neck Fork Post Peg Holes Fork Cover • Position the seat upside down. Rear of Trike • Fit the small pegs on the seat retainer into the holes in the seat. • Turn the frame upright. • Insert the fork post up through the hole in the neck of the frame. Make sure the fork is positioned so that the fork covers face the rear wheels. • Place the handlebar over the fork post and push it down onto the frame. Make sure the handlebar is positioned so that the screw hole faces the rear wheels and aligns with the screw hole in the fork post. Hint: You may need to rotate the handlebar to align the holes.
- Page 6 Albany 1331, Auckland. Frame Seat Retainer Tab • Turn the frame on its side. • Squeeze the seat retainer tabs toward one another and lift the seat from the frame. Fisher-Price, Inc., a subsidiary of Mattel, Inc. East Aurora, New York 14052, U.S.A. PRINTED IN MExICO ©2011 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. x2244pr-0920...
