Summary of Contents for Sensorex UVT-LED-PW

  • Page 1 QUICK START GUIDE...
  • Page 2 THANK YOU FOR CHOOSING THIS UVT-LED-PW UV-TRANSMITTANCE SENSOR. For over forty years, Sensorex has been the preeminent supplier of leading edge technology and innovative products to measure and monitor the quality of water. Today, we remain focused on the continual advancement of water quality monitoring products and technology.
  • Page 3 STEP 3 – INSTALLING THE UVT-LED Once calibrated, the UVT-LED is ready to be installed in the process. There are several op- tions for installation, including in-line and bypass, which are recommended by Sensorex. A) Weld on stainless steel sanitary flange B) 2”...
  • Page 4 #8. Install 2”NPT x 1.5” sanitary flange adapter (#4) onto top of #5. Insert 1.5” sanitary gasket into groove on top of #4. Install UVT-LED-PW sensor (#1) into #4 with #3. Attach provided 1.5” sanitary clamp (#2) around flange of #4 and flange of #1. Tighten clamp to seal sensor using wing nut on #2.
