ASTI LEVER
B ar Mi xer
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE LABEL ON THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The mixer shower installation MUST be carried out by a suitably qualified person, in the sequence
of this instruction book.
IMPORTANT SAFETY ADVICE
The shower head and hose supplied with
this product are a safety critical part of your
shower. Failure to use genuine Triton parts may
cause injury and invalidate your guarantee.
2181430C - October 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Triton ASTI LEVER
Summary of Contents for Triton ASTI LEVER
- Page 1 (FROM THE LABEL ON THE FRONT OR TOP OF THE BOX) this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321...
-
Page 2: Table Of Contents
GUARANTEE, SERVICE POLICY, etc..........rear cover nstallers please note these InstructIons are to be left wIth the user To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Please see back of book for contact information. -
Page 3: Main Components
Inclusive Bar Mixer Shower MAIN COMPONENTS Fig.1 A. Thermostatic bar mixer valve B. Dogleg connector X2 C. Cover trim X2 All dimensions listed in this fitting book regarding the product and installation are approximate. *All kits are for illustration purposes only and are not supplied unless otherwise stated. -
Page 4: Introduction
Inclusive Bar Mixer Shower INTRODUCTION Water Temperature Requirements Recommended maximum: = 65°C This book contains all the necessary fitting and operating instructions for your mixer shower. Minimum hot water temperature: = 55°C Please read them carefully and read through Maximum cold water temperature: = 25°C the whole of this book before beginning your installation. - Page 5 Inclusive Bar Mixer Shower PLUMBING REQUIREMENTS Hard Water Areas a. If it is intended to operate the shower DO NOT use jointing compounds on any pipe in areas of hard water (above 200-ppm fittings for the installation. temporary hardness), a scale inhibitor DO NOT solder fittings near the mixer shower may have to be fitted.
-
Page 6: Typical Domestic Installations
Inclusive Bar Mixer Shower TYPICAL DOMESTIC *Diagrammatic view – not to scale. *Fig.2 INSTALLATIONS For illustration purpsoes only. Domestic Gravity Fed Systems ( fig.2) The mixer shower MUST be fed from a cold water cistern and hot water cylinder providing Stop valve nominally equal pressures. - Page 7 Inclusive Bar Mixer Shower Instantaneous Gas-heated Systems, *Diagrammatic view – not to scale. *Fig.4 e.g. combination boilers (fig.4) For illustration purpsoes only. The mixer shower MUST be installed with a multi-point gas water heater or combination boiler of a fully modulating design i.e. to maintain relatively stable hot water temperatures.
- Page 8 Inclusive Bar Mixer Shower Mains Pressurised thermal Store Systems *Diagrammatic view – not to scale. *Fig.6 fig.6) For illustration purpsoes only. Packages of this type, fitted with a tempering valve (blender valve) can be used. A drop tight pressure reducing valve MUST be fitted if the supply pressures exceed 5 bar running.
-
Page 9: Installation
Inclusive Bar Mixer Shower INSTALLATION *Diagrammatic view – not to scale. *Fig.7 For illustration purpsoes only. PREPARING THE SHOWER Check the contents to make sure all items are present. Before starting the installaion, make sure all of the openings on the valve are carefully covered to stop ingress of any debris etc. -
Page 10: Variable Fittings
Inclusive Bar Mixer Shower *VARIABLE FITTINGS Fig.8 The supply pipes can be routed from the side, rising, rear or falling and must end in suitable fittings to accept the variable connectors (fig.8). The variable connectors can be used to connect Appropriate to ½”... -
Page 11: Making Good
Inclusive Bar Mixer Shower MAKING GOOD Fig.10 Make good the wall and complete the tiling. NOTE: It is advised to use a suitable sealer around the variable connector where it enters the wall to stop water ingress (fig.9). Screw the supplied cover trims onto the fittings until tight to the wall (fig.10). -
Page 12: Fitting The Mixer Controls
Inclusive Bar Mixer Shower FITTING THE MIXER CONTROLS Fig.11 Maximum The mixer controls will need to be fitted before temperature commissioning can be carried out. stop Temperature Control - (fig.11) Fit the maximum temperature stop. The orientation is shown in fig.11. Fit the temperature control (right hand side) ensuring that the temperature override engages Marker to be... -
Page 13: Commissioning
Inclusive Bar Mixer Shower COMMISSIONING Fig.13 Start the water flow by rotating the flow control (left hand side) anti-clockwise. Mixer outlet Make sure that the hot and cold water supplies are fully open and at (or near to) their design temperature and pressures, and are within the requirements as stated on page 2 &... -
Page 14: Temperature Adjustment Range
Inclusive Bar Mixer Shower TEMPERATURE ADJUSTMENT RANGE Fig.14 Temperature The mixer has a temperature stop to prevent Override accidental rotation to higher temperatures. This Button is adjustable to provide a maximum temperature of 35°C – 45°C. The mixed water temperature can be adjusted from cold through to a top limit (which can be pre-set during installation –... -
Page 15: Operating The Shower
Inclusive Bar Mixer Shower OPERATING THE SHOWER Fig.16 To start the shower, rotate the flow control (left-hand side) anti-clockwise. For maximum flow, rotate the flow control anti-clockwise until it stops. To stop the water flow, rotate the flow control clockwise until the water stops flowing (fig.16). To adjust the water temperature, rotate the temperature control (right-hand side), clockwise for a cooler shower or anti-clockwise for a hotter... -
Page 16: Dimensions
Inclusive Bar Mixer Shower DIMENSIONS- All dimensions regarding the product and installation are approximate. -
Page 17: Approvals
Inclusive Bar Mixer Shower APPROVALS * BS EN 1111 This mixer valve is approved to the requirements of: *On pressures above 0.5 bar. * WRAS Designation: HP-S (high pressure shower only) PRODUCT FLOW RATES Flow Rate (l/m) 5.0 6.9 9.0 10.9 12.0 17.5 25.5 31.5 36.5 41.0 Pressure (bar) 0.1 0.2 0.3 Conditions for test... -
Page 18: Maintenance
Inclusive Bar Mixer Shower MAINTENANCE Cleaning It is recommended that all products are cleaned The following maintenance procedure must using warm, soapy water. be carried out for commercial and health care premises, but is not necessarily required for Do not use abrasive or aggressive chemical domestic installations. -
Page 19: Fault Finding
Inclusive Bar Mixer Shower FAULT FINDING The following can be carried out by a competent person Problem Cause Action 1 Water too hot. 1.1 Temperature 1.1.1 Refer to the Commissioning section. control incorrectly commissioned. 1.2 Not enough cold 1.2.1 Reposition temperature control knob water flowing through shower. - Page 20 Inclusive Bar Mixer Shower FAULT FINDING Problem Cause Action 4 Water does 4.1 Water supplies cut off. 4.1.1 Check water elsewhere in house and if not flow or necessary contact local water company. shower pattern 4.2 Shower unit blocked. 4.2.1 Inspect the inlet filters. Clean if necessary. collapses when 4.3 Blockage in pipework.
- Page 21 Inclusive Bar Mixer Shower...
- Page 22 Inclusive Bar Mixer Shower...
- Page 23 Inclusive Bar Mixer Shower...
- Page 24 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2021...
