- Page 1 VM-HT19LCD High Resolution 19” LCD MONITOR USER MANUAL Speco Technologies 200 New Highway Amityville, NY 11701 800-645-5516 / www.specotech.com...
-
Page 2: Warning
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: Explanation of Graphical Symbols CAUTION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Important Information
Important Information IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4. -
Page 4: Safety Precautions
Safety Precautions Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Table Of Contents
Table of Contents Warning…………………………………………………………………………………………………… 2 Important Information…………………………………………………………………………………… 3 Safety Precautions……………………………………………………………………………………….. 4 Table of Contents………………………………………………………………………………………… 5 Components………………………………………………………….. …………………………………. 5 Feature……………………………………………………………………………………………………. 6 Exploring Your New Monitor…………………………………………………………………………….. 7 Backside Connections…….………………………………………………………………………….…. 8 Selecting a Location for the Monitor…………………………………………………………………… 8 Connecting your Monitor………………………………………………………………………………… 9 Connecting Device………………………………………………………………………………………. 10 Setup your Monitor……………………………………………………………………..………………... -
Page 6: Feature
Features ■Professional TFT LCD for surveillance with multiple connections. ■Compatible with VGA(640X480), SVGA(800X600), XGA(1024X768), SXGA(1280X1024) resolution, ■Picture-In-Picture feature that allow multi-picture display ■High brightness level and contrast ration with super wide viewing angle ■Built-in 3D comb filter and 3D de-interlace for crispy picture performance ■Fast response time and refresh rate without time lagging. -
Page 7: Exploring Your New Monitor
Exploring Your New Monitor You can operate your monitor by using the buttons on the front panel. The side panels provide the inputs to connect other equipment to your monitor. Front Panel Back Side... -
Page 8: Backside Connections
Rear Connections (L) 6 1, 2 AUDIO 2 IN (R, L) Stereo Audio Signal Input, this input is for AV2 (Refer to Note below) 3, 4 AUDIO 2 OUT (R, L) Audio looping outputs for AUDIO 2 5, 6 AUDIO 1 IN (R, L) Stereo Audio Signal Input, this input is for AV1 or S-Video (Refer to Note below) 7, 8... -
Page 9: Connecting Your Monitor
Connecting your Monitor If you don’t have experience in electronic equipment connection before, you may wish to read this section. (Cables are not supplied, just for reference) Audio cables are usually color coded according to use: red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel. -
Page 10: Connecting Device
Connecting Accessories Connect PC to Monitor through VGA connector as shown on the above picture Connect External device such as DVD or Game Player to Monitor as shown on the above picture Connect CCD Camera 1 and 2 to Monitor through Video Input 1 and 2 (BNC Connector) as showing on the above picture Support Resolution... -
Page 11: Setup Your Monitor
Setup your Monitor Auto-optimize displaying picture under PC mode. AUTO: Enter: CCD Mode: Under AV/1 / AV2 / S-Video press Auto can be changed to OSD menu ON / OFF control. MENU: (EXIT Item) Increase or decrease the value on OSD menu. ADJUST: Down: Select input signal from AV1, AV2, S-Video or VGA (PC). -
Page 12: General Setup
General Setup Auto Source Detect : OSD Language : Power ON Control : Key Lock : Power Memorize : Channel Display : CCD Mode: Default : The monitor will auto detect the video source when power ON. Multi-Language selection in English. This function is to assign a specific video signal when power ON. -
Page 13: Video Setup
Video Setup Brightness : Contrast : Color : TINT : Sharpness : Color Temperature : Scale Mode : H-position : V-position : AGC Control : Default : Adjusts the overall picture shade and brightness. Permits adjustment of contrast between light and dark areas of the picture. -
Page 14: Vga Setup
VGA Setup A uto B rig h tne ss C o ntr ast C o lor Temp er at u re H -p os iti on V - Pos iti on C lo ck P ha se D e fau lt Auto : Brightness : Contrast :... -
Page 15: Audio Setup
Audio Setup Volume : Mute Default : Controls built-in speakers’ output volumes To disable the audio function. To enable, press MUTE again. Sets AUDIO settings to the original factory setting. -
Page 16: Pip Setup
PIP Setup Multi-Mode : Sub Source : Sub Window Size: Sub Window H-Position : Control the PIP window position in horizontal position. Sub Window V-Position : Control the PIP window position in vertical position. Switching : Switching Time : Audio Source: Auto Close : * PIP Hotkey: Auto + Menu This function allows the PIP mode to be selected. -
Page 17: Lcd Monitor Mounting Guide
LCD monitor Mounting Guide Desktop Adjust the viewing angle of LCD to fit most comfortable monitoring status. 4 5° Mounting the monitor on the rack Note: When adjusting to a rack, you will need to use an optional rack mount to the back side of the LCD monitor. -
Page 18: Troubleshooting
Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solution. Symptom Solution Monitor will not turn on ● Make sure the power cord is plugged in, then press POWER button. No picture, no sound ●... -
Page 19: Lcd Color Monitor Specifications
Humidity Accessories (∗1) The brightness spec. Is from panel spec. Design and Specifications are subject to change without notice. (∗2) It is not guaranteed for all the specified range. VM-HT19LCD 640 x 480 @ 60/72/75 800 x 600 @ 56/60/72/75... -
Page 20: Lcd Color Monitor Dimensions
LCD Color Monitor Dimensions VM-HT19LCD...
