DAVIS Antenna Mast-Mount Kit Quick Start Manual

All manuals and user guides at all-guides.com
A
N T E N N A
F
O R
The Antenna Mast-Mount Kit provides hardware for mounting an antenna mast
(provided by the user) on the station's Sensor Mounting Arm support or other
post or pipe and for mounting a Davis-supplied omni antenna on the mast.
C
OMPONENTS
The Antenna Mast-Mount Kit contains the following components. Please make
sure you have all components before continuing.
2-3/8" U-Bolts & Hardware
1-1/2" U-Bolts & Hardware

Tools and Materials Needed

In addition to the components listed above, you may need some of the follow-
ing tools and materials. Please be sure you have everything you need before
beginning the installation.
3/4" Galvanized Pipe or Antenna Mast, maximum outside diameter of 1-1/4" (32 mm)
Phillips Screw Driver
Slotted Screw Driver
Adjustable Wrench or Socket Set
Electric Drill with 3/16" (4.8 mm) drill bit.
M
O -D
M N I I R E C T I O N A L
Saddle
Flat Washer
Split-Lock
5/16" Hex Nut
Saddle
Flat Washer
Split-Lock
1/4" Hex Nut
-M
A S T O U N T
A
N T E N N A
Antenna
Mounting
Bracket
1/4" x 1-1/2" Lag Screws
1/4" Flat Washer
K
I T
Antenna Mast
Brackets
Product # 7995
