  • Page 1 Flow Communications Options User’s Guide 916-115 F panametrics.com JUL 2021...
  • Page 3 JUL 2021 panametrics.com Copyright 2021 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries. All third-party product and company names are trademarks of their respective holders.
  • Page 4 [no content intended for this page]...

  • Page 5: Table Of Contents

    Contents 1. Modbus Communications Introduction ..................... .1 Installing the MODBUS Option Card .
  • Page 6 Contents Setup ......................58 6.3.1 Downloading the Digi Device Discovery Program .
  • Page 7 Preface Information Paragraphs Note: These paragraphs provide information that provides a deeper understanding of the situation, but is not essential to the proper completion of the instructions. IMPORTANT: These paragraphs provide information that emphasizes instructions that are essential to proper setup of the equipment.
  • Page 8 Environmental Compliance Waste Electrical and Electronic Equipment (WEEE) Directive Baker Hughes is an active participant in Europe’s Waste Electrical and Electronic Equipment (WEEE) take-back initiative, directive 2012/19/EU. The equipment that you bought has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment.
  • Page 9 Chapter Graphics/panametrics_lg_hrz_rgb_pos.eps 1 Graphics/Cover.tif @ 150 dpi 1 Graphics/panametrics_lg_hrz_rgb_pos.eps i Graphics/Wheelie_binx.eps vi Graphics/Figure 01.ai 20 Graphics/Figure 02.ai 21 Graphics/Figure 03.ai 22 Graphics/Figure 04.ai 23 Graphics/Figure 05.ai 24 Graphics/Figure 06.ai 25 Graphics/Figure 07.ai 26 Graphics/Figure 08.tif @ 180 dpi 27 Graphics/Figure 09.tif @ 300 dpi 27 Graphics/Figure 10.tif @ 300 dpi 28 Graphics/Figure 11.tif @ 300 dpi 29 Graphics/Figure 12.tif @ 300 dpi 31...
  • Page 10 Chapter Graphics/Figure 44.tif @ 300 dpi 62 Graphics/Figure 45.tif @ 300 dpi 63 Graphics/Figure 46.tif @ 150 dpi 64 Graphics/Figure 47.tif @ 150 dpi 64 Graphics/Figure 48.tif @ 150 dpi 66 Graphics/Figure 49.tif @ 150 dpi 67 Graphics/Figure 50.tif @ 150 dpi 68 Graphics/Figure 51.tif @ 150 dpi 69 Graphics/Figure 52.tif @ 150 dpi 70 Graphics/NE107_Failed.tif @ 150 dpi 71...

  • Page 11: Modbus Communications

    Chapter 1. Modbus Communications Modbus Communications Introduction GC3E.MBS) Your flowmeter hardware and software ( have been modified to provide improved MODBUS communications. The MODBUS option card provides an RS485 interface with a host system, while the main circuit board continues to support RS232 communications for use with a PC running PanaView™ software. PanaView™...

  • Page 12: Installing The Modbus Option Card

    Chapter 1. Modbus Communications Installing the MODBUS Option Card IMPORTANT: The installation information presented here supersedes the information in the standard flowmeter User’s Manual. The modified flowmeter uses the RS485 standard for MODBUS communications. This standard allows up to 32 nodes (drivers and receivers) on one multidrop network, at distances up to 4,000 ft (1,200 m).
  • Page 13 Chapter 1. Modbus Communications Setting Up MODBUS Communications (cont.) COMM PROGRAM  [The UART bits setting applies only to the RS232 serial port.] BAUD RATE  Press the [ until the desired RS232 UART bits setting current value appears here appears on the option bar and then press the appropriate [Fx] function key to select it.

  • Page 14: Modbus Register Map

    Chapter 1. Modbus Communications Press the appropriate [Fx] COMM PROGRAM function key to select [NONE], MODBUS BAUD RATE [ODD], or [EVEN] for the MODBUS parity setting. current value appears here MODBUS PARITY current setting appears here none even COMM PROGRAM Press the appropriate [Fx] function key to select [1] or [2] MODBUS PARITY...
  • Page 15 Chapter 1. Modbus Communications Table 2: MODBUS Registers for a 1-Channel Gas Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes 2 (16 bit signed int) ”Clear Ch1 Totalizers” Not Used 2 (16 bit signed int) 3, 4** Velocity 4 (32 bit Long Integer) 5, 6*...
  • Page 16 Chapter 1. Modbus Communications Table 2: MODBUS Registers for a 1-Channel Gas Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes RESERVED The complete floating point value is constructed by combining readings from the first register with a second register. An eight Hex digits number will represent the IEEE-754 hexadecimal floating point value.
  • Page 17 Chapter 1. Modbus Communications Table 3: MODBUS Registers for a 2-Channel Gas Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes 38, 39* Ch2 Act Volumetric 4 (IEEE 32 bit Float) 40, 41* Ch2 Std Volumetric 4 (IEEE 32 bit Float) 42, 43** Ch2 Fwd Totals Register 46...

  • Page 18: Notes For A Gas Flowmeter

    Chapter 1. Modbus Communications Table 3: MODBUS Registers for a 2-Channel Gas Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes 112, 113* CH2 SNR Up 4 (IEEE 32 bit Float) 114, 115* CH2 SNR Down 4 (IEEE 32 bit Float) MODBUS baud rate MODBUS parity MODBUS stop bits...
  • Page 19 Chapter 1. Modbus Communications 10. Descriptions: For the GF868, register numbers 26, 27 and 59, 60 have the description Molecular Weight. For the GN868, register numbers 26, 27 and 59, 60 have the description Fpv. Table 4: MODBUS Registers for a 1-Channel Liquid Flowmeter Scaling MODBUS Reg # Description...
  • Page 20 Chapter 1. Modbus Communications Table 4: MODBUS Registers for a 1-Channel Liquid Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes RESERVED The complete floating point value is constructed by combining readings from the first register with a second register. An eight Hex digits number will represent the IEEE-754 hexadecimal floating point value.
  • Page 21 Chapter 1. Modbus Communications Table 5: MODBUS Registers for a 2-Channel Liquid Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes 2 (16 bit signed int) Clear Totalizers 2, 3** CH 1 Velocity 4 (32 bit Long Integer) 4, 5* CH 1 Volumetric 4 (IEEE 32 bit Float)
  • Page 22 Chapter 1. Modbus Communications Table 5: MODBUS Registers for a 2-Channel Liquid Flowmeter Scaling MODBUS Reg # Description (decimal places) Size in Bytes 69, 70** CH 1 DELTH 4 (32 bit Long Integer) 71, 72* CH 2 Power 4 (IEEE 32 bit Float) 73, 74** CH 2 +Energy Register 77...

  • Page 23: Notes For A Liquid Flowmeter

    Chapter 1. Modbus Communications 1.4.2 Notes for a Liquid Flowmeter: Clear Totalizers: Write 1 to Reg 1 to clear Channel 1 and Channel 2 totalizers. Error Value: see table in DF868 manual for error codes Average: average of channel 1 and channel 2 if both channels out of error, channel 1 value if channel 2 is in error, channel 2 value if channel 1 is in error, zero if both channels are in error.
  • Page 24 Chapter 1. Modbus Communications Table 6: MODBUS Registers for a Sentinel Flowmeter MODBUS Reg # Description Default Unit Refresh Size in Bytes 1, 2* Actual Volumetric Flow 4 (IEEE 32 bit Float) 3, 4* Soundspeed 4 (IEEE 32 bit Float) Measurement Status 2 (16 bit Int) 6, 7*...
  • Page 25 Chapter 1. Modbus Communications Table 6: MODBUS Registers for a Sentinel Flowmeter MODBUS Reg # Description Default Unit Refresh Size in Bytes Path D Last Error 10s* 2 (16 bit Int) Path E Velocity m/s x 1000 2 (16 bit Int) Path E Sound Speed m/s x 10 2 (16 bit Int)

  • Page 26: Notes For A Sentinel Flowmeter

    Chapter 1. Modbus Communications 1.4.3 Notes for a Sentinel Flowmeter The Sentinel Flowmeter, when equipped with the optional Modbus output card, can transmit flow data and diagnostic information to a flow computer or SCADA, serially, using a Gould-type RTU protocol. For security and audit-trail purposes, the unit must be programmed through the PanaView interface.
  • Page 27 Chapter 1. Modbus Communications Table 7: Modbus Registers for the Sentinel LCT or Sentinel LNG Flowmeter Composite Channel 1 Channel 2 Channel 3 Channel 4 Register Register Register Register Register Category Measurement Size Format Address Address Address Address Address Primary Velocity 2 LSW float 1 0x0000...
  • Page 28 Chapter 1. Modbus Communications Table 7: Modbus Registers for the Sentinel LCT or Sentinel LNG Flowmeter Composite Channel 1 Channel 2 Channel 3 Channel 4 Register Register Register Register Register Category Measurement Size Format Address Address Address Address Address Temp- Supply Temp 2 LSW float 63 0x003E...
  • Page 29 Chapter 1. Modbus Communications Table 7: Modbus Registers for the Sentinel LCT or Sentinel LNG Flowmeter Composite Channel 1 Channel 2 Channel 3 Channel 4 Register Register Register Register Register Category Measurement Size Format Address Address Address Address Address Meter Error Code 2 LSW 385 0x0180 1409 0x0580 2433 0x0980 3457 0x0D80...
  • Page 30 Chapter 1. Modbus Communications Table 8: Data Type/Symbol for the Sentinel LCT or Sentinel LNG Flowmeter Size Register Sequence Symbol Numeric Type Comments* Integer Single, signed 16-bit word Long integer 2LSW 32-bit signed integer may be listed as double word on some types of programmable logic controller (PLC).
  • Page 31 Chapter 1. Modbus Communications 1-Ch Meter 2-Ch Meter GLOBL COMM Baud Rate (RS232) 1200 2400 4800 9600 19200 UART Bits (RS232) 8,no 8,odd 7,odd 7even 8even Network I.D.? MODBUS Baud Rate 2400 4800 9600 MODBUS Parity NONE EVEN MODBUS Stop Bits MODBUS Address NOTE: Plain text represents prompt area messages and boxed text represents option bar choices.

  • Page 32: Swapping The Floating Point

    Chapter 1. Modbus Communications Swapping the Floating Point To represent a correct floating point value, you may need to swap the reading from two registers. Some applications allow you to swap the registers. Some do not. When using the Modscan32 utility in order to monitor register values, you need to select 03: HOLDING REGISTER (see Figure 3), select the corresponding communications parameters in the menu item Connection-Connect, and hit OK to make a connection.
  • Page 33 Chapter 1. Modbus Communications Swapping the Floating Point (cont.) To see all the register readings in Hexadecimal form, select Menu-Setup-Display Options-Hex (see Figure 4). HEX values are 3E23 and D70A. Figure 4: Finding the Hex Values Communications Options User’s Guide...
  • Page 34 Chapter 1. Modbus Communications Swapping Floating Point (cont.) To monitor the floating point variable, enter the first register of the variable in the Address (see Figure 7), and set the Length to “2”. Looking at only Mass flow register Figure 5: The Mass Flow Register Communications Options User’s Guide...
  • Page 35 Chapter 1. Modbus Communications Swapping the Floating Point (cont.) Then select Menu-Setup-Display Options-Swapped FP (see Figure 6). Modscan32 will swap the register and display the floating point variable correctly. Starting at address 2. Swapped floating swaps every registers. Figure 6: Swapped Floating Point Communications Options User’s Guide...
  • Page 36 Chapter 1. Modbus Communications Swapping the Floating Point (cont.) Web utilities can also be used to convert hexadecimal register readings into floating point values (see Figure 7). Note: How to construct an 8-digit hexadecimal value from two registers is explained at the bottom of the Modbus Register tables, Table 2 on page 5 for 1-Channel flow meters and Table 3 on page 6 for 2-Channel flow meters.

  • Page 37: Introduction

    Chapter 2. Modbus Over Ethernet Communications 1 2. Modbus Over Ethernet Communications 1 IMPORTANT: These setup instructions apply only when using option card 703-1476-05, rev. A, or option card 703-1477-03, rev. C and lower. Introduction This document provides instructions for setting up a flowmeter equipped with Modbus Over Ethernet (Modbus/TCP) communications.

  • Page 38: Setup

    Chapter 2. Modbus Over Ethernet Communications 1 Setup The default IP address in setting up the Ethernet option card is Dynamic (DHCP). If it has to be changed to a static IP address, the instrument must first be connected to the DHCP network. Note: The following are setup procedure examples.

  • Page 39: Changing The Password

    Chapter 2. Modbus Over Ethernet Communications 1 2.2.2 Changing the Password Example: Change the Password for the module with IP address 3.112.161.79 (see Figure 11). Open a DOS command prompt. Type telnet 3.112.161.79 10000 and hit Enter. Enter the current Login and Password. The factory defaults are root and Netsilicon . Note: The Login and Password are case sensitive.

  • Page 40: Changing Ip Parameters

    Chapter 2. Modbus Over Ethernet Communications 1 2.2.3 Changing IP Parameters Example: Change the DHCP-assigned IP address to static address 192.168.2.225 and disable DHCP for the module with IP-assigned address 3.112.161.79 (see Figure 12 on page 31 and Figure 13 on page 32). Open a DOS command prompt.
  • Page 41 Chapter 2. Modbus Over Ethernet Communications 1 2.2.3 Changing IP Parameters (cont.) Figure 12: Changing IP Parameters - 1 Communications Options User’s Guide...
  • Page 42 Chapter 2. Modbus Over Ethernet Communications 1 2.2.3 Changing IP Parameters (cont.) Figure 13: Changing IP Parameters - 2 Communications Options User’s Guide...

  • Page 43: Introduction

    Chapter 3. Modbus Over Ethernet Communications 2 3. Modbus Over Ethernet Communications 2 IMPORTANT: These setup instructions apply only when using option card 703-1476-05, rev. B and higher, or option card 703-1477-03, rev. D and higher. Introduction This document provides instructions for setting up a flowmeter equipped with Modbus Over Ethernet (Modbus/TCP) communications.

  • Page 44: Setup

    Chapter 3. Modbus Over Ethernet Communications 2 Setup The Digi Device Discovery Program is required to set up Ethernet parameters. To download the program, proceed with the following steps: 3.2.1 Downloading the Digi Device Discovery Program Go to www.digi.com on the internet. Move the cursor to the SUPPORT button and select Diagnostics, Utilities and MIBs from the menu.

  • Page 45: Finding The Assigned Ip Address

    Chapter 3. Modbus Over Ethernet Communications 2 3.2.4 Finding the Assigned IP Address The following are setup procedure examples. Note: Example: Find the IP address of the module with Media Access Control (MAC) address 00409d24ded5. Run the Digi Device Discovery Program (see Figure 16). Note: To access the Digi Device Discovery Program , see page 34.

  • Page 46: Changing Ip Parameters

    Chapter 3. Modbus Over Ethernet Communications 2 3.2.5 Changing IP Parameters Example: (to change the dynamic DHCP IP address to static). Change the DHCP-assigned IP address to static address 192.168.2.207 and disable DHCP for the unit with IP assigned address 3.112.162.129 (see Figure 17). Plug the option card into the DHCP network.
  • Page 47 Chapter 3. Modbus Over Ethernet Communications 2 Accept incoming Modbus/TCP in UDP/IP: UDP Port: XXX  Apply Figure 18: Changing Modbus/TCP Port Communications Options User’s Guide...

  • Page 48: Changing User's Information

    Chapter 3. Modbus Over Ethernet Communications 2 3.2.7 Changing User’s Information To change the user name and/or password: Under Device Task select Open web interface . Enter the Username and Password. The factory defaults are root and dbps. Note: The username and password are case sensitive. Panemetrics recommends changing the default password and disabling unused ports and services.
  • Page 49 Chapter 3. Modbus Over Ethernet Communications 2 3.2.7 Changing User’s Information (cont.) To change the User Name, click in the box, delete the current name, and type in the new name. To create a New Password, click in the box, delete the current password, and type in the new password. To Confirm the new Password, click in the box, delete the current password and type in the new password.
  • Page 50 Chapter 3. Modbus Over Ethernet Communications 2 [no content intended for this page] Communications Options User’s Guide...

  • Page 51: Ethernet Only Communications

    Chapter 4. Ethernet Only Communications 4. Ethernet Only Communications Introduction This document provides instructions for setting up a flowmeter equipped with Ethernet Only communications. To apply these procedures, the flowmeter must have the option card installed. See the option card examples in Figure 21 and Figure 22.

  • Page 52: Setup

    Chapter 4. Ethernet Only Communications Setup The Digi Device Discovery Program is required to set up Ethernet parameters for the Ethernet Only board. To download the program, proceed with the following steps: 4.2.1 Downloading the Digi Device Discovery Program Go to www.digi.com on the internet. Move the cursor to the SUPPORT button and select Diagnostics, Utilities and MIBs from the menu.

  • Page 53: Finding The Assigned Ip Address

    Chapter 4. Ethernet Only Communications 4.2.4 Finding the Assigned IP Address The following are setup procedure examples. Note: Example: Find the IP address of the module with Media Access Control (MAC) address 00409d24ded5. Run the Digi Device Discovery Program (see Figure 23). Note: To access the Digi Device Discovery Program , refer to page 42.

  • Page 54: Changing Ip Parameters

    Chapter 4. Ethernet Only Communications 4.2.5 Changing IP Parameters Example: Change the DHCP-assigned IP address to static address 192.168.2.207 and disable DHCP for the unit with IP assigned address 3.112.162.129 (see Figure 24). Under Device Task select Open web interface . Enter the Username and Password.
  • Page 55 Chapter 4. Ethernet Only Communications Note: The username and password are case sensitive. Panemetrics recommends changing the default password and disabling unused ports and services. Click on Login. Figure 25 appears. Select Configuration / Users . Click on New..Figure 26 on page 46 appears. Figure 25: User’s Configuration Menu Communications Options User’s Guide...
  • Page 56 Chapter 4. Ethernet Only Communications 4.2.6 Changing User’s Information (cont.) To change the User Name, click in the box, delete the current name, and type in the new name. To create a New Password, click in the box, delete the current password, and type in the new password. To Confirm the new Password, click in the box, delete the current password and type in the new password.

  • Page 57: Modbus Over Wi-Fi Communications

    Chapter 5. Modbus Over WI-FI Communications 5. Modbus Over WI-FI Communications Introduction This document provides instructions for setting up a flowmeter equipped with Modbus Over WI-FI communications. To apply these procedures, the flowmeter must have the option card installed (see the example in Figure 27) and connected to a WI-FI antenna.
  • Page 58 Chapter 5. Modbus Over WI-FI Communications WI-FI Components (cont.) Figure 29: WI-FI Cable Antenna Connection Figure 30: WI-FI Cable PC Board Connection Communications Options User’s Guide...

  • Page 59: Setup

    Chapter 5. Modbus Over WI-FI Communications Setup The default IP address in setting up the Modbus Over WI-FI option card is Dynamic (DHCP). If it has to be changed to a static IP address, the instrument must first be linked to the DHCP network. Note: The following are setup procedure examples.

  • Page 60: Finding The Assigned Ip Address

    Chapter 5. Modbus Over WI-FI Communications 5.3.4 Finding the Assigned IP Address The following are setup procedure examples. Note: Example: Find the IP address of the module with Media Access Control (MAC) address 00409d24ded5. Run the Digi Device Discovery Program (see Figure 31). Note: To access the Digi Device Discovery Program , see page 49.

  • Page 61: Changing Ip Parameters

    Chapter 5. Modbus Over WI-FI Communications 5.3.5 Changing IP Parameters Example: Change the DHCP-assigned IP address to static address 192.168.2.207 and disable DHCP for the unit with IP assigned address 3.112.162.129 (see Figure 32). Have your option card joined to the wireless network. Under Device Task select Open web interface .
  • Page 62 Chapter 5. Modbus Over WI-FI Communications  Apply Figure 33: Changing Modbus/TCP Port Communications Options User’s Guide...

  • Page 63: Changing User's Information

    Chapter 5. Modbus Over WI-FI Communications 5.3.7 Changing User’s Information To change the user name and/or password: Under Device Task select Open web interface . Enter the Username and Password. The factory defaults are root and dbps. Note: The username and password are case sensitive. Panemetrics recommends changing the default password and disabling unused ports and services.
  • Page 64 Chapter 5. Modbus Over WI-FI Communications 5.3.7 Changing User’s Information (cont.) To change the User Name, click in the box, delete the current name, and type in the new name. To create a New Password, click in the box, delete the current password, and type in the new password. To Confirm the new Password, click in the box, delete the current password and type in the new password.

  • Page 65: Tips For Improving Wireless Data Communications

    Chapter 5. Modbus Over WI-FI Communications Tips for Improving Wireless Data Communications A suitable installation site should locate the antenna in a transmission path as unobstructed as possible; in the direction of the associated router. When a wireless transducer is linked to a router, a yellow LED on the WI-FI option board remains on. Received Signal Strength Indication (RSSI) is an important indicator of wireless link quality.
  • Page 66 Chapter 5. Modbus Over WI-FI Communications [no content intended for this page] Figure 37: System Information Menu - WI-FI Lan Communications Options User’s Guide...

  • Page 67: Wi-Fi Only Communications

    Chapter 6. WI-FI Only Communications 6. WI-FI Only Communications Introduction This document provides instructions for setting up a flowmeter equipped with WI-FI Only communications. To apply these procedures, the flowmeter must have the option card installed (see the example in Figure 38) and connected to a WI-FI antenna.
  • Page 68 Chapter 6. WI-FI Only Communications WI-FI Components (cont.) Figure 40: WI-FI Cable Antenna Connection Figure 41: WI-FI Cable PC Board Connection Setup Communications Options User’s Guide...
  • Page 69 Chapter 6. WI-FI Only Communications The default IP address in setting up the WI-FI Only option card is Dynamic (DHCP). If it has to be changed to a static IP address, the instrument must first be wirelessly linked to the DHCP network. You may need a WI-FI router in order to activate that.
  • Page 70 Chapter 6. WI-FI Only Communications 6.3.4 Finding the Assigned IP Address The following are setup procedure examples. Note: Example: Find the IP address of the module with Media Access Control (MAC) address 00409d24ded5. Run the Digi Device Discovery Program (see Figure 42). Note: To access the Digi Device Discovery Program , see page 59.
  • Page 71 Chapter 6. WI-FI Only Communications 6.3.5 Changing IP Parameters Example: Change the DHCP-assigned IP address to static address 192.168.2.207 and disable DHCP for the unit with IP assigned address 3.112.162.129 (see Figure 43). Have your option card joined to the wireless network. Under Device Task select Open web interface .
  • Page 72 Chapter 6. WI-FI Only Communications Note: The username and password are case sensitive. Panemetrics recommends changing the default password and disabling unused ports and services. Click on Login. Figure 44 appears. Select Configuration / Users . Click on New..Figure 45 on page 63 appears. Figure 44: User’s Configuration Menu Communications Options User’s Guide...
  • Page 73 Chapter 6. WI-FI Only Communications 6.3.6 Changing User’s Information (cont.) To change the User Name, click in the box, delete the current name, and type in the new name. To create a New Password, click in the box, delete the current password, and type in the new password. To Confirm the new Password, click in the box, delete the current password and type in the new password.
  • Page 74 Chapter 6. WI-FI Only Communications Tips for Improving Wireless Data Communications A suitable installation site should locate the antenna in a transmission path as unobstructed as possible; in the direction of the associated router. When a wireless transducer is linked to a router, a yellow LED on the WI-FI option board remains on.

  • Page 75: Foundation Fieldbus Communications

    Chapter 7. Foundation Fieldbus Communications 7. Foundation Fieldbus Communications Optional Measurements Foundation Fieldbus provides a means of communicating with the flowmeter. The patent numbers which apply are 5,909,363 and 6,424,872. This Foundation Fieldbus device supports 6 Analog Input (AI) blocks, which can be configured to supply the following measurements on the network (see Table 9 below).

  • Page 76: Configuration Utility Setup

    Chapter 7. Foundation Fieldbus Communications Configuration Utility Setup The following is an example setup using National Instruments Configuration Utility v3.1. Figure 48 below shows the Configuration Utility with a flowmeter on the network (Panemetrics Flow-XMT). Figure 48: Configuration Utility Setup Example Note: The following procedures assume that the device has been placed in the OOS (out-of-service) mode before executing.
  • Page 77 Chapter 7. Foundation Fieldbus Communications Selecting the Desired Measurements (cont.) After the desired measurements have been selected, choose the unit system (UNIT_SELECTOR) that has been programmed in the flowmeter (English or SI). Figure 49: Primary Selector Drop Down List Communications Options User’s Guide...

  • Page 78: Selecting Units For Ai Blocks

    Chapter 7. Foundation Fieldbus Communications Selecting Units for AI Blocks To select the units for the individual AI blocks: Double click on the AI block for which you wish to set the units (in the tree under GEFlow-XMT; see Figure 48 on page 66).

  • Page 79: Resetting Instrument Totalizers

    Chapter 7. Foundation Fieldbus Communications Resetting Instrument Totalizers To reset the instrument totalizers: Double click on the FLOW transducer block (in the tree under GEFlow-XMT; see Figure 48 on page 66). Select the Others tab and scroll down to the CLEAR_TOTALIZERS listing. Select Clear from the drop down list box (see Figure 51).

  • Page 80: Function Block Application

    Chapter 7. Foundation Fieldbus Communications Function Block Application Figure 52 is an example setup using the Function Block Application editor. The flowmeter AI blocks, along with the AO and PID of another device on the network, are displayed. We have connected the AI_1 OUT of the flowmeter to the CAS IN of the AO block.

  • Page 81: Namur Ne107 Recommended Settings

    Chapter 7. Foundation Fieldbus Communications NAMUR NE107 Recommended Settings NAMUR NE107 provides guidelines for instruments to publish diagnostic information to the Fieldbus Network. Table 10 below shows the diagnostic information available for the ultrasonic flowmeter as well as the recommended settings. Note: A check mark means that masking is active and the error will not be reported.
  • Page 82 Chapter 7. Foundation Fieldbus Communications [no content intended for this page] Communications Options User’s Guide...

  • Page 83: Hart Communications

    Chapter 8. HART Communications 8. HART Communications Introduction The Panametrics GF868, XGM868, XGS868 and XMT868 ultrasonic flowmeters may be modified to permit two-way communication with a HART communication device. This requires the installation of a HART option card in the flowmeter. The option card generates a 4-20 mA analog output signal that can be read by the HART device. Proceed to the appropriate section for detailed instructions on installing and using the HART option card.

  • Page 84: Flowmeter Software Setup

    Chapter 8. HART Communications Installing the HART Option Card (cont.)stalling the HART Option Card (cont.) For a GF868 flowmeter, the option card connector is mounted on the card, and the HART device leads should go to pins 1 and 2 of this connector. As for other option cards installed in the same meter as the HART option card, the HART device will not recognize any option card installed in Slots 3-5 and it will only recognize option cards installed in Slots 1-2 if they are Analog Input, Analog Output, or RTD option cards.

  • Page 85: Using The Hart Interface

    Chapter 8. HART Communications Flowmeter Software Setup (cont.) To configure your HART option card analog output using any of the first three methods, follow the instructions in the appropriate User’s Manual . During configuration, the choice of parameter must be limited to those listed in Table 11. To use the HART device for configuration of the analog output, refer to the instructions that came with that device.
  • Page 86 Chapter 8. HART Communications • Tracking windows (XMT868 only) • Minimum and maximum soundspeed (XMT868 only) • 2-path error handling • Velocity averaging response time • Static density • Error handling • mA error level (if selected) Clear totals • Note: Refer to your User’s Manual for a complete description of each of the above functions.

  • Page 87: List Of Programmable Variables

    Chapter 8. HART Communications List of Programmable Variables For convenient reference, all of the programmable variables for the four flowmeter models are listed in Table 12. Table 12: Programmable Variables Description Format* R/W/B* XMT868 XGS868 XGM868 GF868 Channel Process Variables Ch1, Ch2, or Ave vel f.p.
  • Page 88 Chapter 8. HART Communications Table 12: Programmable Variables Description Format* R/W/B* XMT868 XGS868 XGM868 GF868 Ch1, Ch2, or Ave Temp_super f.p. Ch1, Ch2, or Ave Rho f.p. Ch1 or Ch2 Err code Ch1 or Ch2 re# f.p. Global Meter Information MeterType (Model) #Channels 2-Path?
  • Page 89 Chapter 8. HART Communications Table 12: Programmable Variables Description Format* R/W/B* XMT868 XGS868 XGM868 GF868 Slot 1 or 2 A, B, C, or D Variable uchar if active if active if active if active Slot 1 or 2 A, B, C, or D Units uchar if active if active...
  • Page 90 Chapter 8. HART Communications [no content intended for this page] Communications Options User’s Guide...

  • Page 91: Bacnet/Ip (Bacnet Over Ethernet)

    Chapter 9. BACNet/IP (BACNet Over Ethernet) 9. BACNet/IP (BACNet Over Ethernet) Introduction This chapter provides instructions for setting up a flowmeter equipped with BACNet Over Ethernet communications. To apply these procedures, the flowmeter must have the option card installed. The option card, based on the features that were ordered, will have many components (see Figure 55 and Figure 56).

  • Page 92: Setup

    Chapter 9. BACNet/IP (BACNet Over Ethernet) Setup Using an Ethernet Crossover Cable, connect the flowmeter to a computer as shown in Figure 57. You must set up the computer’s IP parameters according to Figure 57 below. IP = 192.168.0.1 BACNet/IP Ethernet MASK = 255.255.255.0 No GATEWAY...
  • Page 93 Chapter 9. BACNet/IP (BACNet Over Ethernet) Setup (cont.) To change the BACNet Device ID (see Figure 58), under Device Configuration, click on Edit and a screen similar to Figure 59 appears. Enter the flow meter type and/or the device ID and click on “Save Settings” to save the change or “Cancel Changes”...
  • Page 94 Chapter 9. BACNet/IP (BACNet Over Ethernet) Setup (cont.) To change the IP address, under Network Settings, click on Edit and a screen similar to the following appears. Enter the new address and click on “Save Settings” to save the change, or “Cancel Changes” to return to the previous setting. You must type the new IP in the browser to return to the main page.

  • Page 95: Adding Information To The Monitor List

    Chapter 9. BACNet/IP (BACNet Over Ethernet) Adding Information to the Monitor List To test connectivity and view data, use any BACNet monitoring software. The table shown in Figure 61 is used to monitor specific properties of certain objects on the CAS BACNet Explorer. To add new objects to this list, right click on the BACNet device in the main window and select “add this device’s object to monitor list”...
  • Page 96 Chapter 9. BACNet/IP (BACNet Over Ethernet) [no content intended for this page] Communications Options User’s Guide...
  • Page 97 Warranty Warranty Each instrument manufactured by Panemetrics is warranted to be free from defects in material and workmanship. Liability under this warranty is limited to restoring the instrument to normal operation or replacing the instrument, at the sole discretion of Panemetrics. Fuses and batteries are specifically excluded from any liability. This warranty is effective from the date of delivery to the original purchaser.
  • Page 98 Warranty [no content intended for this page] Communications Options User’s Guide...
  • Page 100 E-mail: mstechsupport@bakerhughes.com Copyright 2021 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries. All third-party product and company names are trademarks of their respective holders. 916-115 F...
