Scag Power Equipment WALK BEHIND SFW36-16BV Illustrated Parts Manual

Model sfw walk-behind

Hide thumbs Also See for WALK BEHIND SFW36-16BV:

Operator's manual (48 pages)

Table Of Contents

Quick Links

Download this manual See also: Operator's Manual

IPL

This manual conTains The illusTraTed parTs lisT for models:

sfW36-16BV

sfW48-16BV

Scag Power Equipment

Division of Metalcraft of Mayville, Inc.

Model SFW

Walk-Behind

with a serial number of e5600001 to e5699999

with a serial number of e5700001 to e5799999

ILLUSTRATED

PARTS

MANUAL

Part No. 06202

Printed 2/09

Printed in USA

Table of Contents

Need help?

Do you have a question about the WALK BEHIND SFW36-16BV and is the answer not in the manual?

Questions and answers

Summary of Contents for Scag Power Equipment WALK BEHIND SFW36-16BV

Page 1 This manual conTains The illusTraTed parTs lisT for models: sfW36-16BV sfW48-16BV © 2009 Scag Power Equipment Division of Metalcraft of Mayville, Inc. ILLUSTRATED PARTS MANUAL Model SFW Walk-Behind with a serial number of e5600001 to e5699999 with a serial number of e5700001 to e5799999 Part No.
Page 3: Table Of Contents
Table of contents Table of contents 36" cuTTer decK ...2 48" cuTTer decK ...4 cuTTer decK conTrols ...6 handle assemBlY...8 enGine decK ...10 elecTrical sYsTem and ThroTTle conTrol ...12 replacemenT decals and informaTion plaTes ...14 sfW elecTrical schemaTic ...16...
Page 4: 36" Cutter Deck
36" cuTTer decK section 8...
Page 5 section 8 ref. part no. description 462150 Cutter Deck Weldment w/Decals 04112-06 Nut, 3/4-16 Spiral Lock 04063-01 Key, 1/4 x 1/4 x 1-1/4" 04021-09 Nut, Elastic Stop 3/8-16 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD 424615 Bracket, Belt Guide 424367 Dust Shield 483324...
Page 6: 48" Cutter Deck
48" cuTTer decK section 8 22 5...
Page 7 section 8 ref. part no. description 462149 Cutter Deck Weldment w/Decals 04112-06 Nut, 3/4-16 Spiral Lock 04063-01 Key, 1/4 x 1/4 x 1-1/4" 04021-09 Nut, Elastic Stop 3/8-16 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD 424615 Bracket, Belt Guide 424367 Dust Shield 483323...
Page 8: Cutter Deck Controls
cuTTer decK conTrols section 8...
Page 9 section 8 ref. part no. description 462183 Belt Cover, SFW w/Decals 462181 Frame Weldment w/Decals 04009-13 Bolt, Shoulder 1/2 x 1-1/2" 425023 Pusharm 43041 Spacer 04009-10 Bolt, Shoulder 1/2 x 2-3/4" 04019-04 Nut, Serrated Flange 3/8-16 04021-09 Nut, Elastic Stop 3/8-16 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD 425076...
Page 10: Handle Assembly
handle assemBlY section 8 9 10 SFW 2009 HA...
Page 11 section 8 ref. part no. description 462187 Handle Weldment w/Decals 452039 Operator Presence Handle, LH 452040 Operator Presence Handle, RH 483941 Spring, Operator Presence 04001-13 Bolt, Hex Head 5/16-18 x 2-3/4" 04001-53 Bolt, Hex Head 5/16-18 x 2-1/2" 483161 Plug, Handle Bar 04032-01 Washer, Curved Spring 04021-10...
Page 12: Engine Deck
enGine decK section 8 SFW2009ED...
Page 13 section 8 ref. part no. description *483796 Engine, 16HP Briggs & Stratton 483822 Transmission, 4-Speed 04017-16 Bolt, Serrated Flange 5/16-18 x 3/4" 48231 Switch, Neutral Interlock 48122-01 Fiber Washer, Thin 48122-02 Fiber Washer, Thick 48114-05 Grease Fitting, Straight 1/4-28 481581 Coupler, Jackshaft 481582 Jackshaft...
Page 14: Electrical System And Throttle Control
section 8 elecTrical sYsTem and ThroTTle conTrol...
Page 15 section 8 elecTrical sYsTem and ThroTTle conTrol ref. no. part no. description 483957 Switch, PTO 10 Amp 48609 Keyswitch 462069 Key Chain w/Keys 483609 Key w/Shroud 48717 Switch 483904 Throttle Cable 04010-01 Screw, #10-32 x 1/2" 04019-01 Nut, #10-32 48028-05 Cable Tie 483872 Wire Harness, Handle Bar...
Page 16: Replacement Decals And Information Plates
replacemenT decals and informaTion plaTes WarninG insTall BelT coVer Before operaTinG machine read operaTor's manual WarninG roTaTinG Blades and BelTs * Keep hands, feet & clothing clear * Keep all guards in place * shut off engine & disengage blade clutch before servicing * use caution in directing discharge * read instruction manual before operating...
Page 17 section 8 replacemenT decals and informaTion plaTes ref. part no. description 483402 Decal, Belt Cover 483405 Decal, Discharge Chute 483505 Decal, Spinning Blades 483406 Decal, Warning-Rotating Blades 483404 Decal, Sulky Attachment 483407 Decal, Danger-Spinning Blades 483894 Decal, Cutting Height LH 483895 Decal, Cutting Height RH 48404...
Page 18: Sfw Electrical Schematic
sfW elecTrical schemaTic Operator BLK W/RED STRIPE Presence Switch BLK W/RED STRIPE MOWER ENGAGE WHITE WHITE TO ENGINE DECK WIRE HARNESS TO HANDLE BAR WIRE HARNESS ENGINE CHARGE YELLOW ENGINE MAG KILL WHITE Operator Presence Switch BLACK KEY SWITCH WHITE BLACK BLACK YELLOW...
