Elmo Hybrid ELB-3610 Installation Manual

Regulated output power supply g p p
Option Heater Board Option Heater Board
Special "Rim" construction prevents water droplets on the lower dome surface p
Special "Rim" const im co
Air flow
ELMO Mfg. Corp. 1478 Old Country Road, Plainview, NY 11803-503
Tel.: (516) 501-1400
Fax: (516) 501-0429
pp y
p
truction prevents water droplets on the lower dome surface p ater droplets on the low
S Sealed flange l d fl
Blower
The Blower & Heater
configuration allows
warm air to flow on
lower dome surface
Heater
ELB-3610
ELB-3610B
ELB-3610HB
Outdoor Dome housing for
ELMO PTC-200 & PTC-201C IP
PTZ cameras
Features
- Ingenious upper dome configuration prevents water
droplets on lower dome surface
- Lower dome locked in place with 4 screws with retainers
- 2 lower dome colors available
Fabrication
- UV protected black ABS construction (upper dome)
- 1/8" acrylic (lower dome)
Power Supply Specifications
Regulated output power supply
- Input : 24vac-100va when using H & B
- 24vac camera output
- 9 to 18vdc camera output, maximum 1.2amp at 70˚F
-12vdc output for Blower
- 2amp. 250V Fuse Protection
- Surge Protection
Blower Specifications
- 12vdc, 1 watt, 15cfm
- Continuous duty
Heater Board Specifications
- 24vac, 40watt Heater
- Thermostat activates at 6˚C (39˚F ± 3˚F)
- 24vac camera output
p
Adjustable mounting plate
e surface
Rim
"U U tility lead"
holds lower
dome section
