- Page 1 Table Bases Z000000453 Revised 02 16 2015 ...
- Page 2 X1 Series Table Bases Page 2 of 4 Unpacking Your Shipment Unpack and iden fy each component in each box that you received. If your shipment is missing parts, or too many parts were shipped, please contact Plymold. Components Metal Column with table plate Metal Pedestal Base #10x1.00” screw (8 each) Table Base Glide Table Shox ‐ Op onal Tools Required Screw Gun with #2 Phillips Bit Screw Driver Tape Measure Pencil or Marker 3/4” Box End Wrench Set or Socket ...
- Page 3 X1 Series Table Bases Page 3 of 4 Assembly Instruc ons Step 1: Base Foot Assembly 1: Remove bolt from the bo om of the table column with the lock washer and flat washer. 2: Place the base on the table column and a ach with flat washer, lock washer and bolt. 3: Securely ghten bolt using 3/4” box wrench or socket. Step 2: Table Shox to Base Assembly 1: Screw the table shox into the holes on the bo om of the table base. 2: Tighten with flat blade screw driver. ...
- Page 4 X1 Series Table Bases Page 4 of 4 Assembly Instruc ons Step 3: Base to Table Assembly 1: Turn table top upside down on floor (protect table top with cardboard). 2: Locate center of table top and mark with an “X”. 3: Align plate with “X” marked on the bo om of the table top. 4: With a screw gun, a ach the complete base assembly to the table top with 8 ‐ #10 x 1.00” screws. One in each of the 8 holes of the table plate. Step 4: Final Product 1: Turn table right side up.. 2: Orienta on of feet/legs of table base should point towards corners of the table for maximum stability. 3: Posi on table where you want it. 4: Clean table top and cover un l ready to use. Shown Top Down Shown Bo om up ...
