Summary of Contents for Gilson MyPipetman P2
- Page 1 Quick Guide...
- Page 2 To meet user’s needs, MyPIPETMAN is available in three offers, each with different levels of technical and customization options. For more details, please refer to MyPIPETMAN User’s Guide LT801622 available on www.gilson.com. MyPIPETMAN is available as variable volume, either single or multichannel models. ●...
-
Page 3: Single Channel
Description Single channel Multichannel Color-coded push button Locking system Tip ejector button Customizable handle Color ring Colored Connecting nut window Ejector clip Ejector lock Cover Tip holder Tip ejector Figure 1 MYPIPETMAN® single channel and multichannel model components MyPIPETMAN® | QUICK GUIDE... -
Page 4: Specifications
MyPIPETMAN is a high-quality pipette that has excellent accuracy and precision, especially when used with PIPETMAN® DIAMOND Tips. The data given in the “Gilson Maximum Permissible Errors” table below was obtained using PIPETMAN DIAMOND Tips. These values are guaranteed only when genuine PIPETMAN DIAMOND Tips are used. -
Page 5: Setting The Volume
(refer to Figure 2 on page 6). COLOR OF VOLUMETER NUMBERS MODEL BLACK INCREMENT MyPIPETMAN SINGLE CHANNEL MyPIPETMAN P2 µL 0.01 µL 0.002 µL MyPIPETMAN P10 µL 0.1 µL 0.02 µL MyPIPETMAN P20 µL... -
Page 6: Simple Ratchet
Single channel Multichannel model model P100 7.5 µL 12.5 µL 1.25 µL 7.5 µL 12.5 µL 75 µL x200 x300 P200 P1000 P5000 P10mL 125 µL 125 µL 125 µL 0.75 mL 1.25 mL 7.5 mL Figure 2 Dial colors by model Simple Ratchet For pipettes mounted with a simple ratchet, select the volume by turning the push button... -
Page 7: Fitting The Tip Ejector Adapter
Secure Pipetting After selecting your volume, turn the selector to the right until the cursor reaches the locking for secure pipetting. To ensure good performance, always lock NOTE the pipette before pipetting by selecting the locking icon. Fitting the Tip Ejector Adapter Single Channel Models For P2 and P10 pipettes equipped with a stainless-steel tip ejector, a dual-position... -
Page 8: Fitting The Tips
Multichannel Models For P8x10 and P12x10 models, according to the tip used, either D10 or DL10, you may have to fit the ejector adapter. Long collar tips can be inserted without it. Remove the tip ejector, keep both ejector locks depressed , and then pull the tip ejector down Fit the ejector adapter... - Page 9 Multichannel Models PIPETMAN DIAMOND Tips: TIPACK AND TOWERPACK PIPETMAN DIAMOND tips are best fitted with the ROCKY RACK technique, invented by Gilson, available only in our TIPACK and TOWERPACK. PIPETMAN DIAMOND Tip Compatibility for Multichannel Models D10*, DL10, DF10ST, P8x10, P12x10...
-
Page 10: Cleaning And Decontamination
Dispensing Place the end of the tip against the inside wall of the recipient vessel (at an angle of 10° to 40°). Press the push button slowly and smoothly to the first stop. Wait for at least a second, then press the push button to the second stop to expel any residual liquid from the tip. -
Page 11: Maintenance
(including seal and O-rings). This warranty shall also be void in the event pipettes are altered or modified by any party other than Gilson or its designates. Gilson’s sole liability under this warranty shall be limited to, at Gilson’s sole option, repair or replacement of any defective... - Page 12 LT801608/A | ©2019 Gilson, Inc. All rights reserved. LT801608/B | ©2022 Gilson, Inc. All rights reserved.
