OWNER'S
MANUAL
Model No. GZFI8113.5
Serial No.
Write the serial number in the
space above for future reference.
Serial
Number
Decal
(inside
tower)
Q
UESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Visit our website at
www.freemotionfitness.com
®
