Saxby Lighting Hades 91954 Instruction Manual

Wiring
Having correctly identified the wiring from your existing light fitting, connect to the approved IP67 (or higher rated) terminal
block in the following way (recommended terminal block Ref. 90131/90132)
SUPPLY
NEUTRAL
SWITCHED LIVE
Technical data
Supply
220-240 V~, 50 Hz
Voltage:
Bulb
91954--------1.2W LED module (SMD), 3000K
Type:
91955--------1.2W LED module (SMD), 4000K
91956--------1.2W LED module (SMD), Blue
Except the 91956, these products contain a light source of energy efficiency class G.
Non-replaceable light source
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
This product is rated at IP67.
67
IP
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
The LED's are protected by a plastic lens. The lens part must be replaced immediately should
it become cracked or damaged. This fitting must not be used without the plastic lens in place.
Replace Cracked Shade
For further information, please visit https://www.lighting-info.co.uk/91954
V2 28/11/2021
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
LIGHT FITTING
Check that...
BLUE (N)
You have correctly identified the wires.
The connections are tight.
BROWN (L)
No loose strands have been left out of the
connection block.
Non-replaceable control gear
Instruction manual
Hades
91954, 91955, 91956
