CONTOUR L AYOUT
Power On/Off Button
[FRONT OF CONTOUR]
Turns Contour On
Push and hold the Power On/Off button for five
seconds. The LED ring around the button turns
blue when Contour is powered on.
Turns Contour Off
To power down, push the button and hold for five
seconds or until Contour begins to shut down.
QUICK S TAR T GU IDE
USB 3.0
Contour Serial Number
BUT TONS & PORTS
Scan Start/Stop Button
[BACK OF CONTOUR]
Initiate Scanning
Push the Scan Start/Stop button once to initiate the
scanning operation. The LCD screen guides you
through scan options.
Start Scanning
Push the Scan Start/Stop button a second time to
begin the collection process.
Scan Start/Stop
Scan Start/St
Button
Button
Neck Strap Lu
Neck Strap Lug
LCD Touchscr
LCD Touchscreen
USB 3.0/USB
USB 3.0/USB
Port Cover
Port Cover
USB 3.0/USB Port
USB
Colorization Camera
Feature Tracker
Charging/Ext Battery Port
Neck Strap Lug
Mapping Lidar
WHAT'S IN THE BOX?
Contour
USB Wireless Mouse
AC Charger
& Keyboard
USB 3.0 Hub
Neck Strap
Kaarta Warranty
Trickle Charger
Registration Card
Pelican Case
LCD Touchscreen
Stop Scanning
Push the Scan Start/Stop button during active
scanning to stop the process and save the point
cloud.
