ThermoFlow Elex Mini Basic Series Installation Manual, User Manual, And Warranty Information

Electrically controlled tankless water heater

Hide thumbs

Table Of Contents

Quick Links

Electrically Controlled Tankless Water Heater

Installa�on Guide, User Manual, and Warranty Informa�on

Mini Tankless

Instant

Water Heater

Elex Mini Basic Series

Elex Mini Pro Series

e-mini manual thermoflow -na.indd 1

2020/3/25 15:20

Table of Contents

Need help?

Do you have a question about the Elex Mini Basic Series and is the answer not in the manual?

Questions and answers

Jeff

January 24, 2025

How to adjust temperature

1 comments:

Mr. Anderson

February 10, 2025

The manual does not provide specific instructions on adjusting the temperature directly. However, it states that after completing Step 3, opening the hot-water tap again will wake up the appliance, and the LED will display the real-time outlet temperature. If temperature adjustment is needed, it may be controlled by regulating the water flow rate, which should only be adjusted by a specialist. Turning the adjusting screw clockwise decreases the maximum flow rate, which could affect the temperature.

This answer is automatically generated

Summary of Contents for ThermoFlow Elex Mini Basic Series

Page 1 Electrically Controlled Tankless Water Heater Installa�on Guide, User Manual, and Warranty Informa�on Mini Tankless Instant Water Heater Elex Mini Basic Series Elex Mini Pro Series e-mini manual thermoflow -na.indd 1 2020/3/25 15:20...
Page 2: Table Of Contents
Contents Contents Contents ��2 Safety Instructions ��3 Mounting Instructions ��7 Technical Specifications ��16 User Manual ��19 Maintenance ��21 Troubleshooting ��22 Warranty Conditions ��23 Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 2 2020/3/25 15:20...
Page 3: Safety Instructions
Connect the connector to the grounding terminal of the electric service or supply panel with a continuous copper wire in accordance Ca- nadian Electrical Code, Part I. Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 3 2020/3/25 15:20...
Page 4 Each individual heating element is marked with the manufacturer’s part number or its electrical rating in voltage and amperes/watts. The specific spacing between the appliance and adjacent surface. SAVE THESE INSTRUCTIONS Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 4 2020/3/25 15:20...
Page 5 2. BRANCHER UNIQUEMENT À UNE DÉRIVATION PROTÉGÉE PAR UN DISJONCTEUR DIFFÉRENTIEL DE CLASSE A. Pour utilisation sur un circuit de branche individuel uniquement. Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 5 2020/3/25 15:20...
Page 6 If the supply cord is damaged, it must be replaced by the manufacturer, its ser- vice agent or similarly qualified persons in order to avoid a hazard. Declaration of conformity We hereby declares that the Thermoflow devices comply with the following standards: • CAN/CSA E60335-2-35 • CAN/CSA-C22�2 No� 60335-1 •...
Page 7: Mounting Instructions
60Hz Tankless WIRE Panel Water Heater NOTE: The wire has been attached to the appliance. Circuit diagram for Mini Basic Series Elex 3.5MHBL Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 7 2020/3/25 15:20...
Page 8 Circuit diagram for Mini Basic Series Elex 4.5/5.5 MHB Circuit diagram for Mini Pro Series Elex 3.5MEBL Water flow sensor To LED display Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 8 2020/3/25 15:20...
Page 9 • Adhesive tape • Wire stripper Environment To prevent damage during transport this unit is supplied in robust packaging� Please recycle the packaging where possible� Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 9 2020/3/25 15:20...
Page 10 Make sure the clearance meet the requirement of following diagram� Top clearance 4” Front clearance 4” Left clearance 4” Right clearance 4” Bottom clearance 4” Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 10 2020/3/25 15:20...
Page 11 The warranty only applies if the product has not been modified in any way, i.e. subject to it being in unchanged condition. Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 11 2020/3/25 15:20...
Page 12 Drawing A. - Installation as undersink model a. Seal b. Filter mat c. Cold water-connection (inlet) d. Hot water-connection (outlet) e. Rating plate cover Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 12 2020/3/25 15:20...
Page 13 Rated voltage 120V Rated voltage 240V Power Supply Power Supply Outlet Outlet L1 L2 Inlet Inlet Drawing B. - Installation as oversink model Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 13 2020/3/25 15:20...
Page 14 Hot water-connection (outlet) e. Rating plate cover Rated voltage 120V Rated voltage 240V Power Supply Power Supply L1 L2 Outlet Inlet Outlet Inlet Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 14 2020/3/25 15:20...
Page 15 4� Connect power cable L, N and GROUNDING (120V models) to the power supply (4a), or connect power cable L1, L2 and GROUNDING (240V models) to the power supply (4b), then switch on the circuit breaker� Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 15 2020/3/25 15:20...
Page 16: Technical Specifications
150 psi 150 psi Min� inlet water pressure 15 psi 15 psi 15 psi Switch on flow pressure 15 psi 15 psi 15 psi Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 16 2020/3/25 15:20...
Page 17 150 psi 150 psi Min� inlet water pressure 15 psi 15 psi 15 psi Switch on flow pressure 15 psi 15 psi 15 psi Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 17 2020/3/25 15:20...
Page 18 Max� inlet water pressure 150 psi 150 psi Min� inlet water pressure 15 psi 15 psi Switch on flow pressure 15 psi 15 psi Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 18 2020/3/25 15:20...
Page 19: User Manual
Simply connect the power supply and inlet/outlet, open the tap for about 15 secs before switching on power supply, then switching on power supply, the water heater will start working. Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 19 2020/3/25 15:20...
Page 20 In this case, the flow should be reduced with the hot water valve� There is a danger of scalding at out- flow temperatures exceeding 43°C (109°F)� Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 20 2020/3/25 15:20...
Page 21: Maintenance
This can be accessed by separating the device from the tap� Make sure you have switched off the main power supply and the main water supply� Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 21 2020/3/25 15:20...
Page 22: Troubleshooting
Please call for your local service� “E2” If the appliance still fails to operate after you have executed this procedure, please inform customer service. Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 22 2020/3/25 15:20...
Page 23: Warranty Conditions
The statutory provisions and delivery conditions of the national company or importers must be observed� Electric Tankless Water Heater - Installation Manual and User Guide e-mini manual thermoflow -na.indd 23 2020/3/25 15:20...
Page 24 Elex Mini Basic Series Elex Mini Pro Series MINH_MINE NA-B REV 3�4 202003 e-mini manual thermoflow -na.indd 24 2020/3/25 15:20...
